01 18 SKY OCULUS

SKY OCULUS

The SkyOculus Series is our signature round luminaires: recessed, surface, and pendant mounted. Our most timeless form for nearly 40 years, because the circle is literally timeless.

01 19 P4000

P3900

P9000

P8900

SKY OCULUS

01 20

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com P3900

CLIENT

ARCHITECT

Julian Street Library Princeton University

Joel Sanders Architect

AROUND AND AROUND The flexibility, form and function in this simple 360º is astounding. Choose from 14 premium or custom paint colors, gloss and matte. Hang with aircraft cable; surface or pendant mount; use recessed or all three, to mix it up. Choose 18", 24", 36", 48", 60" and a whopping, gorgeous 72" wide circle of perfection.

Recessed P9000 • • • • •

Simply melts into the environment Minimal 7/16" trim or trimless (X7) Flush or drop lens T-bar or hard ceilings (concealed flange option) 12",18", 2’, 3’, 4’ diameters

Recessed P8900 • • • • •

The standard for four decades Slightly regressed 2" trim for a “skylight efect” Concave, convex or flat lens T-bar ceilings or hard ceilings 12", 2’, 3’, 4’, 5’, 6’ diameters

Surface/Suspended P4000 • • • • •

Sleek Euro styling Extruded aluminum housing Sharp 90º edge, slim .5" trim Convex or flat, white acrylic lens 18", 2’, 3’ and 4’ diameters

Surface/Suspended P3900 • • • • •

Classic styling Hand-spun steel two-piece housing Soft radius edge, 1" trim Convex or flat, white acrylic lens 18", 2’, 3’ and 4’ diameters

01 21

SKY OCULUS / P4000

01 22

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P4000

Mercedes Benz

Interior Architects

ORDERING MATRIX Series

Lamp Rows

P4018 P4020 P4030 P4040

18" diam. 2' diam. 3' diam. 4' diam.

LED3 LO, SO, HO † 3000K LED35 LO, SO, HO † 3500K LED4 LO, SO, HO † 4000K P4018 2Bx18w P4020 1T8U6 2Bx39w 2Bx55w P4030 3T8U6 6T5/HO P4040 5T8U6 7T5/HO LO-Low, SO-Standard, HO-High (Output)

†

Shielding

Color/Finish

Distribution Circuiting Voltage

Mounting

Ceiling System

Options See key on back cover.

LED Options

VWA* Convex White Acrylic (1" max. drop) WA White Acrylic Lens PRA Prismatic Acrylic Lens - N/A LED *Standard - VWA lens recommended for LED, lamp imaging may be visible with WA lens TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color Note: Top plate is always Gloss White

P4000 5"

D1 Direct D9 Semi-Direct (10-25% uplight)

18", 26", 37 /8", or 47 /8" 5

SC Single Circuit DC Dual Circuit 120 277 UNV 120-277 - Only LED Voltage SUR* Surface Mount - Standard CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) MPCA Monopoint Mounting SSC Top Swivel Stem Mount SMR Semi-Recessed into hard celiing *D1 Distribution only 4018 Cable Mounted only X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid

One of our classic signature round pendants, P4000 is housed in a smooth extruded aluminum exterior encasement with crisp corners and a minimalist trim detail. Overall fixture depth is 5" and comes in four diameters: 18", 2’, 3’ and 4’. Specify direct only or as a semi-indirect to bathe ceilings in a warm glow. Lens options include flat or convex with lamping options of either LED, Biax, T8U6, T5 or T5HO.

EML EMH 10THD N/A 4018 B_ BSH Stem Mounting DM Specify (N/A 4018) FH IBC RSE T8 & Biax only N/A 4018 ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

01 23

SKY OCULUS / P3900

01 24

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P3900 Guess? Headquarters

ARCHITECT

PHOTOGRAPHER

Studios Architecture

fotoworks

ORDERING MATRIX Series

Lamp Rows

P3918 P3920 P3930 P3940

18" diam. 2' diam. 3' diam. 4' diam.

LED3 LO, SO, HO † 3000K LED35 LO, SO, HO † 3500K LED4 LO, SO, HO † 4000K P4018 2Bx18w P4020 1T8U6 2Bx39w 2Bx55w P4030 3T8U6 6T5/HO P4040 5T8U6 7T5/HO † LO-Low, SO-Standard, HO-High (Output) see Options for Dimming

Shielding

Color/Finish

Distribution Circuiting Voltage

Mounting

Ceiling System

Options See key on back cover.

LED Options

VWA* Convex White Acrylic (1" max. drop) WA White Acrylic Lens PRA Prismatic Acrylic Lens - N/A LED *Standard - VWA lens recommended for LED, lamp imaging may be visible with WA flat lens YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color

P3900 4 1/2"

D1 Direct D9 Semi-Direct (10-25% uplight)

18", 26", 37 1/4", or 48"

SC Single Circuit DC Dual Circuit 120 277 UNV 120-277 - Only LED Voltage SUR* Surface Mount - Standard CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) MPCA Monopoint Mounting SSC Top Swivel Stem Mount for Hard Ceilings (specify length in inches) *D1 Distribution only X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid

A timeless standard, P3900 is one of our signature fixtures in the classic family of round luminaires. Fabricated with an inner and outer spinning of single-piece, 20-gauge steel, P3900 has an overall depth of 41/⁄2". This fixture comes in four diameters; 18", 2’, 3’ and 4’. Lens options include flat or convex with lamping options of either LED, Biax, T8U6, T5 or T5HO.

EML EMH 10THD N/A 3918 B_ BSH DM FH IBC RSE ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

01 25

SKY OCULUS / P3900

01 26

CONTACT PRUDENTIAL LTG. LTG. CONTACT PRUDENTIAL

FIXTURE FIXTURE

CLIENT CLIENT

ARCHITECT ARCHITECT

Tel. 213.746.0360 / prulite.com P3900 Pierce Atwood LLP Winton Scott Architects Tel. 213.746.0360 / prulite.com P3900 South Elementary #9 HMC Architects

PHOTOGRAPHER

RMA Photography

01 27

SKY OCULUS / P9000

01 28

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P9000 GKK Works

ARCHITECT

PHOTOGRAPHER

GKK Works

Lawrence Andersen

ORDERING MATRIX Series

Lamp Rows

P9012 P9018 P9020 P9030 P9040

12" diam. 18" diam. 2' diam. 3' diam. 4' diam.

LED3 LO, SO, HO † 3000K LED35 LO, SO, HO † 3500K LED4 LO, SO, HO † 4000K P9012 2CFL_w - 26w, 32w, 42w 2Bx18w P9018 3Bx18w 1T5C or 1T9C Circline P9020 (2) T8, T8U6 2Bx_w*, 3Bx_w*, 4Bx_w* P9030 (4) T8, T5/HO, (6) T8, T5/HO P9040 (6) T8, T5/HO, (8) T8, T5/HO *Specify 39w, 40w, 50w, 55w

P9000

LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

7 1/2 " 8 1/4 "

†

Shielding Color/Finish

Circuiting Voltage

Ceiling System

Options See key on back cover.

FWA Flush White Acrylic Lens DWA Drop White Acrylic Lens YGW Gloss White TMW Textured Matte White - Standard Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X3 Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML EMH* 10THD N/A 9018 B_ Specify Requirements DM Specify Requirements, N/A 9018 FH RSE T8 & Biax only - N/A in 9018

11 1/4 ", 17 1/4 ", 22 1/4 ", 34 1/4 ", 46 1/4 "

Designed with a refined aesthetic, P9000 is a slimmer iteration of P8900, scaled back to a minimal doorframe trim and co-planar lens that is flush to the ceiling surface. A trimless option is also available for hard ceilings. P9000 has a flat white acrylic lens option for a contrasting ceiling texture. Fixture is available in LED or fluorescent lamping. P9000 is a beautiful circle of light for a streamlined, modern architectural luminescence. Shown here with a drop white acrylic lens option (DWA).

*4’ minimum length *Consult Factory LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

01 29

SKY OCULUS / P8900

01 30

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P8900 Mercer

ARCHITECT Charles David Smith

ORDERING MATRIX Series

Lamp Rows

P8912 P8920 P8930 P8940 P8950 P8960

12" diam. 2' diam. 3' diam. 4' diam. 5' diam. 6' diam.

LED3 LO, SO, HO † 3000K LED35 LO, SO, HO † 3500K LED4 LO, SO, HO † 4000K P8912 2CFL_w - 26w, 32w, 42w 2Bx18w P8920 (2) T8, T8U6 2Bx_w*, 3Bx_w*, 4Bx_w* P8930 (4) T8, T5/HO, (6) T8, T5/HO P8940 (6) T8, T5/HO, (8) T8, T5/HO P8950 (8) T8, T5/HO, (10) T8, T5/HO, (12) T8, T5/HO P8960 (6) T8, T5/HO, (8) T8, T5/HO (12) T8, T5/HO *Specify 39w, 40w, 50w, 55w LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming †

Shielding

Color/Finish

Voltage

Ceiling System

Options See key on back cover.

11 3/4"

CWA Concave White Acrylic - Standard VWA Convex White Acrylic FWA Flat White Acrylic (6' size N/A) TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color Note: Indicates color of outer ring only

Circuiting

P8900

SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X1T T-Bar Ceiling w/tegular panels X3B Hard Ceiling (flange trim)

60" or 72"

A definitive architectural classic, P8900, or SkyOculus, is a 40-year standard bearer of quality and aesthetic style. Available in a wide range of diameters from 12" to 6’ and lenses–concave, convex and flat–P8900 is a timeless beauty and a conceptual lighting element to embellish any design. This is the ideal fixture for large public buildings like spacious offices, courthouses, retail, schools and museums.

EML* EMH* 10THD B_ Specify Requirements DM Specify Requirements, N/A 8918 FH RSE T8 & Biax only - N/A 8918 *Consult Factory

LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

01 31

SKY OCULUS / P8900

01 32

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P8900/P43 Hanover Park Police Headquarters

ARCHITECT

PHOTOGRAPHER

Dewberry Architects

Mariusz Mizera Photography

01 33

02 34 PERIMETER & COVE

PERIMETER & COVE

Perimeter lighting underscores design lines and provides space-defining illumination with a simple linear luminaire with a chameleon-like versatility and adaptability.

02 35 P43

Bionic

P83

P80i

P45i

SuperCove

P59

MicroCove

PERIMETER & COVE

02 36

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Bionic

REIMAGINE THE BORDERS THAT DEFINE A SPACE Hidden in plain sight -- our perimeter systems define the architectural bones of a space, illuminating a room’s lines, contours and bounds with obscured, seamless lighting. Prudential Ltg.’s perimeter systems evolved in anticipation of your every lighting need. From functional and design perspectives to efficiency criteria and aspired look, these systems are the logical choice to illuminate design without obstructing it. Luminosity elevates design.

Bionic and P43 45º

45º

Flush, 1" or 3" regressed lens or louver

•

Complementary family of wall wash and open plan luminaires

•

Bionic or P43 with LED Bionic and P43’s Industry Leading LED Performance 61 lumens per watt

45º

Integrates seamlessly into ceiling systems

0º

45º

•

Bionic or P43 with fluorescent Bionic and P43’s Industry Leading Fluorescent Performance 77% efficiency

45º

P83 and P59 Flush, 1", 3" or 4" regressed lens (P83 only)

•

Floating ceiling effect

•

Bionic, P43 or P83 with lens and LED or fluorescent

45º

Telescoping lamp rows

0º

45º

•

P59 with LED

45º

P59 and P80i Staggered or centerline perimeter (P80i only)

•

Floating ceiling effect

•

0º

P59 with parabolic reflector and fluorescent

0º

P80i with fluorescent

Telescoping lamp rows

•

02 37

PERIMETER & COVE / BIONIC

02 38

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Bionic

Gershman Foundation

RA-DA Studio

Ralf Strathmann

ORDERING MATRIX Series

Style

Lamp Rows

BIO-PLED LED BIO-PSTD Standard Lamping BIO-PSTG Staggered BIO-PSM Seamless Lamp FLSH Flush Lens REG1 1" Regressed Lens REG3 3" Regressed Lens LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K BIO-PSTD: 1T8, 2T8 (D1 only), 1T5/HO BIO-PSTG: 1T8, 1T5/HO, 2T5/HO BIO-PSM: 1SM/HO Osram Seamless T5 Lamp *LO-Low SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

Trim Color+

Distribution

02’ 03’ 04’ 06’ 08’ R__* Row Length AWW* Acrylic Wall Wash Lens - N/A PSTG SAL Satin Acrylic Lens - Standard SPL Silver Parabolic Louver - N/A LED *D1G or D1R Distribution only TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color + Indicates color of flange trim D1 Direct Symmetric D1G* Asymmetric 5°Wall Grazer D1R* Asymmetric to Room (15°) *AWW Lens only

Circuiting

SC Single Circuit DC Dual Circuit - Staggered only

Mounting

WTW Wall to Wall LP Light Pocket

Voltage

Ceiling System

Options See key on back cover.

120 277 347 N/A with MR16s UNV 120-277 - Only LED Voltage X1* Exposed T-Bar 15/16" X1m* Exposed T-Bar 9/16" X2* Dimensional T-Bar Armstrong Interlude® X3 Hard Ceiling (flange trim) X6 Slot Grid X7BF Hard Ceiling Trimless (mud-over backer flange) *Techzone™ compatible EML* EMH* DM RSE T8 only B_ FH QC M1 12" MR16 Module 1/50w lamp M2 12" MR16 Module 2/50w lamp MD SORAA LED MR16 lamp C2 90° 2-Way Corner w/acrylic lens

BIONIC 5 7/16"

02 39 4"

Premium-grade 4" continuous, modular channel-lighting system, Bionic Perimeter™ is available in flush, 1" or 3"” regressed lens or louver. Choose between a soft glow optic to create a floating ceiling effect or our FusionOptics™ integrated reflector-refractor design for a tight wall graze distribution. Dedicated LED options, or staggered and nonstaggered fluorescent options combine with a uniquely engineered housing for simple installation and profound compatibility with multiple modern ceilings systems. >

See the reference fixture on pages 89, 111.

*Consult Factory LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

PERIMETER & COVE / P43

02 40

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com P43

ORDERING MATRIX Series

P43-LED P43-PSTD Standard Lamping P43-PSTG Staggered

Style

FLSH Flush Lens REG3 3" Regressed Lens

Lamp Rows

LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K P43-PSTD: 1T8, 2T8, 1T5/HO, 2T5/HO (2 lamp D1 only) P43-PSTG: 1T8, 1T5/HO, 2T5/HO (2 lamp, D1 only) *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

02’ 03’ 04’ 06’ 08’ R__*Row Length AWW* Acrylic Wall Wash Lens SAL Satin Acrylic Lens OPL Opal Frost Acrylic Lens PRA† Prismatic Acrylic Lens SPL† Silver Parabolic Louver BLA† Blade Louver-Anodized BLW† Blade Louver-White *D1G or D1R Distribution only † Not available in LED

Color/Finish

Distribution

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color D1 Direct Symmetric D1G* Asymmetric 5°Wall Grazer D1R* Asymmetric to Room 15° *AWW Lens & 1 Lamp or LED Only

Circuiting Voltage

Ceiling System

Options See key on back cover.

P43

SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML* EMH* DM RSE 10THD B_ FH QC C2 90º 2-Way Connector

5˝ 5"

4˝

P43 is a taut sliver of light. This 4" aperatured, continuous recessed perimeter system for T-bar or hard ceilings gives a choice of wall graze or soft glow optical distributions allowing P43 to adapt to any space. Lens or louver is flush or regressed 3" to give a floating celing effect. Lamping includes LED or staggered or non-staggered fluorescent for smooth line of light. Telescoping lamps and wide variety of ceiling interface trims make P43 ideal for complex fast track projects. >

See the reference fixture on pages 95, 115.

*Consult Factory LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

02 41

PERIMETER & COVE / P59

02 42

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P59

Gershman Foundation

RA-DA Studio

Ralf Strathmann

ORDERING MATRIX Series/Style

P59 - A6 6" Aperture P59 - A9 9" Aperture

Lamp Rows

1T8 1T5/HO LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K *LO-Low Output, SO-Standard Output, HO-High Output - see Options for Dimming

Nominal Length

13 13/32"

P59

5˝

127mm

R__*Row Length

6" or 4˝8 7/8 " 102mm

*Row length - advise factory of row & pattern dimensions Reflector System

Voltage

Ceiling System

Options See key on back cover.

W White - Standard PR* Parabolic Reflector (pushes light down the wall - flourescent only) 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML* EMH* DM RSE† 10THD† B_ FH QC C2 CX ADS

A recessed, indirect perimeter system, P59 has an option for either a 6" or 9" aperture. Choose a soft indirect glow for a floating ceiling or a parabolic reflector to push the warm light vertically down the wall. Lamping options include LED or single row T8, T5, T5HO lamps. Designed as a prefabricated cove system for suspended or hard ceiling systems. Use the mud-over concealed flange to create a seamless transition from ceilings to cove.

*Consult factory for fixture lengths < 4' †T8 only LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

10 5/8" 8 7/8"

45º

45º 0º

02 43

PERIMETER & COVE / P59

02 44

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P59

Stuart Haaga Gallery of Art at Descanso Gardens

Frederick Fishers & Partners

02 45

GREEN PRODUCTION CYCLE

e ycl c e .R

1. W at

GREEN CYCLE

We make things. And in the process, we try to make things better. For the environment and for future generations. Our ultimate goal: eliminating any waste of material and natural resources from our production process. After all, the light we create, and how we create it, can ensure brighter days ahead for all of us. Here are five key areas we’re focused on.

ocial S . 4

2. Reso u r ces

02 46

3. Energy 1. Water. Here in Los Angeles, no resource is more precious than water. That’s why the dionized water we use to clean our fixtures is recycled in a closed-loop and no harmful chemicals are being released into the water table. The polyester powder-coat paint discharges no CFC’s or other harmful chemicals into the environment.

2. Resources. We locally source as much as possible. It helps cut our carbon footprint--and lead times. The metals that give our fixtures form have a high recycled content. And being in LA means the fabled California sunshine lets us harvest a significant amount of daylight. A lighting factory that conserves electricity? That’s Prudential.

3. Energy. Advancing LED optics are improving the energy-efficiency of our luminaires at a remarkable rate. More than 40 of our fixtures have configurations that operate at efficiency levels of 80% or above. And many of our fixtures now offer integrated controls like occupancy sensors that drastically cut energy consumption.

02 47

4. Social. We believe in giving back to the community we come from. It’s what has guided the actions of our family-owned, woman-owned business for 60 years. Giving back is why we’re an American Institute of Architects Continuing Education Provider, why we’re members of the U.S. Green Building Council and why

we support local non-profits like Dress for Success, the Los Angeles School Police Association, Habitat for Humanity, Ace Mentor, Los Angeles, the Cancer Foundation, Ronald McDonald House, Amigos de los Ninos, American Heart Association and Heal the Bay. We also donate fixtures to schools as well as computers.

5. Recycle. Reduce, re-use, recycle--that’s our mantra. Our lean manufacturing process reduces waste both of materials and energy. We recycle all of our steel, aluminum, copper, corrugated cardboard and acrylic. The packaging we use to ship our fixtures comes from recycled materials too.

