Coll-O-Crimp
HYDRAULIC HOSE
Hose End 'U' Series
'U' Series
Fittings for use with hose: 3130 (-04 to -12), 37AL (-06 & -08), 3740
Note: Refer to current price list for availability of cataloged items. Configurations and dimensions subject to change without notice.
AIR & WATER HOSE & Tubing
Ordering Information: Order individually by part number. O-rings not supplied with flange hose ends. Order o-rings by catalog number; reference individual listings for details. Refer to important safety information on pages 3.
tRUCK Hose
Application: General purpose low, medium, and high pressure hydraulic. Compatible Hose: 3130 (-04 to -12), 37AL (-06 & -08), 3740 Pressure: Determined by maximum operating pressure for hose size and hose end configuration whichever is lesser.
AEROQUIP/POLYON FITTINGS
Collet
AEROQUIP/TTC FITTINGS
Male Pipe Rigid A
SYNFLEX Fittings
E
Material: Low carbon steel Plating: Zinc; clear trivalent chromate Advantages: Wide selection of hose and end configurations allowing a diverse number of applications. An ideal series to introduce hydraulics. Assemble With: Weatherhead customers use T400-1, T410-1, T-420-1, T-440, T-460, T-462, T-465, T-480, ET1000, ET4000, ET4001, and ET4020. Aeroquip customers use ET1000. Label Set: FS-1100 ‘U’ Series fittings are available to Aeroquip customers for use on select Eaton Synflex hose.
WEATHERHEAD (U & Z SERIES) FITTINGS ASSEMBLY EQUIPMENT & Information
Hose Pipe Part Thread I.D. Size Number Size A
Hose Cut-Off Hole Hex Factor Dia. E
1/4 1/4 1/4 1/4 3/8 3/8 3/8 1/2 1/2 1/2 1/2 3/4 3/4 3/4 1 1
.75 .94 1.00 1.06 1.00 1.00 1.25 .88 1.14 1.31 1.28 1.44 1.44 1.69 1.88 1.69
1/8 1/4 3/8 1/2 1/4 3/8 1/2 1/4 3/8 1/2 3/4 1/2 3/4 1 3/4 1
04U-102 04U-104 04U-106 04U-108 06U-104 06U-106 06U-108 08U-104 08U-106 08U-108 08U-112 12U-108 12U-112 12U-116 16U-112 16U-116
1/8-27 1/4-18 3/8-18 1/2-14 1/4-18 3/8-18 1/2-14 1/4-18 3/8-18 1/2-14 3/4-14 1/2-14 3/4-14 1–11-1/2 3/4-14 1–11-1/2
2.31 2.49 2.52 2.77 2.52 2.52 2.77 2.56 2.57 2.75 2.83 3.62 3.61 3.84 4.23 3.90
.16 .16 .16 .16 .25 .25 .25 .28 .36 .36 .36 .61 .61 .61 .81 .81
9/16 9/16 11/16 7/8 11/16 11/16 7/8 13/16 3/4 13/16 1-1/16 1 1-1/16 1-3/8 1-1/4 1-3/8
Technical data
See pages H12-15 for die, pusher, and cage information. Weatherhead ‘U’ Series fittings available for Aeroquip and Synflex customers.
