4 Thermodynamics 4.2 Heat, Work, and the First Law of Thermodynamics
Heat capacity of gases with Cobra3
P2320211
Volume change V as a function of the heat-up time t. U = 4.59 V, I = 0.43 A.
Principle Heat is added to a gas in a glass vessel by an electric heater which is switched on briefly. The temperature increase results in a pressure increase, which is measured with a manometer. Under isobaric conditions a temperature increase results in a volume dilatation, which can be read from a gas syringe. The molar heat capacities CV and Cp are calculated from the pressure or volume change.
Heat capacity of gases P2320201
Cobra4 Experiments - available 2013
Tasks 1. Determine the molar heat capacities of air at constant volume CV and at constant pressure Cp.
Heat capacity of gases with Cobra4 P2320260
What you can learn about ▪ ▪ ▪ ▪ ▪
Related Experiment
Equation of state for ideal gases 1st law of thermodynamics Universal gas constant Degree of freedom, Mole volumes Isobars, Isotherms, Isochors and adiabatic changes of slate
Main articles Cobra3 BASIC-UNIT, USB Precision manometer Weather station, wireless Cobra3 current probe 6A Mariotte flask, 10 l Tripod base PHYWE On/off switch Power supply 12V / 2A Software Cobra3 Universal recorder Stopcock,3-way,t-sh.,capil.,glass
12150-50 03091-00 04854-00 12126-00 02629-00 02002-55 06034-01 12151-99 14504-61 36732-00
1 1 1 1 1 1 1 1 1 1
PHYWE Systeme GmbH & Co. KG · www.phywe.com 85