PERIMETER & COVE / P83

02 48

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P83

USC John McKay Sports Center

RA-DA Studio

Ralf Strathmann

ORDERING MATRIX Series

Lens Position

Lamp Rows

P83-STD P83-STG P83-LED FLSH REG1 11/2" Regress REG3 3" Regress REG4 4 3/8" Regress LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 2T8 1T5/HO 2T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

02’ 03’ 04’ 06’ 08’ R__ *Row Length *Row length - advise factory of row and pattern dimensions

Shielding

Circuiting

SAL Satin Acrylic Lens PRA Prismatic Acrylic Lens (only Flush) SPL* Silver Parabolic Louver BLA† Blade Louver Aluminum BLW† Blade Louver White *REG4 position N/A † REG4 N/A in STG SC Single Circuit DC* Dual Circuit - 2T8 only *N/A on LED

Voltage

Ceiling System Options See key on back cover.

120 277 347 UNV 120-277 - Only LED Voltage

P83 6 5/8" 6"

A prefabricated 6" perimeter system, P83 is a straightforward approach to perimeter lighting. With a choice of lens or louver elevations, field trim-able extension kits, telescoping lamp modules, 90º corner units and choice of LED or fluorescent lamp sources, P83 is the perfect perimeter complement to any design.

X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) EML* EMH* DM RSE 10THD B_ FH QC C2 *Consult factory for fixture lengths < 4’

LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

02 49

PERIMETER & COVE / P80i

02 50

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P80i

USC John McKay Sports Center

RA-DA Studio

Ralf Strathmann

ORDERING MATRIX Series Lamp Rows

Nominal Length

P80i 1T8 2T8 1T5/HO 2T5/HO 03’ 04’ 06’ 08’ R__ Row Length

P80i 7 3/4 "

9 3/4 "

*Row length - advise factory of row and pattern dimensions Shielding

PRA Prismatic Acrylic Lens SPL Silver Parabolic Louver BLA Blade Louver Aluminum BLW Blade Louver White

Reflector

W White - Standard S Specular Miro™ IV Aluminum NR No Reflector

Circuiting

SC Single Circuit DC* Dual Circuit (in-line) *2 Lamp Rows Only

Voltage

Ceiling System Options See key on back cover.

120 277 347 UNV 120-277

P80i is a fantastically versatile, configurable luminaire. This luminaire is a prefabricated 9 3/⁄4" perimeter system designed for easy installation in T-bar or hard ceiling systems. P80i has options for 1 or 2-T8, T5 or T5HO staggered lamp rows. Telescoping lamp ends create even illumination over the whole length of the lighting system. System can be customized to nearly any space with available 90º and 45º angle corner units.

X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) NSS EML EMH DM RSE T8 Only 10THD T8 Only B_ FH QC C2 C6 CX

45º

45º 0º

02 51

PERIMETER & COVE / MICRO COVE

02 52

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com MicroCove

MICRO COVE 8”8 " 223⁄/

1 " 56” /2

ORDERING MATRIX Series/Style

MC LED

Lamp Rows

LED 3 3000K LO, SO, HO LED 35 3500K LO, SO, HO LED 4 4000K LO, SO, HO LO - Low Output SO - Standard Output HO - High Output

Nominal Length

Color/Finish

Circuiting

02’ 03’ 04’ 06’ 08’ R__ Row Length YGW Gloss White TMW Textured Matte White - Standard Y_ Premium Color CC Custom Color SC Single Circuit

Voltage

UNV 120-277

Options

ND Non-Dimming - Standard DM10 0-10v Dimming DM01 1% Dimming STEP Step Dimming 100-50-off DML 1% Dimming Lutron DMD DALI 1% Dimming EMH* (1000 Lumens) EML* (500 Lumens)

See key on back cover.

Diminutive in scale and huge in performance, the MicroCove is a concealed cove luminaire designed to optimize all the benefits of the LED source. Our FusionOptics creates the MicroCove’s idealized distribution giving the ceiling just the right gradient, while maintaining high efficacies. With fully adjustable and lockable aiming, integral or remote drivers, tunable output and wattages, the MicroCove performs exactly how you expect it and precisely where you need it.

4’ minimum fixture length

45º

45º 0º

02 53

PERIMETER & COVE / P45i

02 54

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

The Sue and Bill Gross Womenâ€™s Pavilion at Hoag Hospital Tel. 213.746.0360 / prulite.com

P45i

ARCHITECT TAYLOR

ORDERING MATRIX Series Lamp Rows

P45i 1T8 2T8 1T5/HO 2T5/HO 1Bx39w (3' and 6' only) 1Bx_w*

P45i 2 3/4" 8

*Biax specify 40w, 50w, 55w Nominal Length

Color/Finish

Circuting

02’ 03’ 04’ 06’ 08’ R__ Row Length TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color SC Single Circuit DC* Dual Circuit (in-line) *2 lamp rows only

Voltage

120 277 347 UNV 120-277

Options

EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC ADC †

See key on back cover.

Our lowest-profile asymmetric indirect cove system, P45i is designed for one or two lamp rows. Explicitly created for concealed cove applications or surface mounted as a finished wall fixture, this luminaire has a formed aluminum specular reflector that throws light forward at a very low angle cutting ceiling brightness above the fixture. A notched back-reflector minimizes socket shadows and illuminates without obstructing aesthetics or design.

45º

*Consult factory for fixture lengths < 4' † Consult factory for restrictions

45º 0º

02 55

PERIMETER & COVE / SUPERCOVE

02 56

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

SuperCove

Gordon James Fine Diamonds

Twist Architecture Design

Kristin Zwiers Photography

SUPERCOVE 3 3/4" 6"

ORDERING MATRIX Series Lamp Rows Nominal Length

SC 1T8 1T5/HO 02’ 03’ 04’ 06’ 08’ R__ Row Length

Voltage

120 277 347 UNV 120-277

Options

PAF EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC

See key on back cover.

*Consult factory for lengths < 4'

A high-performance fluorescent cove luminaire, SuperCove bathes ceilings in an even wash of light with a precisely designed and engineered specular aluminum reflector that throws light at very low angles. A galvanized steel bottom reflector directs and diffuses light on ceilings to eliminate striations while limiting uplight. A diffuse white back-light reflector fills cove cavity with illumination, minimizing socket shadows.

45º

45º 0º

02 57

02 58 CASE STUDY

CASE STUDY

CSUN REC CENTER IN THE LEED Education and excellence shine at the California State University, Northridge Recreation Center. Weighing in at 138,000 square feet and a budget of $70 million, the complex houses activities as diverse as rumba, swimming, floor hockey, rock climbing, volleyball, boxing and yoga. In addition, it features indoor gyms, a weight room, workout studios, an indoor track and two outdoor pools. Opened in Winter 2012, the building has an exterior metal skeleton that contrasts with its striking glass panels, creating a folded profile. Clearly, this facility utilizes all the latest materials and techniques of sustainable design, nothing less than LEED Gold-level certification. In fact, workouts on the exercise machines are being used to “keep the lights on,” transferring the power generated into the university’s electrical grid. Irvine, California-based green planning and design firm LPA has already won many awards for their unique design, including one from the AIA. The lighting designer was Kaitlin LeSage Crawford from STUDIOK1. Because the building uses numerous sustainable features including natural daylight in the usable spaces, photometric calculations were used to determine which Prudential Lighting products to place where. Crawford ultimately chose the Snap, a low-profile architectural wrap and one of the company’s most popular and biggest-selling fixtures. “They [the design team] took the time to educate the students about what we’re building and what we’re trying to create here,” said CSU Northridge University Student Union Executive Director Debra Hammond. Here’s hoping the new recreation center inspires a lot of fit new architecture students coming out of CSUN.

02 59

03 60 ARCH WRAPS

ARCHITECTURAL WRAPS

Not your ordinary back-of-house wrap fixtures, designed to exacting standards with a wraparound acrylic lens and refined enough to be integrated in the architecture of the space.

03 61 Zenith

Snap

HalfSnap

Strand

ARCH WRAPS / ZENITH

03 62

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com Zenith

ORDERING MATRIX Series

Lamp Rows

ZES Square Lens ZER Round Lens ZDS Down; Square ZDR Down; Round

Shielding Color/Finish

Circuiting Voltage

Mounting Ceiling System Options See key on back cover.

1 5/16"

LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1SM/HO Osram Seamless Lamp *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Size

ZENITH

22 2' x 2' 33 3' x 3' 44 4' x 4' SAL Satin Acrylic Lens TMW Textured Matte White YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit 120 277 UNV 120-277 - Only LED Voltage

1 1/2"

A Modern, sophisticated square pendant, the Zenith is an inspired design of geometric shapes and creative illumination. Zenith’s corners are completely illuminated by LED or seamless fluorescent lamps. A revelation in light and design. The fixture elevates a simple strip of light into an architectural monopoint luminaire that floats effortlessly above a space, illuminating an area with an airy, open aesthetic.

MPCA Monopoint Mounting 4PM 4 Point Mounting Plate X1 Exposed T-Bar X3 Hard Ceiling EML*† EMH*† B_* FH * IBC *Not Available with LED †Not Available in 2x2

45º

45º 0º

03 63

ARCH WRAPS / ZENITH

03 64

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com Zenith LPA Inc. San Jose

ARCHITECT

PHOTOGRAPHER

LPA Inc.

Costea Photography

03 65

ARCH WRAPS / SNAP

03 66

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Snap

Alterra

Rapt Studio

ORDERING MATRIX Series Lamp Rows

S1 Square R1 Round LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 1T5/HO 2T5/HO 1SM/HO Seamless Lamp *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Lens/Louver

01' LED Only 02’ 03’ 04’ 06’ 08’ R__ Row Length WA White Acrylic Lens SAL Satin Acrylic Lens LPA* Linear Prismatic Acrylic Optic Lens *R1 Round only

Color/Finish

TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized (Black Endplate)

Voltage

120 277 347 UNV 120-277 - only LED voltage

Mounting

X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid Specify with cable mount only

Options See key on back cover.

SUR* Surface or Wall Mount CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) *Standard

Ceiling System

SNAP

EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC IBC cable mount only TRS OCO* OC2C* 2T5 only-N/A EML or EMH OCDM* T5OPT T5/HO optimized lengths EBCP1G EBCP2G SP

2 3/8 "

Our basic lighting building block, Snap is one of our best-selling fixtures. This perfectly scaled wrap simply snaps quickly, neatly and securely into any small space or design configuration. A sleek slip of a light ideal for illuminating vertical surfaces, Snap’s performance and cost-effectiveness is unparalleled in the industry. S-Occ,™ Prudential’s Control system for small spaces, keeps Snap’s lamps off or dimmed until motion is detected, saving even more energy.

*4’ minimum fixture length LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

03 67

ARCH WRAPS / SNAP

03 68

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Snap

Richardson Apartments

David Baker + Partners Architects

Bruce Damonte Photography

03 69

ARCH WRAPS / HALF SNAP

03 70

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

HalfSnap

CLIENT

ARCHITECT

PHOTOGRAPHER

Monster Energy

H. Hendy Associates

Sherman Takata

03 71

ARCH WRAPS / SNAP

03 72

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com

Snap

TannerHecht Architecture

03 73

ARCH WRAPS / HALFSNAP

03 74

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

HalfSnap

TRIS3CT

Gary Lee Partners

ORDERING MATRIX Series Lamp Rows

HSS Square HSR Round LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 1T5/HO 1SM/HO Osram Seamless Lamp *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Lens/Louvre

02' 03' 04' 06' 08' R__ Row Length WA* White Acrylic Lens SAL Satin Acrylic Lens *N/A LED

Color/Finish

Voltage

Mounting

YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color 120 277 UNV 120-277 only LED voltage

HALFSNAP

13/8"

03 75

SUR* Surface or Wall Mount CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable)

1 1/2"

*Standard - ADA compliant Ceiling System

X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid Specify with cable mount only

Options See key on back cover.

EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** MRK10** B_ FH QC IBC cable mount only EBCP1G EBCP2G C2 unlit OCO SP

HalfSnap, a designer minimalist wrap, is a smaller iteration of the wildly popular Snap. Profoundly flexible, HalfSnap can go anywhere and do anything. It has the same height, crisp lines and versatility of the Snap, but with a narrower and more slender profile. HalfSnap is made in both round and square lenses, and is available in white or satin acrylic lenses with a seamless end plate.

*4’ minimum fixture length **Specify 120 or 277 voltage ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

ARCH WRAPS / STRAND

03 76

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Strand

Commerce House

Perkins + Will

Charles Davis Smith

ORDERING MATRIX Series Body Style

Lamp Rows Nominal Length

Lensing

Housing/ Fascia Color

Socket Cap/ Endplate Color

Mounting

Ceiling System

STRAND NF No Fascia SFP Symmetric Fascia Perforated AFP Asymmetric Fascia Perforated 1T5/HO 02’ 03’ 04’ 06’ 08’ R__ Row Length NS* No Shielding SAL Satin Acrylic Lens WA White Acrylic Lens *only option for AFP YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color SUR* Surface or Wall Mount CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) SMR Semi Recessed into hard ceiling or wall *Standard - ADA compliant X1 X3 X6 X7

Exposed T-Bar Hard Ceiling Slot Grid Hard Ceiling Trimless - SMR only

Specify with cable mount only Voltage

120 277 UNV 120-277

Options

EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** MRK10** B_ FH QC IBC cable mount only EBCP1G EBCP2G

See key on back cover.

*4' minimum fixture length **Specify 120 or 277 voltage

STRAND

13/8"

An elegant ribbon of light, the Strand is a higher-style surface mounted fixture. Strand’s formed steel housing with cast aluminum rounded end caps hides the socket and non-illuminated portion of the lens hugging the lamp within. Energy-wise Strand carries an impressive 95% efficiency rating, and is exceptionally adaptable, with several decorative fascias. Highly configurable with lamping, reflectors, lenses and mounting choices.

45º

45º 0º

03 77

ARCH WRAPS / STRAND

03 78

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Strand

TRIS3CT

Gary Lee Partners

03 79

CASE STUDY

03 80

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

INTERIOR DESIGN

Tel. 213.746.0360 / prulite.com

P43

North Face Headquarters

Rapt Studio

CASE STUDY

THE NORTH FACE The new North Face headquarters is the embodiment of the company’s ethos, passion and commitment to the outdoors. San Francisco-based interior designer Rapt Studio, the designer of the company’s headquarters 11 years ago, was tapped again to imagine an interior space in conceptual harmony with the outdoor retailing giant’s message and culture. Guided by the explicit goals to create a work environment mirroring the company’s dedication to outdoor preservation and environmental responsibility, Rapt Studio created a stunning modern, clean, crisp aesthetic space using natural materials. Ample, open windows allow natural daylight to fill interior spaces. The project had strict LEED Gold standards so Rapt Studio selected Prudential Ltg.’s slender strip of a light, the Strand with a perforated diffuser. “We wanted lighting to be minimal with little or no ornamentation while accommodating several lighting needs,” said the project’s design principal, David Galullo. “The Strand was an easy fit into our LEED objectives, our very tight construction budget and it is appropriate to the design.” Prudential’s P43, a 4" wide recessed, crisp, sleek linear fixture, is also featured in the design. The project is expected to receive a LEED Gold designation. The North Face headquarters, a subsidiary of VF Corporation, is situated on VF Outdoor Campus headquarters’ 14-acre campus in Alameda along with JanSport and Lucy. The campus generates 100 percent of its anticipated electricity needs via wind turbines and solar panels and features electric car charging stations. Rapt Studio designed all 160,000 sq. feet of the campus’s interior space.

03 81

04 82 RECESSED LINEAR

RECESSED LINEAR

Continuous luminous channels, lines of light, with patented optic and energy controls make these fixtures as efficient as they are technologically progressive.

04 83 Bionic

P43

P62

100

P42

P63

102

RECESSED LINEAR

04 84

FusionOptics™

MR16 - 363º Control

No Socket Shadows

Bionic showcases a patent pending technology, FusionOptics, the result of inspired thinking, design and relentless engineering. The secret? Refractors and reflectors designed to work together far better than they ever have alone. Never before have lighting designers and architects been offered this much control with this much energy efficiency.

The Bionic Modular System is designed to provide optimal MR16 control by featuring 30º aperture-centered tilt and 363ºrotation for no blind spots. With positive locking on both rotation and tilt, a lens locking ring holds up to three lens mediums—which means that designers can make precise settings and know they are permanent regardless of lamp changes.

Our high-efficiency T5 seamless lamps unveil light elegantly and without socket shadows. Seamless also forms the foundation upon which Prudential built our proprietary FusionOptics. In concert with the Bionic Modular System, seamless lamps provide an economical option requiring spotless, even illumination.

BIONIC - BETTER, STRONGER, FASTER Bionic™ is the organic, continuous channel lighting solution that adapts to its surroundings. Ideal for large scale projects that demand flexibility of installation, precision in lighting, energy efficiencies, and cost savings. Bionic is both a functional and aesthetic wonder. Universally adaptable: with a patent on constructability the bionic modular system arrives at the job site ready to install right away, whether the ceiling is up or not. The Bionic system also corrects for different ceiling thicknesses and material variations and is compatible with Armstrong’s Techzone™ ceiling systems.

45º

Batwing Throws light wide then cuts off sharply at 65˚ without losing any efficiency. Allows for wider on center spacing, saving energy and reducing installation costs.

0º

45º

Ideal vertical light distribution along a wall from two to three feet away with no harsh cut off shadows, no below ceiling mechanical kickers and an appreciable amount of back light.

0º

45º

Wall Wash

45º

Wall Graze

0º

Offers flush or regressed lensing with even vertical illumination for seamless wall-grazing effects. Dramatic control without sacrificing energy efficiency.

04 85

RECESSED LINEAR / BIONIC

04 86

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Bionic

IBM

HOK

04 87

RECESSED LINEAR / BIONIC

04 88

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com Bionic Kirkland and Ellis LLP

ARCHITECT

PHOTOGRAPHER

Studios Architectue

Jasper Sanidad

ORDERING MATRIX Series

Body Style Lamp Rows

BIO-LED - LED BIO-STD - Standard Lamping BIO-STG - Staggered BIO-SM - Seamless Lamp FLSH Flush Lens REG 1" Regressed Lens LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K STD: 1T8, 2T8, 1T5/HO STG: 1T8, 1T5/HO, 2T5/HO SM: 1SM/HO - Osram Seamless T5 Lamp *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

Color/Finish

Distribution

Circuiting Voltage

Ceiling System

Options See key on back cover.

LED Options

02’ 03’ 04’ 06’ 08’ R__ Row Length STD only available up to 8’ SAL Satin Acrylic Lens SPL Silver Parabolic Louver ABW* - Acrylic Batwing Lens *D1X Distribution only TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color Note: Indicates color of flange trim D1 Direct D1X*Symmetric Extended Performance *N/A STG

BIONIC

5 7/16"

SC Single Circuit DC Dual Circuit - STD 2 Lamp only 120 277 347 N/A with MR16s UNV 120-277 - Only LED Voltage X1* Exposed T-Bar 15/16" X1m* Exposed T-Bar 9/16" X2* Dimensional T-Bar Armstrong Interlude® X3 Hard Ceiling (flange trim) X6* Slot Grid X7BF Hard Ceiling Trimless (mud-over backer flange) M Mixed Ceiling (contact factory) *Techzone™ compatible EML 4' minimum fixture length EMH 4' minimum fixture length DM RSE T8 only 10THD T8 only B_ FH QC M1, M2, M4 MR16, LED MR16 C2 90º Corner C3 T-Connector, not lit C4 90°4-Way CX Custom Connector C8 Wall to Ceiling Connector ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

4 1/16" Slots Staggered Flush Mud in X7

Bionic is among our most inventive and innovative luminaires for large scale Class A spaces. Bionic is a highly configurable continuous modular channel lighting system with our superior ground-breaking FusionOptics,™ where lamp, lensing and reflectors are engineered to produce unmatched lighting performance and to maximize energy efficiency. Bionic’s universal housing provides faster and simpler installations with multiple different snap-in ceiling trims. >

See the reference fixtures on pages 39, 111.

