Hydraulic Fittings
SAE / JIC Fittings male SAE screw thread x male SAE screw thread Male SAE Screw
Male SAE Screw
7/16"-20 9/16"-18 3/4"-16 3/4"-16 7/8"-14 7/8"-14 1-1/16"-12 1-1/16"-12 1-1/16"-12 1-5/16"-12 1-5/16"-12 1-5/8"-12 1-7/8"-12
7/16"-20 9/16"-18 7/16"-20 3/4"-16 3/4"-16 7/8"-14 3/4"-16 7/8"-14 1-1/16"-12 1-1/16"-12 1-5/16"-12 1-5/8"-12 1-7/8"-12
Zinc Plated Steel Part # 1204-04-04 1204-06-06 1204-08-04 1204-08-08 1204-10-08 1204-10-10 1204-12-08 1204-12-10 1204-12-12 1204-16-12 1204-16-16 1204-20-20 1204-24-24
PSI 5000 5000 4500 4500 3500 3500 3500 3500 3500 3000 3000 2500 2000
Price/E $1.20 1.60 3.15 2.35 3.80 4.05 5.05 4.95 4.15 9.05 7.55 11.00 20.00
male 37° flare x male NPTF
L
Male 37° Flare
Male NPTF
PSI
7/16"-20 7/16"-20 7/16"-20 7/16"-20 1/2"-20 9/16"-18 9/16"-18 9/16"-18 9/16"-18 3/4"-16 3/4"-16 3/4"-16 3/4"-16 7/8"-14 7/8"-14 1-1/16"-12 1-1/16"-12 1-1/16"-12 1-5/16"-12 1-5/16"-12 1-5/8"-12 1-7/8"-12 2-1/2"-12
⅛"-27 ¼"-18 ⅜"-18 ½"-18 ⅛"-27 ⅛"-27 ¼"-18 ⅜"-18 ½"-14 ¼"-18 ⅜"-18 ½"-14 ¾"-14 ½"-14 ¾"-14 ½"-14 ¾"-14 1"-11½ ¾"-14 1"-11½ 1¼"-11½ 1½"-11½ 2"-11½
4500 4500 4000 3000 4000 4000 4000 4000 3000 4000 4000 3000 2500 3000 2500 3000 2500 2000 2500 2000 1150 1000 1000
Zinc Plated Steel Part # 2404-4-2 2404-4-4 2404-4-6 2404-4-8 2404-5-2 2404-6-2 2404-6-4 2404-6-6 2404-6-8 2404-8-4 2404-8-6 2404-8-8 2404-8-12 2404-10-8 2404-10-12 2404-12-8 2404-12-12 2404-12-16 2404-16-12 2404-16-16 2404-20-20 2404-24-24 2404-32-32
Price/E $1.20 1.55 2.05 4.95 2.10 1.75 1.55 2.10 2.45 2.25 2.25 2.55 4.20 2.75 4.05 5.35 4.20 6.15 8.80 6.25 9.00 15.70 39.50
316 Stainless Steel Part # --SS2404-4-4 ----------SS2404-6-6 ------SS2404-8-8 --------SS2404-12-12 ----SS2404-16-16 -------
Price/E --$15.10 ----------22.00 ------23.50 --------52.00 ----65.00 -------
male 37° flare x female NPTF
396
Male 37° Flare
Female NPTF
PSI
7/16"-20 7/16"-20 9/16"-18 9/16"-18 9/16"-18 3/4"-16 3/4"-16 3/4"-16 7/8"-14 1-1/16"-12 1-1/16"-12 1-5/16"-12 1-5/8"-12
⅛"-27 ¼"-18 ¼"-18 ⅜"-18 ½"-14 ⅜"-18 ½"-14 ¾"-14 ½"-14 ¾"-14 1"-11½ 1"-11½ 1¼"-11½
4500 4500 4000 4000 3000 4000 3000 2500 3000 2500 2000 2000 1150
Zinc Plated Steel Part # 2405-4-2 2405-4-4 2405-6-4 2405-6-6 2405-6-8 2405-8-6 2405-8-8 2405-8-12 2405-10-8 2405-12-12 2405-12-16 2405-16-16 2405-20-20
