2.00mm (.079") Pitch Wire-to-Board Header
2.00 to 2.50mm (.079 to .098") Pitch PCB and Wire Connectors
C
Features and Benefits • Sizes 2 to 15 circuits • Internal push-type positive lock provides secure retention, polarization and easy mating/unmating • Potting type used for sealing components in white goods applications • Polarization pegs assist placement
55487 Vertical Fully Shrouded
Reference Information Product Specification: PS-51216-007 Packaging: Tray Mates With: 51216 Designed In: Millimeters
Circuits 2 3 4 5 6 7 8
Order No. 55487-0219 55487-0319 55487-0419 55487-0519 55487-0619 55487-0719 55487-0819
Lead-free
Yes
Electrical Voltage: 250V max. Current: 2.5A max. Contact Resistance: 20 milliohms max. Dielectric Withstanding Voltage: 1000V AC/1 min. Insulation Resistance: 1000 Megohms min. Physical Housing: Nylon, UL 94V-0 Contact: Brass Plating: T in over Copper
Circuits 9 10 11 12 13 14 15
Order No. 55487-0919 55487-1019 55487-1119 55487-1219 55487-1319 55487-1419 55487-1519
Lead-free
Yes
www.molex.com/customer.html?seriesNumber=55487
2.00mm (.079") Pitch Board-In Connector Crimp Terminal
Features and Benefits • Locking tang secures terminal to housing Reference Information Use With: 51015 Designed In: Millimeters
50034
Order No. 50034-8000 50034-8100
C-38
MX10
Electrical Voltage: 125V max. Current: AWG
26 2.0A
28 1.5A
30 1.0A
Physical Contact: Phosphor Bronze Plating: Tin Wire Range: 26 to 30 AWG Insulation Range: 1.40mm dia. max. Strip Length: 1.40 to 1.90mm
Packaging Reel Bag
Lead-free Yes
www.molex.com/product/board_in.html