45º

45º 0º

04 89

RECESSED LINEAR / BIONIC

04 90

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com Bionic Walgreens

ARCHITECT JPC Architects

Let the nature of your space shine.

Bionic is seamlessly integrated

bionic

Behold the beauty of optically advanced, recessed simplicity. Bionic is Prudentialâ€™s all new, adaptable, precise, continuous channel linear slot system that can bend around corners and integrate into any environment. Beauty belies the brilliance that lurks within. We push energy efficiency higher, make the complex easy to install, and offer a design flexibility that allows you to simply shine. Learn more at prulite.com/bionic. Light creates Life. Create with Prudential Ltg.

Ad campaign featured in Architectural Record and Snap magazine launching the Bionic System.

RECESSED LINEAR / P42

04 92

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com P42 Hanover Park Police Dewberry Architects Headquarters

PHOTOGRAPHER Mariusz Mizera Photography

ORDERING MATRIX Series

Lamp Rows

P42 LED P42 STD P42 STG LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K STD: 1T8, 2T8, 1T5/HO, 2T5/HO STG: 1T8, 1T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

Frame Style/Color

Circuiting

Voltage

Ceiling System

Options See key on back cover.

02’ 03’ 04’ 06’ 08’ R__ Row Length STG only available for 6’ rows or longer Note: STG Row length in 4' increments only WA Frost White Acrylic Diffuser PRA* Prismatic Acrylic Lens LPA* Optiglow™ Linear Prismatic Lens *N/A LED

P42

JW Smooth Frame White - Standard JB Smoothe Frame Black KW Striated Frame White KB Striated Black Frame Note: Fixture body flange finished in gloss white on mounting style X3B SC Single Circuit DC* Dual Circuit (in-line) - 2 Lamp only *N/A STG or LED 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) CR N/A STG EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC INTCW C2 90° Corner CX Custom Connector

4 3/4 " 1 1/2 " 3 5/16 " 5 1/4 "

A 4" wide recessed luminaire with a 1 1/⁄2" splay regress for T-bar or hard ceilings, P42 is a seamless urbane linear fixture with an option for a discreet overlapping flange or trimless style. It comes with an LED option for a smooth continuous light along the lens or staggered lamping to eliminate socket shadows. Choose a striated or smooth-mitered aluminum doorframe.

See the reference fixtures on pages 151, 157.

*4’ minimum length LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

04 93

RECESSED LINEAR / P43

04 94

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P43

ORDERING MATRIX Series

Lamp Rows

P43 LED P43 STD P43 STG LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K STD: 1T8, 2T8, 1T5/HO, 2T5/HO STG: 1T8, 1T5/HO *LO-Low, SO-Standard, HO- High (Output) - see Options for Dimming

Nominal Length

02’ 03’ 04’ 06’ 08’ R__ Row Length STG Only available for 6’ rows or longer

Shielding

SAL Satin Acrylic Extruded Lens OPL Opal Frost Acrylic Lens PRA* Prismatic Acrylic Extruded Lens SPL† Silver Parabolic Louver BLA† Blade Louver-Anodized BLW† Blade Louver White *N/A LED †Acrylic overlay masks LED's

Color/Finish

TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color Note: Indicates Color of Flange -X1 and X3B Ceiling Systems only

Distribution Circuiting

Voltage

Ceiling System

Options See key on back cover.

P43

D1 Direct SC Single Circuit DC* Dual Circuit (in-line) - 2 Lamp only *N/A STG or LED 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) CR N/A STG EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC INTCW C2 90° Corner CX Custom Connector

A 4" wide recessed luminaire for both ceilings and walls, P43 mounts flush to the ceiling plane creating a crisp, sleek line of light. Powerful enough to illuminate ambient space, P43 fits nearly anywhere. This fundamental luminaire comes in either a 1/⁄2" overlapping flange or a trimless style. LED lamping gives smooth even light along the entire length of lens, or a 1-lamp diagonal staggered fluorescent option for a traditional continuous line of light detail. >

See the reference fixture on page 41, 115.

*4’ minimum length LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

04 95

RECESSED LINEAR / P43

04 96

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P43

Mercedes Benz

Interior Architects

04 97

TECHNOLOGY EON 2 LED

TECHNOLOGY

04 98

There will always be something magical about incandescent light, and fluorescent lamps remain a viable solution for many uses. But after decades of development, the promise of LED lighting is at last being realized. It’s now possible for LEDs to deliver long life and energy savings along with high-levels of lighting control. But not all LED fixtures are created equal—there are significant differences. Here are some of the ways Prudential Ltg’s LED technology, EON™, ensures the highest quality and performance in the industry for the ages. Watch for this symbol representing fixtures that utilize the LED source

04 99

EON FOR THE AGES — ADVANCING LED OPTIONS FOR SUPERIOR PERFORMANCE PRUBIN: Testing every module individually, in our integrating sphere, for brightness, color and hue within an industry best 2-step MacAdam elipse. Going then beyond the elipse to guarantee brightness consistency and delivery of only .004 DUV ensures your job looks perfect every time.

State of the Art: Prudential only uses brand name, top quality LEDs and components, rapidy changing and upgrading as soon as higher performing components become available.

TuneAbility: Prudential Ltg’s EON fixtures offer

Built to Last: We design our LED systems with longevity in mind. So low operating temperatures, good thermal management, and low drive currents allow our LED systems to endure well past standard 50,000hrs (L70), even at High Output settings.

the standard levels. Allocating just the right

multiple output levels, standard. Designers also have the freedom to specify customized outputs and wattages anywhere in between amount of light—no more, no less—that an application requires helps conserve energy. And that’s what we call good stewardship.

RECESSED LINEAR / P62

04 100

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P62 School of Mines

ARCHITECT

PHOTOGRAPHER

Oz Architecture

nic lehoux photography

ORDERING MATRIX Series

P62

Lamp Rows

1T8 2T8

Nominal Length

Color/Finish

Frame Style/Color Curcuiting

02’ 03’ 04’ 06’ 08’ R__ Row Length PRA Prismatic Acrylic Lens WA White Acrylic Diffuser LPA Optiglow™ Linear Prismatic Lens JW Smooth Frame White - Standard JB Smooth Frame Black SC Single Circuit DC* Dual Circuit (in-line) *2T8 only

Voltage

Ceiling System

Options See key on back cover.

120 277 347 UNV 120-277 X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim: overhead mounting brackets) X4B Hard Ceiling (flange trim: "C" channel) CR EML* EMH* DM RSE 10THD B_ FH QC *Consult Factory for Fixture Lengths < 4'

P62

5 3/4 " 6 1/2"

*Consult Factory

A narrow recessed luminaire with a 2" smooth splay regress, P62 can be installed as a individual luminaire or in continuous rows. An understated simple fixture ideal for illuminating open offices, retail, healthcare and schools that is designed to fit a variety of different ceiling types. P62 comes with an option for three different shielding materials-clear prismatic acrylic lens, white acrylic diffuser and Optiglow™ linear striated prismatic lens. >

See the reference fixtures on pages 41, 115.

45º

45º 0º

04 101

RECESSED LINEAR / P63

04 102

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com P63 McCarran International Airport

ARCHITECT

PHOTOGRAPHER

PGAL Dana Jeffery Hoff

ORDERING MATRIX Series Lamp Rows

Nominal Length

Color/Finish

Curcuiting Voltage

Ceiling System

Options See key on back cover.

P63 1T8 2T8 1T5/HO 2T5/HO 02’ 03’ 04’ 06’ 08’ R__ Row Length PRA Prismatic Acrylic Lens WA White Acrylic Diffuser SAL Satin Acrylic Lens SPL Silver Parabolic Louver (11/2" high by 23/8" O.C.) BLA Blade Louver-Anodized (1" high by 1" O.C.) BLW Blade Louver-White (1" high by 1" O.C.) SC Single Circuit DC Dual Circuit (in-line) - 2T8 only 120 277 347 UNV 120-277 X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim: overhead mounting brackets) X4B Hard Ceiling (flange trim: "C" channel) CR EML* EMH* DM RSE† 10THD† B_ FH QC INTCW *Consult Factory for Fixture Lengths < 4' †T8 only

P63

6 1/2"

* 1X 5 - 3/64-"P 3

*Consult Factory

A narrow, modular 6" recessed luminaire, P63 is a continuous linear luminaire with an array of lens and louver shielding options including semi-specular parabolic, mini-cube and blade louvers. Comes with clear frost and white acrylic lenses. When mounted in rows, P63 appears as a continuous line of light (CR option). This luminaire works well in large public spaces that require an abundance of light, like offices, health care facilities, schools and corridors. >

See the reference fixtures on pages 41, 115.

45º

45º 0º

04 103

CASE STUDY

04 104

CONTACT PRUDENTIAL LTG.

FIXTUREw

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Strand

TRIS3CT

Gary Lee Partners

CASE STUDY

USC’S ALL-SPORTS BUILDING: JOHN MCKAY CENTER Named for USC’s legendary football coach and unveiled in August 2012, USC’s new McKay Center is a breathtaking $70 million, 110,000 square-foot, self-contained state-of-the-art facility. The explicit mission of Los Angeles-based RA-DA was to design the McKay Center’s interiors as a clean, modern complement to the exterior’s collegiateRomanesque Revival architecture. The interior space had to communicate USC’s rich history athletically and academically while meeting the practical purpose of serving and supporting the needs of the school’s 600 student-athletes competing in 21 sports. “Despite its regal qualities, we wanted the spaces and interiors of the McKay Center to be somehow youthful and energetic,” said Rania Alomar, principal at RA-DA in charge of the John McKay Center’s interior design. The basement is the Center’s biggest floor at 60,000-square feet, housing a 40-yard-by-30-yard turf field, the football locker rooms, a nutrition center, hydrotherapy pools and an expanded sports performance and recovery area. Alomar wanted the light to speak the language of athletes, trainers and coaches, effectively communicating the feel of high-powered sport and physicality: vibrant, energetic and dynamic. In the corridors leading into the strength and conditioning training area on the lower level, RA-DA placed Prudential Ltg.’s P62, creating repeating lines of light.

04 105

“We used the P62 in this staccato manner, marching down the corridors, sort of going boom, boom, boom, down it,” said Alomar, who added that she used the P63 in other parts of the interior. “It creates this punctuated rhythm of light down the corridors. We use them in this graphic way. We are not glorifying the fixture. We are integrating the light into the design. It is part of the design. The light contributes to it.”

CASE STUDY

Alomar found the linear P62 ideal for this purpose.

04 106

“These are really simple fixtures that achieve exactly what we wanted…this continuous line of light. It’s not the fixture that is getting all the attention, it’s the light.”

“...regal…yet youthful and energetic” Lack of ambient light was Alomar’s greatest challenge. “We did not want it to feel like a basement,” says Alomar, who used the P59, Prudential’s Ltg.’s versatile cove fixture in all the Center’s restrooms and in the basement shower rooms. “We used a lot of the P59 light coves. It is a great fixture because it achieves what you want in a light cove which is: it throws the light really even down onto the surface and it is not visible to the eye. Wherever appropriate, we used indirect lighting and coves to add a general sense of lightness without visible fixtures, raising the overall ambient light in the space.” The McKay Center’s ground floor is dedicated entirely to academic services including computer labs. Los Angeles-based project architect HTNB selected Prudential Ltg.’s P63 for the labs. The narrow, modular recessed P63 served the dual purposes of design continuity and function in the lab where computer screens require an even light for visual comfort.

04 107

05 108 WALL WASH & STACK

WALL WASH & STACK

Wall Wash lighting provides an asymmetric layer of beautiful light to vertical surfaces adding drama and defining a space. Stack lights send light into hardto-reach places like library stacks and retail shelves.

05 109 Bionic

110

P43

114

Aparia

118

Snap

P5600

120

116

WALL WASH & STACK / BIONIC

05 110

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Bionic

ORDERING MATRIX Series Style Lamp Rows

BIO-LED BIO-STD FLSH Flush Lens LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 1T5/HO *LO-Low O, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

Trim Color*

02’ 03’ 04’ 06’ 08’ R__ Row Length AWW Acrylic Wall Wash Lens Fluorescent only AWL Acrylic Wall Wash LED TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color *Indicates color of flange trim

Distribution Circuiting Voltage

Ceiling System

See key on back cover.

5 7/16"

D1W Asymmetric to Wall (Wall Wash) SC Single Circuit 120 277 347 N/A with MR16 UNV 120-277 - Only LED Voltage X1* Exposed T-Bar 15/16" X1m* Exposed T-Bar 9/16" X2* Dimensional T-Bar Armstrong Interlude® X3 Hard Ceiling (flange trim) X6* Slot Grid X7BF Hard Ceiling Trimless (mud-over backer flange) *Techzone™ 6" compatible (4" lens)

Options

BIONIC

EML* EMH* DM RSE N/A T5 10THD N/A T5 B_ FH QC M1 12" MR16 Module 1/50w lamp M2 12" MR16 Module 2/50w lamp MD SORAA LED 12" MR16 Module (adj) 12w C2 90° 2-way corner w/acrylic lens

4 1/16"

A premium-grade 4" modular or continuous, extruded aluminum wall wash luminaire with a sealed snap in flush lens. Our FusionOptics™ integrated reflector-refractor design offers a performance wall wash optic for superior efficiency and distribution control that eliminates unsightly drop down kicker reflectors. Bionic delivers a beautiful gradient of light on the wall from the ceiling to floor using LED or fluorescent light sources. Look to Bionic for seamless continuity to light the whole space. >

See the reference fixtures on pages 39, 89.

*Consult factory LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

05 111

FUSION OPTICS™

FUSION OPTICS

Our patent pending innovation wherein every luminaire is individually designed to optimize lighting control. Refractive lens and reflector system work in harmony providing more control than ever before without any efficiency losses. Every ray from the lamp, or LED, every bounce from the reflector and every prism in the lens has been meticulously integrated to achieve a remarkable combination of efficient and controlled light.

05 112

Material Science Advancement in material science fuels Fusion Optics’ performance. Materials up to 99% reflective combine with the latest in acrylic resin chemistry and breakthroughs in manufacturing tolerance to give designers the most advanced products available.

Watch for this symbol representing fixtures that utilize Fusion Optics.

Sustainable Design Whether it is lighting a Picasso or an open office plan, it’s all about putting the correct amount of light where it’s needed, with increased visual comfort and reduced energy use. With Fusion Optic’s precision control and available customized outputs and wattages, designers can tune our fixtures to the right amount of energy and light each application requires. And isn’t that sort of precision you expect from Prudential Ltg?

05 113

WALL WASH & STACK / P43

05 114

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P43

ORDERING MATRIX Series Style Lamp Rows

P43-LED P43-STD FLSH Flush Lens LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 1T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

Trim Color*

02’ 03’ 04’ 06’ 08’ R__ Row Length

Circuiting Voltage

Ceiling System

Options See key on back cover.

LED Options

5" 5"

AWW Acrylic Wall Wash Lens Fluorescent only AWL Acrylic Wall Wash LED TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color *Indicates color of flange trim

Distribution

P43

D1W Asymmetric to Wall (Wall Wash) SC Single Circuit 120 277 347 N/A with MR16 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange)

4" 4"

Our 4" recessed linear steel constructed modular or continuous luminaire for T-bar or hard ceilings delivers a crisp, even light that offers wall wash optics for superior efficiency and distribution control. Lens is flush with the finish plate and trims for a clean, minimal look with drywall applications. The P43 will deliver a beautiful gradient of light on the wall from the ceiling to the floor using LED or fluorescent light sources. P43 is ideal for complex fast track projects.

EML Consult factory EMH Consult factory DM RSE T8 Only 10THD T8 Only B_ FH QC ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

05 115

WALL WASH & STACK / SNAP

05 116

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Snap

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding Color/Finish

Voltage

Mounting

Ceiling System*

Options See key on back cover.

R1 Round LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 1T5/HO 1SM/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming 02’ 03’ 04’ 06’ 08’ R__ Row Length LPA Linear Prismatic Acrylic Lens TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color

SNAP

3 1/8 "

05 117

120 277 347 UNV 120-277 - only LED voltage CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) SUR Surface or Wall Mount - Standard X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid *Specify with cable mount only EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC IBC TRS OCO OCDM* T5OPT T5/HO optimized lengths EBCP1G EBCP2G *

LED Options

2 3/8 "

The wildly versatile Snap luminaire transforms itself into an ideal stack light through the addition of a precisely engineered refractor designed to illuminate a flawless vertical surface. Snap is ideal for library stacks, retail applications, or corridor spaces. Available in LED, T8, T5, T5HO or T5 Seamless. Optional S-OccTM occupancy sensor system optimizes energy efficiency.

4’ minimum fixture length

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

WALL WASH & STACK / APARIA

05 118

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Aparia

Idyllwild Library

HMC Architects

ORDERING MATRIX Series

APA-TRO

Body Style

SD Solid HSL Horizontal Slots

Distibution

STK Stack Distibution

Color/Finish

Lamp Rows Nominal Length

TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized Steel 1T8 1T5/HO 04’ 08’ R__ Row Length

Cast Plate/ Rail Louver Finish

TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color

Flat Endplate Finish

TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color BAL Brushed Aluminum GLV Galvanized

Circuiting Voltage

Mounting

Ceiling System Options See key on back cover.

SC Single Circuit 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable)

APARIA 6 1/8"

As practical as it is stylish, Aparia’s exacting light distribution is ideal for illuminating library stacks and retail shelves with its optimal stack-light distribution. This luminiare is available in an array of colors and metal finishes appropriate to any design aesthetic or architectural sensibility. Specify Aparia Throw version, APR-TRO with STK distribution with your choice of side panel finish for optimal stack lighting performance. >

See the reference fixture on page 171.

X1 Exposed T-Bar - Standard X3 Hard Ceiling EML* EMH* DM RSE T8 only 10THD T8 only B_ QC IBC *4' Minimum Fixture length

45º

45º 0º

05 119

WALL WASH & STACK / P5600

05 120

CONTACT CLIENT ARCHITECT CONTACT PRUDENTIAL PRUDENTIAL LTG. LTG. FIXTURE FIXTURE Tel. Tel. 213.746.0360 213.746.0360 // prulite.com prulite.com P5600

SuperCove

TRIS3CT

Gary Lee Partners

ORDERING MATRIX Series Body Style Lamp Rows Nominal Length

Color/Finish

Voltage

Mounting

Ceiling System

Options See key on back cover.

P5600 SD Solid Louver - Standard P Perforated Louver 1T8 1T5/HO 02’ 03’ 04’ 06’ 08’ R__ Row Length TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC Top-Swivel Stem Mount (specify length in inches) SUR Surface or Wall Mount X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Hard Ceiling

P5600

3 1/2"

3 5/8 "

Perfectly designed to light vertical surfaces, P5600 is a slim 3 1/⁄2" wide stack light with a solid or perforated radial blade louver for use with 1T8, 1T5 or 1T5H0 lamp configurations. Louver blades are spaced 1 1/⁄2" on center, shielding glare from the lamp in the along direction while providing a wide distribution. Also available with daylight harvesting sensors, dimming light in accordance to available light and desired lighting levels.

