Industrial Hydraulic Quick-Connect Couplings Features: • poppet style shut-off valves in both coupler and plug • designed to prevent fluid loss when disconnected • meets dimensional requirements of Series B in ISO 7241-1 • interchangeable with Parker-Hannifin 60 series, see Hydraulic Profile Chart on page 833
• Buna-N seal • Contact Dixon if you intend to use the fittings on a compressed air system.
Poppet Valve Couplers Female NPTF ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½ ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½ ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½
Body Size ¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1"
PSI at 70°F 5000 4000 4000 2500 2000 1000 1000 1000 1000 1000 2000 1500 1500 1500 1000
Material
Part #
Price/E
steel steel steel steel steel brass brass brass brass brass 303 stainless 303 stainless 303 stainless 303 stainless 303 stainless
16-263 16-363 16-463 16-663 16-863 B16-263 B16-363 B16-463 B16-663 B16-863 SS16-263 SS16-363 SS16-463 SS16-663 SS16-863
$29.75 37.00 53.00 81.00 108.00 32.50 44.00 64.00 97.00 134.00 74.00 116.50 184.50 228.95 367.00
Material
Part #
Price/E
steel steel steel steel steel brass brass brass brass brass 303 stainless 303 stainless 303 stainless 303 stainless 303 stainless
17-263 17-363 17-463 17-663 17-863 B17-263 B17-363 B17-463 B17-663 B17-863 SS17-263 SS17-363 SS17-463 SS17-663 SS17-863
$12.50 16.90 22.00 33.00 45.00 14.10 19.30 22.80 35.50 46.75 30.50 46.00 57.70 105.75 190.00
Opt Qty 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Poppet Valve Plugs Female NPTF ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½ ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½ ¼" - 18 ⅜" - 18 ½" - 14 ¾" - 14 1" - 11½
Body Size ¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1"
L
PSI at 70°F 5000 4000 4000 2500 2000 1000 1000 1000 1000 1000 2000 1500 1500 1500 1000
Opt Qty 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Dust Plugs Body Size
Material
Part #
Price/E
¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1"
rubber rubber rubber rubber rubber aluminum aluminum aluminum aluminum aluminum
16-002 16-003 16-004 16-006 16-008 16-002A 16-003A 16-004A 16-006A 16-008A
$3.75 4.40 4.85 8.45 10.50 13.75 15.40 18.00 25.75 70.00
Opt Qty 5 5 5 5 5 5 5 5 5 5
Dust Caps
378
Body Size
Material
Part #
Price/E
¼" ⅜" ½" ¾" 1" ¼" ⅜" ½" ¾" 1"
rubber rubber rubber rubber rubber aluminum aluminum aluminum aluminum aluminum
17-002 17-003 17-004 17-006 17-008 17-002A 17-003A 17-004A 17-006A 17-008A
$3.75 4.30 4.60 9.60 9.80 14.60 16.10 21.50 28.75 77.00