EML* EMH* DM RSE† 10THD† B_ FH QC IBC BSH _DLH** 45º

*4’ Minimum Fixture Length † T8 only **Consult factory, 1T5/HD only

45º 0º

05 121

06 122 RECESSED

Recessed luminaires, by design, merge into the ceilings and walls they are mounted in. Understated, these fixtures integrate and accentuate design and architectural aesthetics.

RECESSED

06 123 P9000

124

P8900

126

Cupola1N/1W

132

Cupola2i

134

MiniCupola

138

Wing11/14

128

Wing22/24

130

Cupola4i

136

P8600

142

Quick Find on the web, search P0107.

P9200

140

RECESSED / P9000

06 124

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com P9000

CLIENT

ARCHITECT

Julian Street Library, Joel Sanders Architect Princeton University

ORDERING MATRIX Series

Lamp Rows

P9012 P9018 P9020 P9030 P9040

12" diam. 18" diam. 2' diam. 3' diam. 4' diam.

P9000 7 1/2 " 8 1/4 "

LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming †

Shielding Color/Finish

Circuiting Voltage

Ceiling System

Options See key on back cover.

11 1/4 ", 17 1/4 ", 22 1/4 ", 34 1/4 ",

Designed with a refined aesthetic, P9000 is a slimmer iteration of P8900, scaled back to a minimal doorframe trim and co-planar lens that is flush to the ceiling surface. A trimless option is also available for hard ceilings. P9000 has a drop lens option (DNA) for a ‘playful’ ceiling texture. Fixture is available in LED or fluorescent lamping. P9000 is a beautiful circle of light for a streamlined, modern architectural luminescence.

EML EMH* 10THD N/A 9018 B_ Specify Requirements DM Specify Requirements, N/A 9018 FH RSE T8 & Biax only - N/A in 9018 *4’ minimum length *Consult Factory

LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

06 125

RECESSED / P8900

06 126

CONTACT PRUDENTIAL CONTACT PRUDENTIAL LTG. LTG.

FIXTURE FIXTURE

CLIENT CLIENT

Tel. 213.746.0360 / prulite.com Tel. 213.746.0360 / prulite.com

P8900 P 8900

LA High School Rapt Studio Quatro Design Group Rapt StudioCentral HQ

ARCHITECT ARCHITECT

PHOTOGRAPHER

Paul Turang Photography

ORDERING MATRIX Series

Lamp Rows

P8912 P8920 P8930 P8940 P8950 P8960

12" diam. 2' diam. 3' diam. 4' diam. 5' diam. 6' diam.

LED3 LO, SO, HO † 3000K LED35 LO, SO, HO † 3500K LED4 LO, SO, HO † 4000K P8912 2CFL_w - 26w, 32w, 42w 2Bx18w P8920 (2) T8, T8U6 2Bx_w*, 3Bx_w*, 4Bx_w* P8930 (4) T8, T5/HO, (6) T8, T5/HO P8940 (6) T8, T5/HO, (8) T8, T5/HO P8950 (8) T8, T5/HO , (10) T8, T5/HO, (12) T8, T5/HO P8960 (6) T8, T5/HO, (8) T8, T5/HO (112) T8, T5/HO *Specify 39w, 40w, 50w, 55w LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming †

Shielding

Color/Finish

Voltage

Ceiling System

Options See key on back cover.

11 3/4"

Circuiting

P8900

SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar X1T T-Bar Ceiling w/Tegular panels X3B Hard Ceiling (flange trim)

60" or 72"

A definitive architectural classic, SkyOculus P8900 is a 40-year standard bearer of quality and aesthetic style. Available in a wide range of diameters from 12" to 6’ and lenses, concave, convex and flat, P8900 is a timeless beauty and a conceptual lighting element to embellish any design. This is the ideal fixture for large public buildings like spacious offices, courthouses, retail, schools and museums.

EML* EMH* 10THD T8 only B_ Specify Requirements DM Specify Requirements, N/A 8918 FH RSE T8 & Biax only - N/A 8918 *Consult Factory

LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

06 127

RECESSED / WING11/14

06 128

CONTACT FIXTURE CLIENT ARCHITECT CONTACT PRUDENTIAL PRUDENTIAL LTG. LTG. FIXTURE Tel. Tel. 213.746.0360 213.746.0360 // prulite.com prulite.com WING11

SuperCove

TRIS3CT

Gary Lee Partners

ORDERING MATRIX Series/Body Style Lamp Rows

WING 11 1' x 1' WING 14 1' x 4' LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1BX18w, 1T8, 2T8, 3T8, 1T5/HO, 2T5HO, 3T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Shielding Frame/Color

Circuiting Voltage

Ceiling System

ABW Acrylic Batwing TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color SC Single Circuit DC Single Circuit - N/A LED 120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar 15/16" X1M Exposed T-Bar 9/16" X2 Dimensional T-Bar Armstrong Interlude® X3B Hard Ceiling (flange trim) X6 Slot Grid Note: T-bar and hard ceiling trims are not interchangeable in the field

Options See key on back cover.

LED Options

WING11/14

AM B_ CH Consult Factory DLH DM EML EMH FH MR PAF ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

4 3/4 " 11 3/8 "

A technologically advanced recessed luminaire, stylish Wing has a clean, simple single-piece doorframe with retro-inspired corners. The precisely engineered singlepiece lens delivers a soft light directly below fixture and a wide batwing distribution with a sharp cut-off at 650 to avoid high angle glare. Our patented Fusion Optics™ allows wider spacing between fixtures lowering costs for installation and energy while meeting criteria for sustainable buildings.

45º

45º 0º

06 129

RECESSED / WING22/24

06 130

CLIENT ARCHITECT CONTACT PRUDENTIAL LTG. FIXTURE FIXTURE Tel. 213.746.0360 / prulite.com Wing24

SuperCove

TRIS3CT

Gary Lee Partners

ORDERING MATRIX Series/Body Style Lamp Rows

WING 22 2' x 2' WING 24 2' x 4' LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1Bx40w, 1Bx50w, 1T8, 2T8, 3T8, 1T5/HO, 2T5HO, 3T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Shielding Frame/Color

Circuiting

ABW Acrylic Batwing TMW Textured Matte White -Standard YGW Gloss White Y_ Premium Color CC Custom Color

Ceiling System

120 277 347 UNV 120-277 - Only LED Voltage X1 Exposed T-Bar 15/16" X1M Exposed T-Bar 9/16" X2 Dimensional T-Bar Armstrong Interlude® X3B Hard Ceiling (flange trim) X6 Slot Grid Note: T-bar and hard ceiling trims are not interchangeable in the field

Options See key on back cover.

LED Options

4 3/4 " 23 3/8 "

SC Single Circuit DC* Single Circuit - N/A LED *2 or 3 lamp option only

Voltage

WING22/24

Stylish and technically advanced, Wing is a recessed luminaire using our patented FusionOptics™ technology. This precisely engineered lens achieves over 80% efficiency and a batwing distribution that allows wider spacing between fixture rows to optimize energy savings. Ultimately lowering cost for installation and energy while meeting criteria for LEED Certified initiatives. Available in LED, or T8, T5, T5HO and biax lamps with Daylight harvesting controls for the fluorescent versions.

AM B_ CH Consult Factory DLH DM EML EMH FH MR PAF ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

06 131

RECESSED / CUPOLA1N/1W

06 132

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Cupola1W

GKK Works

Lawrence Anderson

ORDERING MATRIX Series Body Style

1N Lamp Rows

1W Lamp Rows

CUP1N (41/2" wide center-mount diffuser) CUP1W (9" wide center-mount diffuser) 14 1' x 4' 1N Only 22 2' x 2' 24 2' x 4' 2T8* 3T8* 2T5/HO 3T5/HO 2BX_w† 2T8* 2T5/HO 1BX_w† *Continuous Row Mounting not available †Biax, Specify 40w, 50w or 55w, 22 Style only

1N Diffuser Style Shielding Bezel Finish

Voltage

Ceiling System

Options See key on back cover.

R Rounded Diffuser S Squared Diffuser - WFA Only WFA White Frost Acrylic P Perforated - Round Diffuser Only YGW Gloss White TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color 120 277 347 T8 & T5HO Only UNV 120-277

CUPOLA1N/1W *

5" 23 3/4 "

*Consult Factory

Two contemporary direct/indirect recessed luminaires with a 4 1/2"”wide or 9"” wide center-mounted white frost acrylic diffuser held in place by extruded aluminum bezels painted white or a contrasting color. Available in round or square styles. Fixture is up to 80% efficient when using a frosted acrylic diffuser. Between the two fixture designs, accommodates eight lamping configurations.

X1 Exposed T-Bar X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML EMH DM RSE* 10THD* B_ FH ADS DLH Squared Fascia only *T8 & Biax only

45º

45º 0º

06 133

RECESSED / CUPOLA2i

06 134

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Cupola2i

ORDERING MATRIX Series Body Style

Lamp Rows

CUP2i 14 1' x 4' -Asymmetric Mounted Fascia 22 2' x 2' 24 2' x 4' 1 x 4 2T8*, 2T5/HO 2 x 2 2T8*, 4T8*, 2T5/HO 4T5/HO, 2BX_w† 2 x 4 2T8*, 4T8*, 2T5/HO, 4T5/HO, 2BX_w† *N/A with Continuous Row Mounting †Biax, Specify 40w, 50w or 55w, N/A 2x4

Diffuser Style

R Rounded Diffuser S Squared Diffuser - WFA only

Shielding

WFA White Frost Acrylic P Perforated Round Diffuser

Bezel/Finish

TMW Textured Matte White YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color

Voltage

Ceiling System

Options See key on back cover.

120 277 347 T8 & T5HO only UNV 120-277

CUPOLA2i *

6" 23 /4 " 3

*Consult Factory

An iteration of our classic Cupola, Cupola2i is a 2-sided 2’ x 2’ or 2’ x 4’ recessed direct/indirect luminaire. A sleek, modern fixture that works well in open and private offices, meeting rooms, retail space and schools, Cupola 2i is available with side-mounted frost white acrylic or perforated steel diffusers. With 78% efficiency, Cupola 2i helps meet LEED criteria for Green building standards. Accommodates up to 4/T8, T5, T5H0 or Biax lamp configurations.

X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML EMH DM RSE* 10THD* B_ FH DLH *T8 & Biax only

45º

45º 0º

06 135

RECESSED / CUPOLA4i

06 136

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Cupola4i

CUPOLA4i ORDERING MATRIX Series Body Style Lamp Rows

Shielding Bezel/Finish

Voltage

Ceiling System

Options See key on back cover.

CUP4i 22 2' x 2' 44 4' x 4' 4T8 4T5/HO 4BX55w 4' x 4' NA WFA White Frost Acrylic P Perforated TMW Textured Matte White YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color 120 277 347 T8 & T5HO only UNV 120-277

6" 23 /4 " 3

*Consult Factory

Our Cupola4i is a four-sided recessed direct/indirect luminaire engineered to enhance performance and efficiency. Our Cupola4i features a frost white acrylic to handle both high transmittance and lamp obscuration. Held in place with cast aluminum corner bezels that can be painted to match or contrast diffusers. Ideal for open or private offices, meeting rooms, retail and schools. Install in suspended T-bar ceilings or hard ceiling systems.

X1 Exposed T-Bar - Standard X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) EML EMH DM RSE* 10THD* B_ FH DLH *T8 & Biax only

45ยบ

45ยบ 0ยบ

06 137

RECESSED / MINI CUPOLA

06 138

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

MiniCupola

MINI CUPOLA *

4 1/2 " 11 /16 " 3

*Consult Factory

ORDERING MATRIX Series Lamping Body Style Diffuser Style Shielding Bezel Finish

Voltage

Ceiling System

Options See key on back cover.

Mini C 1' x 1' Recessed Housing 1BX18w CMD Symmetric Center Mounted Diffuser SMD Asymmetric Center Mounted Diffuser R Rounded S Squared WFA White Frost Acrylic P Perforated - Round Diffuser Only TMW Textured Matte White - Standard YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color

A squared contemporary recessed luminaire, MiniCupola is a small semi-direct luminaire with a modern diffuser style. Center-mounted or single side-mounted diffuser comes in perforated steel or white frost acrylic, attached with extruded aluminum bezels that can be painted in contrasting or matching colors. Trimless look is available for drywall ceiling installations. Housing is 1’ x 1’ recessed with 1/18w Biax lamp.

120 277 347 X1 Exposed T-Bar (cut-in ceiling tile) X3B Hard Ceiling (flange trim) X7 Hard Ceiling Trimless (concealed flange) FH DLH* Right Light™ daylight harvesting

45º

45º 0º

*Squared fascia style only

06 139

RECESSED / P9200

06 140

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P9200

The Sue and Bill Gross Womenâ€™s Pavilion at Hoag Hospital

TAYLOR

ORDERING MATRIX Series

Lamp Rows

P9204 6" x 4' P9214 1' x 4' P9222 2' x 2' P9224 2' x 4' P9233 3' x 3' P9244S 4' x 4' x 61/4" housing P9244D 4' x 4' x 8" housing - Standard LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 6" x 4’ 1T8, IT5/HO 1’ x 4’ 2T8, 3T8, 2T5/HO, 3T5/HO, 2BX_w† 2’ x 2’ 2T8, 3T8, 4T8, 2T5/HO 3T5/HO, 4T5/HO, 2BX_w† 2’ x 4’ 2T8, 3T8, 4T8, 6T8, 2T5/HO, 3T5/HO, 4T5/HO 6T5/HO, 4BX_w† 3’ x 3’ 4T8, 6T8, 4T5/HO, 6T5/HO 4 x 4’ 4T8, 6T8, 8T8, 4T5/HO, 6T5/HO 8T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming †Biax specify 40w, 50w, or 55w

Shielding

Frame Style/Color

PRA Prismatic Acrylic Lens- Standard P19A Prismatic Acrylic Lens, Pattern19 WA White Acrylic Diffuser

Voltage Ceiling System

Options See key on back cover.

6 1/4 " or 8"

JW Smooth Frame White - Standard JB Smooth Frame Black KW Striated Frame White KB Striated Frame Black Note: Fixture body flange finished in gloss white on mounting styles X3B & X4B.

Circuiting

P9200

SC Single Circuit DC Dual Circuit (2-lamp minimum) 120, 277, 347, UNV 120-277 X1 T-Bar (exposed) -Standard X3B Hard Ceiling (flange trim: overhead mounting brackets) X4B Hard Ceiling (flange trim: "C" channel) X5B T-Bar (concealed) X8B Armstrong Interlude® XL Grid System compatible

48"

A high-quality 2" deep regressed skylight troffer, P9200 is a classic clean fixture that creates the feel of a skylight. Comes with a sturdy, extruded aluminum doorframe with a smooth or striated surface and clean mitered corners. Fixture is designed for contiguous ceiling applications and is recess mounted into exposed T-bar or hard ceilings.

EML* EMH* DM RSE† 10THD† B_ MR FH *Consult Factory for Fixture Lengths < 4' † T8 only

LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

06 141

RECESSED / P8600

06 142

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P8600

ORDERING MATRIX Series

Lamp Rows

P8604 P8614 P8622 P8624 P8633 P8644

6" x 4’ 1’ x 4’ 2’ x 2’ 2’ x 4’ 3’ x 3’ 4’ x 4’

LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 6" x 4’ 1T8, 2T8, IT5/HO, 2T5/HO 1’ x 4’ 2T8, 3T8, 4T8, 2T5/HO, 3T5/HO, 4T5/HO 2’ x 2’ 2T8, 2T846, 2T5/HO, 2BX_w† 2’ x 4’ 2T8, 3T8, 4T8, 6T8, 2T5/HO, 3T5/HO, 4T5/HO, 6T5/HO, 3’ x 3’ 4T8, 6T8, 4T5/HO, 6T5/HO 4 x 4’ 4T8, 6T8, 8T8, 4T5/HO, 6T5/HO 8T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming †Biax specify 40w, 50w, or 55w

Shielding

Frame Style/Color

PRA Prismatic Acrylic Lens- Standard P19A Prismatic Acrylic Lens, Pattern19 PWS Minicube Louver-Silver (1/2" x 1/2" x 1/2") PW2S Minicube Louver-Silver (11/2" x 11/2" x 1) WA White Acrylic Diffuser DW Flush Frame (steel) White DB Flush Frame (steel) Black SW Flush Frame (aluminum) White SB Flush Frame (aluminum) Black RW 1/2" -Deep Regressed Frame (aluminum) white RB Deep Regressed Frame (aluminum) black MW Regressed Frame (aluminum) with Black Reveal

P8600 5"

Note: Body flange finished in Gloss White on mounting styles X3A, X3B & X4B Reflector System

Circuiting Voltage Ceiling System

Options See key on back cover.

W White - Standard S* Specular Miro®IV aluminum *Available on P8614, P8622 & P8624, 2- or 3-lamp only SC Single Circuit DC Dual Circuit (2-lamp minimum) 120, 277, 347, UNV 120-277 X1 T-Bar (exposed) -Standard X3A Hard Ceiling (flange trim: swing arm) - N/A P8604 X3B Hard Ceiling (flange trim: overhead mounting brackets) X4B Hard Ceiling (flange trim: "C" channel) X5 T-Bar (concealed) 10THD† AL B_ 20G SB PAF 2SB CR TRS EML* MR EMH* FH DM 1PL P8644 only RSE†

2 3"

A classic high-end 5" deep-lensed troffer, P8600’s availability in many sizes and apertures makes it wildly versatile and adaptable. Apertures range from 6" x 4’ narrow to 4’ by 4’ square. Designed to work with assorted lamp types in most grid styles and ceiling surfaces, P8600 works well in both square and continuous-row installation. Fluid integration with the ceiling is achieved through options including doorframe style, flat or regressed lens elevations and steel or aluminum housing.

*Consult Factory for Fixture Lengths < 4’ † T8 only LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

06 143

LINEAR

07 144 Pulse

146

P40

150

P60

158

P69

160

Wave2

Pru15

166

Aparia

P46

156

162

Wave

164

170

172

Simple understated essential fixtures that provide the illumination that allows entrepreneurs, scientists, teachers, lab technicians and everyday workers to invent, search, teach and work.

07 145 Pru5

174

P25

176

Pru7

180

Olympic

182

Vader

194

178

192

MiniOlympic

184

Pru9

Snap

196

HalfSnap

197

LINEAR / PULSE

07 146

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com

Pulse

Juxt Interactive

PULSE 5" max ORDERING MATRIX Series Lamp Rows Nominal Length

Shielding

PULSE 2T5/HO 04’ 08’ R__ Row Length NS No Shielding LPA Linear Prismatic Acrylic Lens

Color/Finish

YGW Gloss White

Distribution

D3 Direct/Indirect

Voltage

Mounting

Ceiling System

Options See key on back cover.

9 1/4 "

120 277 347 UNV 120-277

Inspired by the rhythms of the California coastline, Pulse is more than just another linear pendant. It’s a luminous sculptural form that, when repeated in rows, transforms the typical static rectilinear space into a dynamic environment where time and movement are implied. And its lantern-like luminosity creates a glow that projects evenly to beautifully illuminate floors, walls, ceilings and other architectural surfaces.

CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid EML 8' or Longer Fixtures EMH 8' or Longer Fixtures DM B_ FH IBC _DLH

45º

45º 0º

07 147

LINEAR / PULSE

07 148

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Pulse

inspire and de(light)

pulse These are the emotions of innovation and change. Prudentialâ€™s luminous homage to the cool design culture of the California coast and the rhythm of the ocean. Prudential shines with the pulse of innovation.

Award winning ad campaign recognized by Architectural Record, Form and Graphis magazines.

LINEAR / P40

07 150

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com

P40

Cole Haan

ORDERING MATRIX Series

Lamp Rows

P40 LED P40 Standard P40 STG Staggered, D1 & 1 Lamp Only LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K STD 1T8, 2T8, 1T5/HO, 2T5/HO STG 1T8, 1T5/HO *LO-Low, SO-Standard, HO-High (Output )- see Options for Dimming

Nominal Length

Shielding

Color/Finish

Disribution

Circuiting

Voltage

Mounting

Ceiling System

Options See key on back cover.

LED Options

03’ 04’ 08’ R__ Row Length NS No shielding - D2 only SAL* Satin Acrylic Extruded Lens OPL* Opal Frost Acrylic Lens PRA* † † Prismatic Acrylic Lens SPL† Parabolic Louver BLA† Blade Louver Aluminum BLW† Blade Louver White *N/A DLH †Acrylic Overly Masks LED's † †Fluorescent only TMW Textured Matte White - Standard YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized Steel D1 Direct D1R* Asymmetric to Room D1W* Asymmetric to Wall D2* Indirect D2R* Indirect/Asymmetric to Room *1-Lamp or LED only

P40 4"

SC Single Circuit DC* Dual Circuit (in-line) - N/A STG *2-Lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SUR* Surface Mount WB Wall Bracket (2" standoff) WS Wall Spacer (1/2" standoff) WM Direct to Wall, ADA Compliant *For Non-Staggered D1, D1R, D1W only X1 Exposed T-Bar -Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM Specify Manufacturer RSE T8 only 10THD T8 only (not available on STG) B_ FH C2 90º 2 Way Connector; unlit CX Custom Connector ADC T8 only - D2 only _DLH SPL, BLA, BLW only INTCW ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

4" P40_cross2

A sleek and compact square luminaire, P40 cuts a crisp 4" profile and is slender enough to be ADA-compliant when wall mounted. The P40 uses either LED or optional single-lamp staggered lamping, delivering even light without socket shadows to enhance an architectural space. Immense design flexibility with direct, indirect, symmetric or single lamp asymmetric light distributions. Can be mounted to fit any design aesthetic. Dimming option for glare-free classroom and conference presentations. >

See the reference fixture on pages 93, 95, 157.

45º

45º 0º

07 151

LINEAR / P40

07 152

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P40

Idylwild LIbrary

HMC Architects

07 153

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P40

Walt Disney Concert Hall Store

Hagy Belzberg

LINEAR / P40

07 154

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P40

Ernest McBride High School

LPA Inc.

Costea Photography

07 155

LINEAR / P46

07 156

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P46

Laughlin Constable

Gary Lee Partners

ORDERING MATRIX Series Lamp Rows Direct/Indirect

P46 LED P46 LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K D3 1T8/1T8 2T8/1T8 1T8/2T8 2T8/2T8 D6 1T8/1T8 1T8/2T8

1T5/HO-1T5/HO 2T5/HO-1T5/HO 1T5/HO-2T5/HO 2T5/HO-2T5/HO 1T5/HO-1T5/HO 1T5/HO-2T5/HO

D7R/ 1T8/1T8 1T5/HO-1T5/HO D7W 2T8/1T8 2T5/HO-1T5/HO D8R/ 1T8/1T8 1T5/HO-1T5/HO D8W 2T8/1T8 *LO-Low, SO-Standard, HO-High (Output )- see Options for Dimming Nominal Length Shielding For Direct Lighting

Color/Finish

Distribution

Circuiting Voltage Mounting

Ceiling System

Options See key on back cover.

LED Options

02’, 03’, 04’, 06’, 08’ R__ Row Length SAL Satin Acrylic Extruded Lens OPL Opal Frost Acrylic Lens PRA* Clear Prismatic Acrylic Extruded Lens SPL † Silver Parabolic Louver BLA † Blade Louver Anodized BLW † Blade Louver White *N/A LED † Acrylic Overly Masks LED's TMW Textured Matte White - Standard YGW Gloss White YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized Steel D3 Direct/Indirect D6 Asymmetric Direct/Indirect D7R Direct/Asymmetric Indirect to Room D7W Direct/Asymmetric Indirect to Wall D8R Asymmetric Indirect to Room/Room D8W Asymmetric Indirect to Wall/Wall SC Single Circuit DC Dual Circuit, Direct & Indirect Circuits 120, 277, 347 UNV 120-277, Only LED Voltage CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) WB Wall Bracket (2" standoff) WS Wall Spacer (1/2" standoff) WM Direct to Wall - ADA Compliant X1* Exposed T-Bar X3* Hard Ceiling X6* Slot Grid *Specify with Cable Mount only EML 4' Minimum Length EMH 4' Minimum Length DM Specify Manufacturer RSE - T8 only 10THD - T8 only B_ FH IBC C2 90" 2-Way Connector; unlit CX Custom Connector ADC INTCW _DLH Consult Factory, SPL, BLA, BLW only ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

P46

P46 is a 4" by 6" highly adaptable linear luminaire that fits nearly any space. This direct/indirect fixture offers both symmetric or single lamp asymmetric distributions. Mounting options include pendant, surface or wall. Comes in LED or single lamp staggered lamping system for even light with no socket shadows and RightLight™ sensors for harvesting daylight to maximize efficiency. >

See the reference fixture on pages 93, 95, 115.

45º

45º 0º

07 157

LINEAR / P60

07 158

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P60

USC John McCay Center

RA-DA

Ralf Strathmann

ORDERING MATRIX Series

P60

Lamp Rows

1T8 2T8

Nominal Length

Shielding

04’ 08’ R__ Row Length NS No shielding - D2 only PRA* Prismatic Acrylic Lens WA* White Acrylic Diffuser SAL* Satin Acrylic Extruded Lens SPL Silver Parabolic Louver BLA Blade Louver Aluminum BLW Blade Louver White 3EA† Asymmetric Acrylic Lens *Not available with DLH †1 lamp only-Not available with DLH

Color/Finish

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized Steel

Distribution

D1 Direct D1R* Asymmetric to Room D1W* Asymmetric to Wall D2 Indirect D3 Direct Indirect (40/60) - Wall Mount only D9 Semi-Direct (83/17) - 2 lamp only

P60

*Wall Mount 1-Lamp only Circuiting Voltage

Mounting

SC Single Circuit DC* Dual Circuit (in-line), 2-Lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount WB Wall Bracket (3" standoff) WS Wall Spacer (1" standoff) *Specify length in inches

Ceiling System

Options See key on back cover.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE 10THD B_ FH IBC BSH Stem Mounting 2-lamp only CO End Connector C1 Straight Connector C2 900 2-Way Connector C3 900 3-Way Connector C4 900 4-Way Connector CX Custom Connector _DLH SPL, BLA, BLW only INTCW

* *Consult Factory

A classic versatile 6" x 6" linear luminaire, P60 is a square fixture that works way outside the box, and is perfect for expansive, voluminous spaces like retail floors, libraries, open offices and wide-open corridors. Mounting options include direct, stem, cable, wall spacer and 3" wall bracket. P60 also offers a broad range of corner connection options giving designers freedom to create specific shapes and patterns. >

See the reference fixture on pages 101, 103.

45º

45º 0º

07 159

LINEAR / P69

07 160

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P69

Kixeye Gaming

Rapt Studio

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

P69 D1 1T8, 2T8 D2 1T8, 2T8 D3 1T8*/1T8†, 2T8*/1T8† 1T8*/2T8†, 2T8*/2T8† D6 1T8*/1T8†, 1T8*/2T8† D7R/D7W 1T8*/1T8†, 2T8*/1T8† D8R/D8W 1T8*/1T8† *Direct †Indirect 04’ 08’ R__ Row Length NS No shielding - D2 only PRA Prismatic Acrylic Lens WA White Acrylic Diffuser SAL Satin Acrylic Extruded Lens SPL Silver Parabolic Louver BLA Blade Louver Aluminum BLW Blade Louver White

Color/Finish

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color

Distribution*

D1 Direct D2 Indirect D3 Direct/ Indirect D6 Asymmetric Indirect D7R Direct/Asymmetric to Room D7W Direct/Asymmetric to Wall D8R Asymmetric/Asymmetric to Room D8W Asymmetric/Asymmetric to Wall *See Distribution Illustrations on spec sheet

Circuiting Voltage

Mounting

SC Single Circuit DC Dual Circuit (in-line), 2-Lamp Minimum 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount WS Wall Spacer (1" standoff) SUR Surface Mount, D1 only *Specify length in inches

Ceiling System

Options See key on back cover.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE 10THD B_ FH IBC BSH Stem Mounting 2-lamp only ADC CO End Connector C1 Straight Connector C2 900 2-Way Connector C3 900 3-Way Connector C4 900 4-Way Connector CX Custom Connector _DLH Consult Factory. SPL, BLA, BLW only

P69 9"

07 161

*Consult Factory

A striking streamlined rectilinear 6" x 9" linear light, P69 is a singular linear luminaire for multiple spaces. Designed for building lobbies, corridors and high-volume spaces. P69 is aesthetically compatible with the P60 series. A wide variety of lenses, louvers and mounting options and optional modular corner connectors and assemblies make patterns and angles customizable to any space or aesthetic.

45º

45º 0º

LINEAR / WAVE2

07 162

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Wave2

South Elementary

HMC Architects

RMA Architectural Photography

ORDERING MATRIX Series Lamp Rows

WV2 LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8, 2T8, 3T8 1T5/HO, 2T5/HO, 3T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

04’ 08’ 12’ R__ Row Length ABW Acrylic Batwing Lens - LED only WA White Acrylic Diffuser - Standard SPL Silver Parabolic Louver* BLW Blade Louver White* *Not available in LED

Color/Finish

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color

Distribution

D1 Direct Solid Top D1X** Symmetric Extended Performance D3 Direct/Indirect - Standard D3C*† Direct/Indirect w/center Lamp D9† Semi-Direct/Perforated Top

WAVE2

*3-lamp only †Fluorescent only **LED only - specify ABW lens Circuiting Voltage

Mounting

Ceiling Systems

Options See key on back cover.

2 3/4 " 9"

SC Single Circuit DC Dual Circuit, 2- or 3-lamp only or LED 120 277 347 UNV 120-277 - only LED voltage CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM B_ FH IBC ADC _DLH* _OCO* _OCDM* INTC†

Wave2 is a low-profile high performance direct/indirect fixture that directs light out to uniformly light the ceiling and down onto study or work surfaces for optimal lighting conditions. An ideal choice for classrooms, this linear fixture has three different integrated control systems available to maximize energy efficiency and lighting flexibility for an array of daylight conditions or user experience needs. LED or fluorescent lamp options. Housing made from 20-gauge steel with cast aluminum ends. >

See the reference fixture on page 203.

*Consult Factory †See Sense™ System to Specify LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

07 163

LINEAR / WAVE

07 164

CONTACT PRUDENTIAL LTG. FIXTURE FIXTURE CLIENT Tel. 213.746.0360 / prulite.com Wave

ARCHITECT CLIENT

University of Hawaii ZGF Architects SuperCove TRIS3CT

ARCHITECT PHOTOGRAPHER Lawrence Anderson Gary Lee Partners

ORDERING MATRIX Series Body Style

Lamp Rows

Nominal Length

Color/Finish

Circuiting Voltage

Mounting

Ceiling System

WV P Perforated -Standard SD Solid SL Slotted 2T8 3T8 1T5/HO 2T5/HO 3T5/HO 04’ 08’ 12’ R__ Row Length TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit, 2- or 3-lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable)

WAVE *

A classic shallow curvilinear luminaire, with a wide spread indirect distribution. The single T5 version is designed for low ceiling applications, throwing light at very low angles to maintain excellent ceiling uniformity. Wave’s housing is constructed from 20-gauge steel and distinctive medallions made from aluminum castings finish row ends. Available as a completely solid indirect; a subtly perforated or slotted version.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid

See key on back cover.

EML EMH DM RSE T8 Only 10THD T8 Only B_ FH IBC ADC _DLH* _OCO* _OCDM* *Consult Factory

*Consult Factory

Options

2 3/4 "

See the reference fixture on page 203.

07 165

LINEAR / PRU15

07 166

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Pru15

HDR Architects

ORDERING MATRIX Series Body Style Lamp Rows

PRU 15 SQ Square R Round LED3 LO, SO, HO* 3000K LED35 LO, SO, HO* 3500K LED4 LO, SO, HO* 4000K 1T8 , 2T8, 3T8 1T5/HO, 2T5/HO, 3T5/HO *LO-Low, SO-Standard, HO-High (Output) - see Options for Dimming

Nominal Length

Shielding

04’ 08’ 12’ R__ Row Length ABW Acrylic Batwing Lens SAL Satin Acrylic Extruded Lens - Standard PRA* Prismatic Acrylic Lens LPA Optiglow™ Linear Prismatic Lens SPL Silver Parabolic Louver† BLW Blade Louver White† *Fluorescent only † Not available in LED

Color/Finish

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized

Distribution

D1 Direct Solid Top D1X† Symmetric Extended Performance D3 Direct/ Indirect - Standard D3C* Direct/ Indirect w/center Lamp D9* Semi-Direct Solid Top

PRU15 2 1/2 "

*3 Lamp only † LED only Circuiting Voltage

Ceiling System

Mounting

Options See key on back cover.

10"

SC Single Circuit DC Dual Circuit, 2- or 3-lamp only or LED 120 277 347 UNV 120-277 only LED voltage X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) EML EMH DM Specify Manufacturer B_ FH IBC ADC _DLH* _OCO* _OCDM INTC†

A high performance rectilinear luminaire, Pru15 is designed to direct light out to uniformly light the ceiling between fixture rows, and down onto work surfaces for optimal classroom study or workspace lighting needs. LED or fluorescent lamp options, Pru15’s direct/indirect lighting system is designed with options for three different controls systems to maximize energy efficiency for various conditions. Suspended from aircraft cables.

*Consult Factory † See Sense™ System to Specify LED Options

ND Non-Dimming - Standard DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming STEP Step Dimming 100-50-Off DML 1% Lutron Dimming DMD 1% Dali Dimming

45º

45º 0º

07 167

07 168 CASE STUDY

CASE STUDY

EXETER SCHOOL An exercise in smart lighting. The school district of Exeter, Missouri, needed to provide a new gymnasium, cafeteria, and performance space for its 320 students. Architects Brandon Dake and Andrew Wells of Dake Wells Architecture in Springfield, MO collaborated with electrical engineer Devin Conway, acoustician Bruce Moore, and daylighting advisor Jason Hainline to make their solution work: a single 11,600-sq.-ft. structure plus an additional 5,400 sq. ft. in an existing building to achieve both operational and aesthetic goals. The sculptural ceiling plays the key role in the scheme: it unifies the new and existing structures, provides acoustic panels, and integrates lighting and daylighting for the new space. According to Dake, the complete system is kind of like a sushi roll: the wood wrapper helps reflect sound, while the acoustic panels act as rice “absorbing the sound.” “Our basic approach to lighting the space,” says architect Wells, “was to make the most effective use of daylight.” The team opened the east and west ends with large expanses of frosted glass, and added four 32" X 96" skylights. Randomly-placed 6" x 4’ Prudential P63 recessed fixtures are the size and scale the designers wanted to accentuate the visual interest of the wood ceiling. The dimmable fixtures, using 32W T8 lamps, have high impact-resistant acrylic lenses and integrated emergency ballasts. On overcast days, Conway recorded 55 fc (foot candles) in the main assembly space, rising to 120 on bright days. Conway pointed out that the space has achieved its designed power density of 1.1 watts per sq. ft. A photocell was installed for overall control of the indirect lighting based on natural light available in the space.

07 169

LINEAR / APARIA

07 170

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Aparia

ORDERING MATRIX Series/Style

APA-GLO (Glow) STR Solid Translucent Fascia LP Large Aperture Perforated P Small Aperture Perforated APA-TRO (Throw) SD Solid HSL Horizontal Slots

Distibution APA Tro only Color/Finish (All except STR)

Color/Finish - STR Lamp Rows

WD Wide Distibution - Standard NW Narrow Distibution (single lamp only) STK Stack Distibution (single lamp only) TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized Steel BFA Blue Frost Acrylic (translucent) WFA White Frost Acrylic (translucent) 1T8 2T8* 1T5/HO 2T5/HO* *TRO - Wide Distribution only

Nominal Length

Cast Plate/ Rail Louver Finish

Flat Endplate Finish

Circuiting Voltage

Mounting

Ceiling System Options See key on back cover.

APARIA 6 1/8"

04’ 08’ R__ Row Length TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color BAL Brushed Aluminum GLV Galvanized SC Single Circuit DC Dual Circuit (in-line) 2-lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable)

07 171 6"

Created in collaboration with Aparia Design, the versatile Aparia is available in two versions allowing you to choose your lighting effect. The Glow is the translucent body style with a curvaceous form that creates a luminous, radiant presence with three distinctive fascia. The Throw body style has a high performance reflector with precise control and with three distribution patterns in the reflector system. Options include assorted metal finishes and translucent acrylics, wide, narrow or stack distributions. >

See the reference fixture on page 207.

X1 Exposed T-Bar - Standard X3 Hard Ceiling EML EMH DM RSE T8 only 10THD T8 only B_ IBC

45º

45º 0º

LINEAR / M5

07 172

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

A’Maree’s

PAUL DAVIS Architects

ORDERING MATRIX Series Body Style

Lamp Rows Nominal Length

M5 SQ Square O Octagonal R Round E Elliptical 1T5/HO 2T5/HO 04' 08' R__ Row Length

Shielding

SPL Silver Parabolic Louver - Standard SPL-OL Silver Parabolic Louver - with Acrylic Overlay - Not available with DLH

Color/Finish

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized

Circuiting Voltage

Mounting

Ceiling System

Options See key on back cover.

SC Single Circuit DC Dual Circuit (in-line) 2-lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable)

2 5/16 " 7"

The M5 is a high-performance compact fixture that is ideally suited to classrooms, libraries, and open-floor offices with optional square, octagonal, round and elliptical body styles. Removable end plates make for clean continuous row-mounting options. Indirect light spreads wide across the ceiling while direct illumination is controlled by parabolic louvers. T5 and T5HO lamps only.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM B_ FH IBC _DLH* _OCO* _OCDM* *SQ Body, SPL only. Consult Factory

45ยบ

45ยบ 0ยบ

07 173

LINEAR / PRU5

07 174

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Pru5

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

PRU5 2T8 3T8 2T5/HO 3T5/HO 04' 08' 12' R__ Row Length SAL* Satin Acrylic Lens SPL Silver Parabolic Louver - Standard PRA* Prismatic Acrylic Lens *Not Available with DLH

Color/Finish

Reflector System

Circuiting Voltage

Mounting

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized Steel D1 Direct Solid Top D3 Direct/Indirect - Standard D9 Semi-Direct (85/15)

Options See key on back cover.

3 1/2 " 10 1/2 "

SC Single Circuit DC Dual Circuit (in-line) 2 or 3 lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount *Specify length in inches

Ceiling System

PRU5

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE† 10THD† B_ FH IBC AMP Existing Variable Mounting Locations BSH Stem Mounting only ADC C2 900 2-Way Connector C3 900 3-Way Connector C4 900 4-Way Connector _DLH Consult Factory - SPL only † T8 only

A classic capsule-shaped linear luminaire, Pru5 is perfectly suited for mixed-use areas, retail, classrooms, laboratories and open-floor offices. With an optional adjustable mounting plate for irregularly-spaced mounting points, existing mounting points and feed locations, Pru5 fits nearly any configuration. Die-formed internal reflectors coupled with a semi-specular parabolic louver give even, efficient light. Dimming, emergency and integrated daylight harvesting options available.

45º

45º 0º

07 175

LINEAR / P25

07 176

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P25

Volcom HQ

LPA Inc.

Costea Photography

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

P25 2T8 3T8 2T5/HO 3T5/HO 04’ 08’ R__ Row Length SAL* Satin Acrylic Lens PRA* Prismatic Acrylic Lens SPL Silver Parabolic Louver - Standard *Not available with DLH

Color/Finish

Distribution

Circuiting Voltage

Mounting

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized D1 Direct D3 Direct Indirect (44/56) - Standard D9 Semi-Direct (85/15)

Options See key on back cover.

3 1/2 " 9 1/2 "

Ceiling System

P25

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid

A classic linear luminaire with a beveled edge, P25 is a unique form for any design space including classrooms, supermarkets, laboratories and open offices. P25 has a semi-specular parabolic louver that creates a 34º 01 PRU-0193 longitudinal shielding and delivers direct/indirect or semi-direct lighting. P25 comes with optional corner connectors to construct your own fixture patterns.

EML EMH DM RSE† 10THD† B_ FH IBC AMP* BSH Stem Mounting only C2 900 2-Way Connector C3 900 3-Way Connector C4 900 4-Way Connector _DLH SPL only *For Existing/Variable Mounting Locations † T8 only

45º

0º

45º

07 177

LINEAR / M7

07 178

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Interior Architects

Takata Photography

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

M7 2T8 1T5/HO 2T5/HO 3T5/HO 04’ 08’ 12’ R__ Row Length RBL Radial Blade Louver RBL-OL* Radial Blade Louver with Acrylic Overlay *Not Available with T5HO or with DHL

Color/Finish

Distibution Circuiting Voltage

Mounting

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized D1 Direct D9 Semi-Direct (80/20) SC Single Circuit DC Dual Circuit (in-line) 2 or 3 lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount *Specify length in inches

Ceiling System

Options See key on back cover.

M7 3 1/4 " 7 3/4 "

A compact oval-shaped luminaire, M7 is a high-performing fixture that throws an even bright light on vertical surfaces such as library stacks, grocery shelving, whiteboards and chalkboards. M7 delivers semi-direct lighting with an optional slotted-top housing for better illumination across ceiling surfaces. M7 features radial-blade louvers and upper-side housing perforations. The fixture maximizes energy efficiency through use of optional daylight controls.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE T8 only 10THD T8 only B_ FH IBC BSH Stem Mounting only WBC _DLH RBL only, 2-lamp only

45º

45º 0º

07 179

LINEAR / PRU7

07 180

CONTACT PRUDENTIAL LTG. FIXTURE FIXTURE CLIENT Tel. 213.746.0360 / prulite.com Pru7

CLIENT ARCHITECT

ARCHITECT

SuperCove LycÃ©e InternationalTRIS3CT Osborn Architects Gary Lee Partners

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

PRU7 2T8 3T8 2T5/HO 3T5/HO 04’ 08’ 12’ R__ Row Length RBL Radial Blade Louver - Standard RBL-OL* Radial Blade Louver with Acrylic Overlay LPA* Linear Prismatic Acrylic Lens *Not Available with DLH

Color/Finish

Voltage Circuiting Voltage

Mounting

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized D1 Direct D9 Semi-Direct (85/15) SC Single Circuit DC Dual Circuit (in-line) 2 or 3 lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount *Specify length in inches

Ceiling System

Options See key on back cover.

X1 Exposed T-Bar -Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE† 10THD† B_ FH IBC BSH Stem Mounting only WBC _DLH RBL-only † T8 only

PRU7 4 3/8 " 10"

One of our most adaptable and popular linear luminaires, Pru7’s high-side angles make it perfect for illuminating vertical surfaces such as grocery shelves, retail shelves and library stacks. Options include an aluminum radial blade louver with or without acrylic overlay, or linear prismatic acrylic lens. It can be surface mounted or suspended with aircraft cables or stems. Maximize efficiency by opting for RightLight™ sensors, which harvest daylight adjusting illumination output accordingly.

45º

45º 0º

07 181

LINEAR / OLYMPIC

07 182

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Olympic

Stamps.com HQ

Ware Malcomb

fotoworks

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding Color/Finish

OLYP 2T8 3T8 2T5/HO 3T5/HO 04’ 08’ R__ Row Length SPL Silver Parabolic Louver TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color CCA* Clear Commercial Anodized GLV Galvanized Steel

OLYMPIC 7 3/4 "

*Black Painted Endplate Distribution

D1 Direct D9 Semi-Direct (89/11)

Circuiting

SC Single Circuit DC Dual Circuit (in-line)

Voltage

Mounting

120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount *For Hard Ceilings Only. Specify Length in Inches

Ceiling System

Options See key on back

12"

A grand-scale linear system that illuminates voluminous high-ceiling spaces such as libraries, laboratories and warehouse-style architectural spaces, Olympic has a streamlined look with punched upper housing and removable finish plates for continuous row installation. Designed and named for the U.S. Olympic Training Center, Olympic delivers optional semi-direct light through slotted upper housing.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE† 10THD† B_ FH IBC BSH Stem Mounting only _DLH Consult Factory † T8 only

45º

45º 0º

07 183

LINEAR / MINI OLYMPIC

07 184

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

MiniOlympic

Solestruck

Sky Lab Architecture

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

Color/Finish

MOLY 1T8 2T8 1T5/HO 2T5/HO 04’ 08’ R__ Row Length SPL Parabolic Louver- Standard PRA* Prismatic Acrylic Lens *Not available with DLH TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color CCA* Clear Commercial Anodized GLV Galvanized Steel

MINI OLYMPIC 5 1/2 "

* *Consult Factory

6 7/8 "

*Black painted endplate Distribution Circuiting Voltage

Mounting

D1 Direct D9 Semi-Direct (89/11) SC Sincle Circuit DC Dual Circuit (in-line) 2 lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount SUR Surface Mount *Specify length in inches

Ceiling System

Options See key on back cover.

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE T8 only 10THD T8 only B_ FH IBC BSH Stem Mounting only QC _DLH SPL only

A compact version of our magnificent Olympic fixture, MiniOlympic is a clean modern versatile linear luminaire that is perfect for smaller classrooms, offices, and retail spaces. A linear direct or semi-direct system in a compact 5 1/⁄2" profile gives MiniOlympic a trim modern profile. Optional slotted top steel housing creates even semidirect light distribution on ceiling surfaces. The fixture maximizes energy efficiency through use of optional daylight controls.

45º

45º 0º

07 185

PEOPLE

07 186

Richard Schuler Design Engineering Manager

The People of Prudential

Like many family-owned enterprises, Prudential Ltg. started out small, believing bigger things would come, one new customer at a time. That’s how it’s been for sixty years. We’re still a family-owned business guided by a sense of responsibility that goes beyond our accountability to the balance sheet alone. And as we’ve grown our ranks have included many generations of employees who’ve joined Prudential Ltg. as a family tradition, spanning three and four generations. From the start, we knew that if good people were dedicated to pursuing good ideas, Prudential Ltg. would succeed. We’ve remained rooted in Los Angeles and committed to manufacturing our fixtures in America in large part because of our dedicated workforce. Members of the International Brotherhood of Electrical Workers bring to Prudential a pride of craftsmanship and spirit of cooperation that honors the finest traditions of American labor. Our national network of independent sales representatives is the final key to our success. They’re among the most knowledgeable and service oriented in the lighting industry. Collaborating with leading architects and lighting designers, their expertise gives our customers the confidence of knowing that Prudential Ltg. can bring their vision to reality. It’s simple, really. Good people make a great product even better.

07 187

PEOPLE

07 188

Jeff Cox Field Service Manager

Jose Gutierrez Shear Operator

07 189

Good people support good deeds. Our support of organizations like Heal the Bay is only natural. Los Angeles is our home, and since 1985 Heal the Bay has been helping to make southern Californiaâ€™s coastal waters and watersheds, including Santa Monica Bay, safer and cleaner. Other groups whose efforts we commit our resources and volunteer our time to include the Ronald McDonald House, the Boy Scouts of America, Amigos de los Ninos, the National Multiple Sclerosis Society, the Food Bank and Giving Back.

PEOPLE

07 190

Kara Villalobos Inside Sales

Francisco Mendoza Field Service Technician

07 191

Their qualities are our quality. We create innovative products and deliver exceptional service for one simple reason: our people are innovative and exceptional, too. Our focus is always to solve the unique needs of your project. Visit our factory in Los Angeles, and youâ€™ll see members of the International Brotherhood of Electrical Workers making sure that every fixture we fabricate and every order we ship is precisely what you want, when you want it. After all, a company is only as good as the people who work for it.

LINEAR / PRU9

07 192

CONTACT PRUDENTIAL LTG. FIXTURE CONTACT PRUDENTIAL LTG.

CLIENT FIXTURE

ARCHITECT CLIENT

Tel. 213.746.0360 / prulite.com/ prulite.com Pru9 Tel. 213.746.0360

Volcom HQ SuperCove

LPA Inc Costea Photography TRIS3CT Gary Lee Partners

PHOTOGRAPHER ARCHITECT

ORDERING MATRIX Series Body Style Lamp Rows

Nominal Length

Color/Finish

Reflector System

PRU 9 P Perforated - Standard VSL Vertical Slots 1T8 2T8 3T8 1T5/HO 2T5/HO 3T5/HO 04' 08' 12' R__ Row Length TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized W White Ballast Cover - Standard S* Specular Miro™IV Aluminum

PRU9 3"

*2 or 3 lamp only Frame Style Color Voltage

Mounting

SC Single Circuit DC* Dual Circuit, 2 or 3 lamp only 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable) SSC_* Top Swivel Stem Mount *Specify length in inches

Ceiling System

Options See key on back cover.

10 1/8 "

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid EML EMH DM RSE T8 only 10THD T8 only B_ FH IBC BSH Stem Mounting only ADC C2 90o 2-Way Connector C3 90o 3-Way Connector C4 90o 4-Way Connector _DLH* _OCO* _OCDM* *Consult Factory

Pru9 is a classic curvilinear shape luminaire with an indirect distribution, an ideal solution for high-quality lighting of conference rooms, open offices, or gathering nodes. An architecturally highlighted housing with perforations or vertical slots, Pru9 comes with an option for a specular aluminum reflector for enhanced even gradient ceiling illumination. Efficiency is enhanced with RightLight™ sensors that measure light levels adjusting output according to daylight harvest.

45º

0º

45º

07 193

LINEAR / VADER

07 194

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Vader

ORDERING MATRIX Series Lamp Rows Nominal Length

VDR 2T8 2T5/HO

VADER

04’ 08’ R__ Row Length

5 1/4" 9 /8" 7

Shielding

RBL Radial Blade Louver - Standard RBL-OL* Radial Blade Louver with Acrylic Overlay *Not Available with DLH

Color/Finish

Circuiting Voltage

Mounting

TMW Textured Matte White - Standard YGW Gloss Whte Y_ Premium Color CC Custom Color GLV Galvanized SC Single Circuit DC Dual Circuit (in-line) 120 277 347 UNV 120-277 CA48" Aircraft Cable (adjustable) - Standard CA96" Aircraft Cable (adjustable) CA144" Aircraft Cable (adjustable)

Cieling System

X1 Exposed T-Bar - Standard X3 Hard Ceiling X6 Slot Grid

Options

EML EMH DM RSE T8 only 10THD T8 only B_ FH IBC DLH Consult Factory, RBL only

See key on back cover.

The Vader optical system offers a fresh direct/indirect lighting approach. The unique closed-top indirect reflector system lights the celing uniformly while reducing brightness above the fixture. Vader’s radial blade louver shields while controlling light with forward throw optics. Removable finish plates make continuous row installation simple for a long, continuous linear. Options for dimming, emergency and harvesting daylight make Vader smart both in function and style.

45º

45º 0º

07 195

LINEAR

07 196

SNAP Our best selling architectural wrap, shown here with LED, a single-piece lens and no socket shadows. See page 66.

HALF-SNAP Monsterâ€™s Headquarters in Southern California features the pendant mounted Half Snap. See page 74.

07 197

08 198 WALL MOUNT

WALL MOUNT

Wall mounted fixtures illuminate the walls of an interior. They light the way in corridors, the artwork and logos on walls and help define the boundaries of a space.

08 199 ERgo

200

WalWave

202

WalAparia

206

P40

212

P46

212

Wal14

208

Strand

204

Wal8

210

P69

213

Quick Find on the web, search P0107.

P60

213

WALL MOUNT / ERGO

08 200

CONTACT PRUDENTIAL LTG. FIXTURE FIXTURE

CLIENT ARCHITECT

Tel. 213.746.0360 / prulite.com ERgo Snap Richardson Apartments

Rapt Studio

ERGO

11 1/4 "

08 201 11 1/4 "

ORDERING MATRIX Series Lamp Rows Shielding Color/Trim Distribution Circuiting Voltage Mounting Options LED Options

ERGO LED3 3000K LED4 4000K RD Round SQ Square w/Rounded Corners TMW Textured Matte White

A glass LED wall sconce, the ADA compliant ERgo hugs walls with both minimal projection and lowers the risk of catching a passing IV cord. When California‘s OSHPD code changed to limit protrusion of corridor fixtures to 1.5", Prudential leveraged this mandate for a new level of brilliance in sconce luminaires. The ERgo™, in both round and square designs, are simple, smart and aesthetic. ERgo emanates light in a soft, glowing, soothing way— demonstrating both beauty in form and utility in function.

D1 SC Single Circuit UNV 120-277 Wall semi-recessed Rough-in Bracket Kit DM 1% Lutron DM10 0-10v 10% Dimming DM01 0-10v 1% Dimming DL 1% Lutron Dimming DMD 1% DALI Dimming

45º

0º

45º

WALL MOUNT / WAL WAVE

08 202

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com WalWave

ORDERING MATRIX Series Body Style

Lamp Rows

Nominal Length

Color/Finish

Circuiting Voltage

Mounting Options See key on back cover.

WAL WAVE

WALWV P Perforated - Standard SD Solid SL Slotted 1T5/HO 1T8 2T5/HO 04’ 08’ R__ Row Length TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color SC Single Circuit DC* Dual Circuit 2-lamp only 120 277 347 UNV 120-277

2 3/4 "

*Consult Factory

6 1/4 "

The WalWave illuminates with a rush of warm indirect light. The design aesthetics complement the shallowradiused Wave and Wave2 linear fixtures. The low-profile indirect wall bracket comes in perforated, slotted or a solid fascia with cast aluminum end medallions. The WalWave accommodates up to 1T8, 2T5 or T5HO lamps and comes in lengths of 4’ and 8’. >

See the reference fixtures on pages 163, 165.

WM Direct to Wall EML EMH DM B_ RSE* 10THD* FH QC ADC *T8 only

0º 45º

08 203

WALL MOUNT / STRAND

08 204

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Strand

Volcom

LPA Inc.

PHOTOGRAPHER

Costea Photography

ORDERING MATRIX Series Body Style

Lamp Rows Nominal Length

Lensing

Housing/ Fascia Color

Socket Cap/ Endplate Color

Mounting

Ceiling System

STRAND NF No Fascia SFP Symmetric Fascia Perforated AFP Asymmetric Fascia Perforated 1T5/HO 02’ 03’ 04’ 06’ 08’ R__ Row Length NS* No Shielding SAL Satin Acrylic Lens WA White Acrylic Lens *only option for AFP YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color YGW Gloss White - Standard TMW Textured Matte White YPE Pewter Y_ Premium Color CC Custom Color SUR* Surface or Wall Mount SMR Semi Recessed into hard ceiling or wall *Standard - ADA compliant X3 Hard Ceiling X7 Hard Ceiling Trimless - SMR only Specify with cable mount only

Voltage

120 277 UNV 120-277

Options

EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** MRK10** B_ FH QC EBCP1G EBCP2G

See key on back cover.

*4' minimum fixture length **Specify 120 or 277 voltage

STRAND 13/8" 4"

45º

0º

45º

08 205

WALL MOUNT / WAL APARIA

08 206

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Wal Aparia

ORDERING MATRIX Series

WAL-AP-GLO WAL-AP-TRO

Body Style

STR Solid Translucent LP Large Aperture Perforated VSL Vertical Slots P Small Aperture Perforated SD* Solid *TRO series only

Color/Finish

BFA* Blue Frost Acrylic WFA* White Frost Acrylic TMW Textured Matte White YPE Pewter GLV Galvanized BAL Brushed Aluminum * Not Illuminated on TRO Style

WAL APARIA

Lamp Rows

1BX24w* 1’ Only 1T8 1T5/HO *GLO series only

*Consult Factory

Nominal Length

01’* 02’ 03’ 04’ R__ Row Length *GLO series only

Cast Plate Mounting Finish

TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color

Flat End Plate Finish

TMW Textured Matte White YPE Pewter YBB Black Y_ Premium Color CC Custom Color BAL Brushed Aluminum GLV Galvanized

Mounting Options See key on back cover.

* 11 7/8 " 8 3/16 "

WalAparia is a highly configurable linear wall mount luminaire with an elegant arced profile. A wide offering including premium metals, contrasting paint colors, perforation patterns, and reflector options provide almost infinite possibilities for a customized look for any space. Choose the high-performance forward throw distribution to evenly light the ceiling; or allow light to glow through translucent acrylic or perforated metal fascias for a lantern effect. >

See the reference fixture on page 171.

ADJ Adjustable Mounting Bracket FMB Fixed Flush Mounting Bracket EML* EMH* DM B_ RSE T8 only 10THD T8 only *4’ minimum fixture length

4 1/2 "

0º

45º

08 207

WALL MOUNT / WAL14

08 208

CONTACT PRUDENTIAL LTG. FIXTURE FIXTURE CLIENT Tel. 213.746.0360 / prulite.com Wal14

CLIENT ARCHITECT

Snap LA Animal Shelter Richardson Apartments RA-DA Studio

ARCHITECT PHOTOGRAPHER Rapt Studio Ralf Strathmann

ORDERING MATRIX Series Body Style

Lamp Rows

Nominal Length

Color/Finish*

Circuiting Voltage

Mounting

WAL14 WFA White Frost Acrylic BFA Blue Frost Acrylic P Perforated SD Solid 1T8 2T8 1T5/HO 2T5/HO 02’ 03’ 04’ 06’ 08’ R__* Row Length *WFA/BFA adds .25" to length P/SD adds .125" to length

WAL14 7"

08 209

TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color BAL** Brushed Aluminum CC Custom Color GLV Galvanized *For WFA and BFA specify paint color for Endplate and Bezel only **SD Body Style only - black endplate unless otherwise specified SC Single Circuit DC Dual Circuit (in-line) 2 lamp only 120 277 347 UNV 120-277 WM Direct to Wall - Standard SUR* Surface or Ceiling Mount VWM* Vertical Wall Mount

*Consult Factory

An ADA-compliant wall mount luminaire, the Wal14 is an architectural fixture open at the top and bottom to wash light above and downward. Optional white or blue frost acrylic fascias give a warm and modern feel. Wal14 has S-Occ™, Prudential ‘s control system that keeps lamps off or dimmed to minimum output while unoccupied. Its direct/indirect lighting with a soft glow is perfect for illuminating hallways, entryways, small spaces and stairwells.

*Kicker Reflector is not Supplied Options See key on back cover.

EML* EMH* DM RSE † 10THD † B_ FH QC OCO* OC2C* 2 lamp only OCDM* *4’ minimum fixture length † T8 only

0º

45º

WALL MOUNT / WAL8

08 210

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Wal8

Oasis Senior Center

Robert Coffee Architects

RMA Photography

ORDERING MATRIX Series Body Style

Lamp Rows

Nominal Length

Color/Finish

Circuiting Voltage

Mounting Options See key on back cover.

WAL8 P2 Perforated 2" P4 Perforated 4" - Standard VSL Vertical Slots SD Solid 1T5/HO 1T8 2T5/HO 2T8 02’ 03’ 04’ 06’ 08’ R__ Row Length TMW Textured Matte White - Standard YGW Gloss White Y_ Premium Color CC Custom Color GLV Galvanized SC Single Circuit DC* Dual Circuit (in-line), 2-lamp only 120 277 347 UNV 120-277 WS Wall Spacer (1/2" standoff) WM Direct to Wall - Standard EML* EMH* DM RSE T8 only 10THD T8 only B_ FH QC ADC C2 90o 2-Way Connector *4’ minimum fixture length

WAL8 3 1/4 "

* 8"

*Consult Factory

A curvilinear shaped indirect luminaire, Wal8 is a lowprofile architectural fixture that works well in modern retail space, corridors or big open lobbies. A sculptural linear fixture for large spaces, its clean sleek lines make this wall mount an architectural design point with assorted body styles, perforated in 2" and 4" vertical slots, in solid and numerous optional metal finishes. A complementary wall mount to the Pru9. Wal8 accommodates up to 2/T8, T5, or T5HO lamp configurations. >

See the reference fixture on page 193.

0º 45º

08 211

P40

WALL MOUNT

Our best-selling square fixture with a 4" profile enhances any architectural space. See page 150 for complete specifications.

08 212

P46 This 4" x 6" linear luminaire is option-rich, stylish, highly adaptable and efficient. See page 156 for complete specifications.

P60 The linear 6"”x 6"”fixture that provides a broad, even light in voluminous spaces. See page 158 for complete specifications.

08 213

P69 The classic style of our 6" x 9"” linear luminaire is compatible for use with the P60. See page 160 for complete specifications.

09 214 STRIPS

STRIPS

Strip lights are the unsung heroes of lighting; fundamental lines of light. Use these straightforward, clean strips as a functional way of embellishing a space.

09 215 Edge

216

Twist

222

String

218

PT5 PT8 PT8W

226

PT5SS PT8WSS

228

STRIPS / EDGE

09 216

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Edge

ORDERING MATRIX

Color/Finish

Circuiting Voltage

Mounting

Ceiling System

Options See key on back cover.

02’ 03’ 04’ 06’ 08’ R__ Row Length

EDGE

Nominal Length

NR No Reflector AR Asymmetric Reflector ARP Asymmetric Reflector Perforated ASR Asymmetric Sawtooth Reflector APR Symmetric Reverse Reflector SR Symmetric Reflector SRP Symmetric Reflector Perforated

ARR

Body Style

1T8 1T5/HO 1SM/HO

TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color SC Single Circuit 120 277 UNV 120-277 SUR Surface or Wall Mount - Standard CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) SMR Semi Recessed into hard ceiling or wall X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid X7 Hard Ceiling Trimless - SMR only Specify with cable mount only EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** T5HO Only MRK10** T5HO Only B_ FH IBC EBCP1G EBCP2G *4' minimum fixture length **Specify 120 or 277 voltage

Lamp Rows

EDGE

Series

2 5/16"

1 3/8"

Edge is an understated variation of a high tech strip fixture. This straightforward clean strip is an exercise in minimalism. Edge delivers an architectural aesthetic to any space. All the manufacturing details, including an integrated ballast, are concealed within a sleek housing and endplates that streamline the fixture’s look and allows it to be semi-recessed into a hard ceiling or wall. Edge’s soft edging and smooth finish provide a Euro-style flourish.

45º

45º 0º

09 217

STRIPS / STRING

09 218

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com String Chapman University: Argyros School of Business & Economics

ARCHITECT

PHOTOGRAPHER

AC Martin Partners

Tom Bonner Photography

ORDERING MATRIX Series Lamp Rows Configuration

STRING T5/HO 1TM: All Styles 1SM:

NR, ARR only

2RA:

NR, ARR only

2SM: NR, SRR only 3SM: NR, SRR only

Voltage

Mounting

Ceiling System

Circuiting

TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color

ARR

Color/Finish

02' 03' 04' 06' 08' R__ Row Length

STRING

2 5/16"

SC DC 2 or 3 lamp only 120 277 UNV 120-277 SUR Surface or Wall Mount - Standard CA48" Aircraft Cable (adjustable) CA96" Aircraft Cable (adjustable) X1 Exposed T-Bar X3 Hard Ceiling X6* Slot Grid

Nominal Length

NR No Reflector AR Asymmetric Reflector ARP Asymmetric Reflector Perforated ASR Asymmetric Sawtooth Reflector SR Symmetric Reflector SRP Symmetric Reflector Perforated

Body Style

1 3/8"

One of our most configurable strip lights, String is a mini-strip light scaled down to its purest essence. Unfettered and utilitarian, String has up to three rows of lamps and features a number of reflector choices for control and function.

*Specify with cable mount only Options See key on back cover.

EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** MRK10** B_ FH IBC EBCP1G EBCP2G

An urban industrial T5 strip light on a single, slim housing base with an integrated ballast, String is a powerful minimalist luminaire with maximum options.

*4' minimum fixture length **Specify 120 or 277 voltage 45ยบ

0ยบ

45ยบ

09 219

STRIPS / STRAND

09 220

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Strand

Commerce House

Perkins + Will

PHOTOGRAPHER

Charles Davis Smith

09 221

STRAND Use our popular Strand fixture to create amazing words and geometries. See page 77 for complete specifications.

STRIPS / TWIST

09 222

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

Twist

ORDERING MATRIX Series Lamp Rows Nominal Length

Color/Finish

Circuiting

2 7/32"

TWIST-SS Staggered Strip TWIST-DG Diagonal Staggered

2 /16 " 3

1T5/HO 2T5/HO SS Series Only 02' 03' 04' 06' 08' R__ Row Length TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color SC Single Current DC Dual Circuit 2 lamp only

Voltage

120 277 UNV 120-277

Options

EML* EMH* ECO10** ECOS** ECOS-H** HI-L** HI-L3D** MRK7** MRK10** B_ FH

See key on back cover.

TWIST

*4’ minimum fixture length **Specify 120 or 277 voltage

Twist is one of the most compact, T5 staggered strip lights in the industry. Twist’s telescoping and overlapping lamps present long, continuous clear light without the interruption of socket shadows. This versatile small strip light comes in both diagonal or traditional staggered lamping–with 6" overlaps–fitting nooks, coves and stairwells. Options for integral dimming and emergency batteries are available.

45º

09 223

OPTIONS ARE GOOD STRIPS / OPTIONS

ASR

09 224

Imagine that. Or this. Or that. Basis Series strips give you lots of lamping, reflector, lens, fascia and mounting options. The straightforward String is the most basic mini-strip available. The Edge is a clean, modern luminaire. The Twist is a low profile staggered strip T5 available in both traditional and diagonal staggered configurations. Begin here to see all the magnificent array of designs you can use to create a unified look throughout a space that fulfills your vision.

Edge

ARR

ARP

Seamless

String

Twist

2SM

3SM

2RA

SRR

STRIPS / PT5/PT8/PT8W

09 226

CONTACT PRUDENTIAL LTG. FIXTURE FIXTURES CLIENT

CLIENT ARCHITECT

PT5/PT8 Tel. 213.746.0360 / prulite.com PT8W Trash for TeachingTRIS3CT HLW Architects

ARCHITECT PHOTOGRAPHER Gary Lee Partners fotoworks

ORDERING MATRIX Series

Body Style

Lamp Rows

Nominal Length

Color/Finish

Ciruiting

PT5 PT8 PT8W STD Standard, No Reflector AR Asymmetric Reflector ARP Asymmetric Reflector Perforated SR Symmetric Reflector SRP Symmetric Reflector Perforated WA White Acrylic Diffuser WG Wire Guard 1T8 PT8 only 2T8 PT8W only 1T5/HO PT5 only 2T5/HO PT5 only 02' 03' 04' 06' 08' R__ Row Length TMW Textured Matte White YGW Gloss White - Standard YPE Pewter Y_ Premium Color CC Custom Color GLV Galvanized

2 1/8 "

3 3/8 "

The PTS/PT8/PT8W family is a compact industrial surface mount strip offering. Available with both dimming and emergency battery pack options. Reflectors include options for solid or perforated and a rugged zinc-coated wire guard. A white acrylic lens creates a sleek lensed wrap. A practical and stylish linear strip.

SC Single Circuit DC Dual Circuit 2 lamp only

Voltage

120 277 347 UNV 120-277

Options

AL Aluminum body EML* EMH* DM B_ RSE T8 only 10THD T8 only FH

See key on back cover.

PT5/PT8/PT8W

*4' minimum fixture length

45ยบ

45ยบ 0ยบ

09 227

STRIPS / PT5SS/PT8WSS

09 228

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

Tel. 213.746.0360 / prulite.com

PT5SS

Westside German Shepherd Rescue RA-DA Studio

ARCHITECT

PHOTOGRAPHER Ralf Strathmann

ORDERING MATRIX Series

Body Style

Lamp Rows

PT8W-SS Staggered PT8W-SS-TEL Staggered Telescoping PT5-SS Staggered PT5-SS-TEL Staggered Telescoping STD Standard, No Reflector AR Asymmetric Reflector ARP Asymmetric Reflector Perforated SR Symmetric Reflector SRP Symmetric Reflector Perforated

Color/Finish

Circuiting

02' 03' 04' 06' 08' R__ Row Length, Telescoping Only TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color GLV Galvanized SC Single Circuit DC Dual Circuit 2 lamp only

Voltage

120 277 347 UNV 120-277

Options

AL Aluminum body EML* EMH* DM RSE T8 only 10THD T8 only B_ FH

See key on back cover.

2 1/8 "

1T8* 2T8 † 1T5/HO † 2T5/HO †** *PT8W only † PT5 only **HO N/A on telescoping

Nominal Length

PT5SS/PT8WSS

*Consult factory for fixture lengths less than 4’

3 3/8 "

Our standard shadow-concealing staggered PT8WSS is an innovative, powerful strip light that provides a simple clear, warm light. Low profile in appearance, it has precise staggered lamping with a 6" overlapping system which is a unique telescoping end module to eliminate unsightly socket shadows. PT8WSS is highly configurable with assorted sizing and lamps. It is available in perforated or solid reflectors.

45º

45º 0º

09 229

010 230 SURFACE

SURFACE

The heavy-duty, industrial-strength hero that can light distant surfaces and conquer big, open, well-travelled, industrial spaces that are the backbone of public architecture.

010 231 P3600

232

P1800

238

P1220

234

P5100

240

P1600

236

P6000

242

SURFACE / P3600

010 232

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P3600/P3900

ORDERING MATRIX Series

Lamp Rows

P3614 P3622 P3624 P3633 P3644 1’x4’ 2T8, 3T8 2’x2’ 2T8, 2T8U6 2’x4’ 2T8, 3T8, 4T8, 6T8 3’x3’ 4T8, 6T8 4’x4’ 4T8, 6T8, 8T8

Shielding

Color/Finish

Frame Color

Circuiting Voltage

Mounting

Ceiling System

Options See key on back cover.

PRA Prismatic Acrylic Lens P19A Prismatic Acrylic Lens, pattern 19 WA White Acrylic Diffuser TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color DW Flush Frame (steel) White DB Flush Frame (steel) Black SW Flush Frame (aluminum) White SB Flush Frame (aluminum) Black RW 1/2" Deep Regress Frame (alum) White RB 1/2" Deep Regress Frame (alum) Black MW 1/2" Deep Regress Frame (alum) with Black Reveal SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 SUR Surface Mount - Standard MPCA 48" monopoint mounting cable MPCA 96" monopoint mounting cable SSC Top Swivel stem mount, specify length in inches

P3600 *

*Consult Factory

24"

P3600 is perfect for large, high-traffic retail environments like grocery stores and warehouse retail spaces. An understated rectangular or square luminaire with a C stylish, durable metal body. P3600’s classic shapes make a bold modern architectural statement. Surface or pendant mounted, P3600 offers either a regressed or flat hinge-and-latch doorframe assembly. Its Dtamper resistant screws and optional aluminum body offer even more flexibility.

X1 Exposed T-Bar X3 Hard Ceiling X6 Slot Grid AL EML EMH DM RSE 10THD B_ FH 1PL P3644 only TRS ‘D’ style frame only BSH

45º

45º 0º

010 233

SURFACE / P1220

010 234

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P1220

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding

Color/Finish

Voltage

Mounting

Options See key on back cover.

P1220 Damp P1260 Wet 1T8 2T8 1T5 2T5 02’ 03’ 04’ 06’ 08’ PRA Prismatic Acrylic Lens HPRA High-impact Acrylic Lens, Pattern 12 HL Holophane™ Lens WA White Acrylic Diffuser - Standard HWA High-impact White Acrylic Diffuser TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color 120 277 347 UNV 120-277 SUR Surface Mount - Standard SSC_ Top Swivel Stem Mount, specify length in inches AL EML* EMH* DM RSE † 10THD † B_ FH OCO* OC2C* 2 Lamp Only OCDM* *consult factory † T8 only

P1220 4 1/2 "

*Consult Factory

5 1/8 "

The P1220 is a narrow industrial surface-wrap fixture with a patented scissor-spring latch. This sleek modern luminaire comes with five different lens options and can be surface or stem mounted. Highly efficient, the P1220 has S-Occ,™ Prudential’s control system for small spaces and stairwells in seldom-traveled traffic spots. Our patented light control system keeps lamps off or dimmed to a minimal level of output until motion is detected. A smart luminaire for an efficiency-aware world.

45º

45º 0º

010 235

SURFACE / P1600

010 236

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P1600

ORDERING MATRIX Series

P1600 Damp P1660 Wet

Body Style

1 5 1/8" wide 2 8 7/8" wide 4 13 3/4" wide

Lamp Rows

Nominal Length

Shielding

Color/Finish

Circuiting Voltage

Mounting Options See key on back cover.

5 1/8" 1T8 8 7/8" 2T8, 3T8 13 3/4" 2T8, 3T8, 4T8

P1600 4 1/4 " W

02’ 04’ 08’ PRA Prismatic Acrylic Lens HPRA High-impact Acrylic Lens, Pattern 12 WA White Acrylic Diffuser HWA High-impact White Acrylic Diffuser TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit 2, 3 or 4 lamp only 120 277 347 UNV 120-277

8 7/8 "

The P1600 is a heavy-duty, enclosed rectalinear commercial fixture. This highly versatile wrap around comes in a variety of lens options. The P1600 can be surface or stem mounted, individually or in rows. Highly durable, P1600’s housing is made of 20 gauge cold-rolled steel and can be fabricated from sheet aluminum for corrosive salt environments. This workhorse withstands the wet in the optional wet-label P1660 specification.

SUR Surface Mount - Standard SSC_ Stem Mount, specify length in inches AL EML* EMH* DM RSE 10THD B_ FH GL TRS BSH *4’ minimum fixture length

45º

45º 0º

010 237

SURFACE / P1800

010 238

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P1800

South Region High School #9

RMA Photography

Leo Daly

P1800 ORDERING MATRIX Series Lamp Rows

Nominal Length Shielding Color/Finish

Circuiting Voltage

Mounting Options See key on back cover.

3 5/8 "

P1802 11 /8" P1804 16 1/8" 1

2T8 3T8 P1804 Only 4T8 P1804 Only 04’ 08’ PRA Prismatic Acrylic Lens WA White Acrylic Diffuser TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color

11 1/8 "

P1800 is a slim architectural wrap around luminaire. The P1800 is available in two body styles, a narrow 11 1/⁄8"”and a 16 1/⁄8"”width to accommodate large and small rooms. Lensing options are prismatic or white acrylic. A positive torsion spring latching mechanism gives superior lens-to-body retention. P1800 comes in 4’ to 8’ lengths.

SC Single Circuit DC Dual Circuit 120 277 347 UNV 120-277 SUR Surface Mount - Standard SSC_ Stem Mount, specify length in inches AL EML EMH DM RSE 10THD B_ FH BSH Stem Mount Only

45º

45º 0º

010 239

SURFACE / P5100

010 240

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P5100

ORDERING MATRIX Series Lamp Rows Nominal Length

Shielding

Color/Finish

Circuiting Voltage

Mounting Options See key on back cover.

P5100 Damp P5160 Wet Listed, under covered ceilings 1T8 2T8 02’ 03’ 04’ 06’ 08’ WA White Acrylic Diffuser HWA High-impact White Acrylic Diffuser TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit 2 lamp only 120 277 347 UNV 120-277

P5100 5 1/2 "

010 241

*Consult Factory

5 1/8 "

The heavy-duty P5100 is a surface-mounted wrap around with a radial lens for damp climates. This versatile industrial light is ideal for stairwells, parking structures, and warehouses. Wet-listed companion P5160 is strengthened with tamper resistant screws and an aluminum body. It is a fixture ideally suited for outdoor use under canopies and comes with a classic half-round lens diffuser and a clean architectural appeal.

SUR Surface Mount - Standard SSC_ Stem Mount, specify length in inches AL EML* EMH* DM RSE 10THD B_ FH TRS *4’ minimum fixture length

45º

45º 0º

SURFACE / P6000

010 242

CONTACT PRUDENTIAL LTG.

FIXTURE

Tel. 213.746.0360 / prulite.com

P6000

P6000 5"

ORDERING MATRIX Series Lamp Rows

Nominal Length

Shielding Color/Finish

Circuiting

P6000 1T8 2T8 1T5 2T5 02’ 04’ 08’ PRA Prismatic Acrylic Lens TMW Textured Matte White YGW Gloss White - Standard Y_ Premium Color CC Custom Color SC Single Circuit DC Dual Circuit 2 lamp only

Voltage

120 277 347 UNV 120-277

Options

AL EML* EMH* DM RSE † 10THD † B_ FH RF

See key on back cover.

*4’ minimum fixture length † T8 only

A flexible corner-mounted, square-lensed luminaire, P6000 directs light downward and away from the wall. This dependable surface mount workhorse comes with a linear prismatic acrylic lens that refracts light in an asymmetric pattern. Welded construction housing is painted after fabrication. It safely lights stairwells and corridors for way-finding applications and brightens busy public bathrooms.

45º 0º

010 243

011 244 WET LISTED/CLEAN ROOM

Fixtures that are code compliant, designed thoughtfully, with the public safety in mind. Specification Grade, these products set high standards for reliability, quality, fit and finish.

WET LISTED CLEAN ROOM

WET LISTED

P1260

011 245 P61

P2100

P5460

P1660

P5160

P5360

Quick Find on the web, search P0107.

CLEAN ROOM

PCR2200

PCR3100

WET LISTED

011 246

CONTACT PRUDENTIAL LTG. Tel. 213.746.0360 / prulite.com

WET LISTED These fixtures are exactly right for lighting under canopies, covered walkways and alcoves. Use Prudentialâ€™s P1260 or P5160 here.

011 247

011 248 CLEAN ROOM

011 249

CLEAN ROOM Our specification grade sealed clean room fixtures for use in a hospital or laboratory. Use Prudentialâ€™s PCR2200 or PCR3100 here.

012 250 APPENDIX

See how we can make our fixtures uniquely yours. Get our Strips quick. Add an Occupancy Sensor. Modify or design your own. Paint them to your palette or buy a legacy fixture to match.

APPENDIX

MODIFICATIONS

252

LEGACY

CUSTOM

260

266

QUICK SHIP

CONTROLS

COLORS

264

272

274

012 251

APPENDIX / MODIFICATIONS

LIFE, LIBERTY AND THE PURSUIT OF HAPPINESS

012 252

Like one of our standard products, but want the freedom to pursue your own version of the perfect Prudential luminaire? No problem. We’re happy to help you bring your unique vision to life. Through a process of feasibility study, including volume and price, prototyping, production planning and costing, we can deliver modified standard products that meet your demands and help you achieve the ideal commercial lighting solution. See a quick overview of our process here and call 213.746.0360 to speak with a representative to see if a modification might be the right solution for you.

LIFE

LIBERTY

Life is about fulfilling your vision. Tell us how many and what you need — a unique size or span, more ballasts or a specific mounting design? Or perhaps it’s a distinctive material or finish? Since all of our fixtures are made to order, special orders are seamlessly integrated into our production process.

You want the freedom to explore new solutions. Working with our engineers, you’ll know just how your requested modifications impact performance, safety, durability, and cost. If our design, engineering and manufacturing teams okay the technical feasibility and production costs of your request, then we’ll create a submittal and deliver you a quote.

PHASE 1

RESEARCH

MODIFICATIONS

PURSUIT

HAPPINESS

If you approve the Customer Quotation, we’ll go to work as only Prudential can to make your vision a reality. We’ll execute the details of every aspect of your job, from design and prototyping to production specs and tooling. At this point, we’re ready to start production of your special order.

We know how much getting it right means to you. So our representatives will continue their involvement with your project until we know you’re completely happy—with the fabrication of each fixture, with the installation of each fixture and with the performance of each and every fixture.

DESIGN/PRODUCTION

DELIVERY

012 253

APPENDIX / MODIFICATIONS

012 254

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Bionic

IBM

HOK

012 255

MODIFICATION Intersecting lines of light created with the Bionic make this IBM installation an outstanding achievement.

APPENDIX / MODIFICATIONS

012 256

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Zenith

LPA Inc. San Jose

LPA Inc.

Costea Photography

MODIFICATION Put two Zenith’s together in LPA’s architectural studio and you have a modification that we now sell standard.

012 257

APPENDIX / MODIFICATIONS

012 258

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

Half Snap

TRIS3CT

Gary Lee Partners

012 259

MODIFICATION With our HalfSnap fixture, we gave all new meaning to the word linear in this design studio.

CL: CREATIVE LICENSE

APPENDIX / CUSTOM

It’s something we’ve never forgotten: a customer, by definition, should have the option of a custom solution. Over the last 60 years, Prudential has collaborated with the industry’s best and brightest designers to create Custom Luminaires for thousands of projects all over North America. Now that well-honed skill set is available to you. Collaborate with us to create your own iconic commercial lighting design.

012 260

SKETCH

DEFINE

It starts by understanding you and your project’s needs. Maybe it’s a simple napkin sketch of what you envision or a lighting problem where only a custom designed solution can bring your idea to life. Either way, we’re here to help.

The first things we’ll do is check to see whether we’ve ever made a fixture that matches your request. Then we’ll define the critical factors of feasibility: Volume and Price. Can the fixture you envision be made in quality, and if so at what cost?

IDEAS

REALIZED

CUSTOM LUMINAIRES

012 261

REFINE

DELIVER

A dedicated project manager will usher you through the process. Next, a team from Design, Engineering and Manufacturing studies the production feasibility and pricing. From this comes a Customer Quotation. Once that’s approved, then prototype drawings are prepared for submission.

We’re rolling now: approval of the Design, Prototype, and Specification and Tooling ensure our quality control standards are upheld as we prepare your job for commercial volume production. The final, and most rewarding step? Delivery to the job site, where we’re there and available to consult on installation.

PERFECTED

PRODUCED

APPENDIX / CUSTOM

012 262

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Custom

Pacific Dental HQ

LPA Inc.

Costea Photography

CUSTOM A fixture (CL6597) with independently controlled up and downlight in extruded aluminum for 12â€™, perfectly straight lines.

012 263

APPENDIX / LEGACY

LEGACY

PERIMETER &

012 264

WALL WASH

COVE P82i

P87

MegaCove

P54

P5900

P5500

& STACK

RECESSED

P8000

Visit prulite.com to see the complete line of fixtures that Prudential Ltg. makes. As time passes, our product line evolves. But there are circumstances where a customer must match an older fixtureâ€™s design. We still offer those classic styles and retain the tooling for fulfillment.

Over the years, our passion for the art and science of light has helped us build our reputation for some of the industryâ€™s most iconic designs. These fixtures continue to represent quality, reliability and affordability.

LINEAR

012 265 Pru11

Legend

P10

WalNV

Wal6

P900

P1100

P30

WALL MOUNT Wal10

SURFACE

P1700

012 266 APPENDIX / COLORS

COLORS In scientific terms, Light and Color are practically inseparable: Light waves create Color. At Prudential Ltg, we know how inseparable Color is to creating the environment you envision. Choose from our premium colors below or let us help you find the perfect color for your project. Whether it’s a tone of gray with just the right nuance, a bold bright crimson or countless colors in between, you’ll be able to specify the body of our fixtures in the hue that perfectly captures what you set out to achieve.

YSL Silver

YPE Pewter

YRG Rain Grey RAL 7023*

YST Storm Grey RAL 7024

012 267

YSK Sky RAL 5024

YDU Dusk RAL 5023

YSA Sapphire RAL 5010*

YDA Daffodil RAL 1018*

YSR Sunset Red RAL 3020*

YFG Forest Green RAL 6016*

YSN Sand

YUM Umber RAL 8007

YBR Bronze RAL 6022*

YBB Matte Black RAL 9011*

*Not an RAL Color, closest RAL equivalent — paint chips are available, please e-mail sales@prulite.com • Premium colors available on most Prudential luminaires for a nominal set-up fee. • For other specialty colors, please choose from RAL powder coatings

See prulite.com/colors

APPENDIX / COLORS

012 268

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

P4000

DC Entertainment

Beckson Design Associates

fotoworks

012 269

COLORS Red and Blue, applied to our signature round - the SkyOculus - our most popular fixture for over 40 years.

APPENDIX / COLORS

012 270

COLORS The lime green of the furnishings match the lime green of the fixtures for inspiration at the Parsonâ€™s school. See page 23.

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

Tel. 213.746.0360 / prulite.com

P4000

The Sheila C. Johnson Design Center at Parsons The New School

Rice + Lipka Architects

012 271

CONTROLS

APPENDIX / CONTROLS

We Make it Easy

012 272

Prudential takes the complexity out of meeting tough new energy codes, with our seamlessly integrated standard controls. Choices include R-Occ™ for Room and Row, S-Occ™ for Stairwells and RightLight™ with daylight compensating photocells. If you are looking for something more or different than our standard offering, Prudential is happy to work with you to integrate any state-of-the-art controls solution that best serves your needs. No matter how complex the job, Prudential is here to make it efficient for you and your clients.

012 273

AMPAPDE EN D TO I X O/R Q DE UR I C /K CS O H LI PO R S

BUILT FOR SPEED

010 012 274

We have never been more focused on our role of delivering within a scheduled time frame. Literally every strategic decision we make is aimed at supporting a fast delivery. Thanks to streamlined manufacturing, supply chain management and software integration that allows us to compress the whole purchase process we deliver made-to-order products faster than almost anyone. Our goal is to ship every product you order within 2 to 4 weeks. Better products, better delivery, better experience â€” Prudential Ltg. delivers.

PREMIUM COLORS In scientific terms, Light and Color are practically inseparable: Light waves create Color. At Prudential Ltg, we know how inseparable Color is to creating the environment you envision. That’s where our Premium Colors come in. Whether it’s a tone of gray with just the right nuance, a bold bright crimson or countless colors in between, you’ll be able to specify the body of our fixtures in the hue that perfectly captures what you set out to achieve.

P3900

Snap

HalfSnap

010 012 275

P43

SRP Wal14

210

P1220

234

P1600

236

QUICK SHIP AR

SRR

Contact your Prudential rep for availability and schedules. Because on some jobs, a few days can make all the difference.

APPENDIX / INDEX

012 276

WET W LISTED

SPECIAL APPS

SURFACE

STRIP

WALL MOUNT

LINEAR

RECESSED

WALL WASH & STACK

RECESSED LINEAR

ATTRIBUTES

ARCH WRAP

COVE

PERIMETER

FIXTURE TYPE

SKY OC

INDEX A-Z

Aparia 119 171

•

Bionic 39 89 111 •

•

Cupola1N/1W 133 •

•

Cupola2i 135 •

•

Cupola4i 137 •

•

Ergo 201 •

•

Edge 217

HalfSnap 75 •

•

M5 173

•

M7 179

•

MiniOlympic 185 •

•

MiniCupola 139 •

•

MicroCove 53 •

•

• •

•

Olympic 183 •

•

PCR2200 see prulite.com

•

PCR3100 see prulite.com

•

P1220/P1260 235 •

•

P1600/P1660 237

•

P1800 239

•

P2100 see prulite.com

•

P3600 233 •

•

P3900

25 •

•

P4000

P25 177

23 •

•

P40 151 212 •

•

P42 93 •

•

P43 41 95 115 •

•

P45i 55

•

P46 157 212 •

•

P5100/P5160 241 •

•

P5360 see prulite.com

•

P5460 see prulite.com

•

P5600 121

•

P59 43 •

•

See prulite.com for complete specifications and additional information.

WET W LISTED

SPECIAL APPS

SURFACE

STRIP

WALL MOUNT

LINEAR

RECESSED

WALL WASH & STACK

RECESSED LINEAR

ATTRIBUTES

ARCH WRAP

COVE

PERIMETER

SKY OC

FIXTURE TYPE

P6000 243

•

P60 159 213 •

•

P61 see prulite.com •

•

P62 101 •

•

P63 103 •

•

P69 161 213 •

•

P80i 51

•

P83 49 •

•

P8600 143 •

•

P8900

31 127 •

•

P9000

29 125 •

•

P9200 141 •

•

Pru7 181

•

Pru9 193

•

Pru15 167 •

•

PT5/PT8/PT8W 227

•

PT5SS/PT8WSS 229

•

Pulse 147

•

Snap 67 117 •

•

Strand 77 205

•

String 219

•

SuperCove 57

•

Pru5 175

•

Twist 223

•

Vader 195

•

Wal Aparia 207 •

•

Wal14 209 •

•

Wal8 211 •

•

WalWave 203 •

•

Wave 165 •

•

Wave2 163 •

•

Wing11/14 129 •

•

Wing22/24 131 •

•

Zenith 63 •

•

LED

>80% Efficiency

Fusion Optics

Controls

Seamless

Wet Listed

•

012 277

•

GLOSSARY Aperture The diameter in the opening of a downlight, in inches (in.). Sometimes manufacturers will round up to the next whole-inch increment.

APPENDIX / GLOSSARY

Ballast A device required by electricdischarge light sources such as fluorescent or HID lamps to regulate voltage and current supplied to the lamp during start and throughout operation. Candela The Systeme International d’Unities (SI) of luminous intensity. One candela is one lumen per steradian. Formerly, candle. Cutoff angle The angle of light distribution from a luminaire, measured upward from nadir, between the vertical axis and the first line at which the bare source (lamp) is not visible. Direct luminaire A luminaire that emits light in the general direction of the task to be illuminated. The term usually refers to luminaires that emit light in a downward direction.

Driver For light emitting diodes, a device that regulates the voltage and current powering the source. Efficacy The ratio of light output (in lumens) to input power (in watts), expressed aslumens per watt (LPW). ALSO: The ratio of the light output of a lamp (lumens) to its active power (watts), expressed as lumens per watt. Field of view The area covered by an occupancy sensor, often reported (for wall-mounted sensors) as a horizontal field of view or (for ceiling-mounted sensors) as the solid angle of the cone-shaped coverage area. Fixture A complete lighting unit consisting of lamp or lamps and the parts designed to distribute the light, position and protect the lamp(s), and connect the lamp(s) to the power supply. (Also referred to as luminaire.) Footcandle (fc) A measure of illuminance in lumens per square foot. One footcandle

equals 10.76 lux, although for convenience 10 lux commonly is used as the equivalent. Heat sinking Adding a material, usually metal, adjacent to an object in order to cool it through conduction. Indirect lighting Light arriving at a surface after reflecting from one or more surfaces (usually walls and/or ceilings) that are not part of the luminaire. Kelvin Color temperature is measured in degrees Kelvin, which indicathe hue of a specific type of light source. Higher temperatures indicate whiter, “cooler" colors, while lower temperatures indicate yellower, “warmer" colors. Louver A fixed shield, usually divided into small cells, that is attached to the face of a luminaire to reduce direct glare. Lumen (lm) A unit measurement of the rate

012 278

CONTACT PRUDENTIAL LTG.

FIXTURE

CLIENT

ARCHITECT

PHOTOGRAPHER

Tel. 213.746.0360 / prulite.com

Strand

Commerce House

Perkins + Will

Charles Davis Smith

at which a lamp produces light. A lamp’s light output rating expresses the total amount of light emitted in all directions per unit time. Ratings of initial light output provided by manufacturers express the total light output after 100 hours of operation. Luminance The photometric quantity most closely associated with the perception of brightness, measured in units of luminous intensity (candelas) per unit area (square feet or square meter). Lux (lx) A measure of illuminance in lumens per square meter. One lux equals 0.093 footcandle. Nadir In the lighting discipline, nadir is the angle pointing directly downward from the luminaire, or 0°. Nadir is opposite the zenith. PN junction For light emitting diodes, the portion of the device where positive and negative charges combine to produce light.

Prismatic lens An optical component of a luminaire that is used to distribute the emitted light. It is usually a sheet of plastic with a pattern of pyramid-shaped refracting prisms on one side. Most ceiling-mounted luminaires in commercial buildings use prismatic lenses. Reflectance A measure of the ability of an object to reflect or absorb light, expressed as a unitless value between 0 and 1. A perfectly dark object has a reflectance of 0, and a perfectly white object has a reflectance of 1. Shielding Blocking an electric or magnetic field with a metallic substance. The incident field induces currents in the metallic substance, and these currents induce a field that opposes the incident field. Shielding reduces radiated electromagnetic waves. Electronic components, wires, lamps, and devices can all be shielded. Specular reflection Light incident on a surface

that is redirected at the specular angle. Glossy or shiny surfaces exhibit a high degree of specular reflection. Supply voltage The voltage, usually direct, applied by an external source to the circuit of an electrode. Uplight Light directed upward at greater than 90° above nadir. The source of uplight can be from a combination of direct uplight and reflected light. Wall-washing The practice of illuminating vertical surfaces, such as walls. Wall-washer luminaries are designed to illuminate vertical surfaces. Zenith In the lighting discipline, zenith is the angle pointing directly upward from the luminaire, or 180°. Zenith is opposite nadir. In astronomical usage, zenith is the highest point in the sky, directly above the observation point.

012 279

For additional glossary terms and more, visit lrc.rpi.edu. The Lighting Research Center is the world’s leading university-based research and education organization devoted to lighting—from technologies to applications and energy use, from design to health and vision.

Light creates Life. Create with Prudential Ltg.

Strand

280

basis series

As seen in Form.

In simplicity lies creativity and freedom. So in response to demand for this basic and popular fixture of lighting, we have created a series of five mini-stripsâ€”our Basis line. Solidly constructed, brilliantly fundamental, the Basis for so much more. See them all at prulite.com/basis. Light creates Life. Create with Prudential Ltg.

OPTIONS KEY 1PL

One piece lens (P8644 only)

EBCP2G

1SS

1 side shield

EML Emergency battery (600-700 lumens)

10THD Ballast with < 10% total harmonic distortion (T8 only) 2SB Double side-mounted ballast

Electrical box 2 gang

EMH Emergency battery (1100-1400 lumens)

2SS

2 side shields

20G

20-gauge housing

IBC

ADC

Acrylic dust cover

ADS

Acrylic dust shield

Aluminum body

INTC Sense Integrated Controls for Classrooms. See supplemental information to specify

ALH

Aluminum inner housing

INTCW Integrates with Sense System as whiteboard luminaire

Antimicrobial paint

Adjustable mounting plate

AMP

B Specific ballast, specify manufacturer and catalog number BSH Longitudinal body sway hanger (stem-mounting only)

End connector

Straight connector

C2 90 degrees 2-way mitered connector

90 degrees 3-way mitered

C4 90 degrees 4-way mitered connector

Fixture fusing (slow blow) Gasketed lens Insulated braided cord

Low temperature ballast Master remote with 11’ whip

MSD

Hanger hooks

NSS

Non-staggered system

OC2C S-Occ one lamp sensored, one lamp on constantly OCO R-Occ Integrated Occupancy System all lamps off/on, (SQ body style only) OCDM R-Occ dim to standby mode, (SQ body style only) PAF

Painted after fabrication

PRG

Programmed start ballast

PS2

Rotary on/off switch

45 degrees mitered connector

45 degrees corner

CA96

PS4 4-way switch (on/off/ direct/indirect)

96” cable length

CA144

144” cable length

Specify cable length

CHJ

Chain hanger joiner

REP Reflector end plates (two per row will be supplied when row-mounting is specified)

Continuous -row installation

Special connector

Quick connect assemblies

Radio frequency filter

RSE

Rapid-start electronic (T8 only)

Side-mounted ballast

DLH RightLight daylight harvesting system, specify number of sensors per row

Single piece lens

T50PT

Dimming (consult factory)

EBCP1G

Electrical box single gang

WBC White ballast cover (for increased luminaire efficiency)

Dual circuit (2 lamp only)

TRS

T5/HO optimized fixture lengths Tamper resistant screws

LED

>80% Efficiency

Fusion Optics

Controls

Seamless

1774 East 21st Street, Los Angeles, CA 90058 TEL 213.746.0360 / FAX 213.741.8590 Moth Branding and Design Ad Agency Los Angeles, CA mothbranding.com

352 7th Avenue, 7th Floor, New York, NY 10001 TEL 908.658.4231 URL

prulite.com / EMAIL info@prulite.com

Wet Listed

281
