GET CONTROL!
Lighting Control: What’s in the New Title 24? By CRAIG DILOUIE, LC, CLCP On January 1, 2023, the 2022 version of California’s energy code—Title 24, Part 6 of the Building Standards Code—takes effect, superseding the previous 2019 version. In terms of lighting controls, the numerous changes include various clarifications and tuning along with two major provisions requiring occupant-sensing in offices larger than 250 sq.ft. and demand-responsive lighting controls. Designers and specifiers need to understand these changes before they begin working on code-covered new construction and alteration projects that will go out for permit in California in 2023. Commercial building energy codes regulate the design energy efficiency of nonresidential buildings. A majority of states adopt model codes and standards, but California developed its own. Generally updated every three years since 1995, this energy code is progressive, often leading the nation in energy-saving measures. It is also well enforced via the permit application process at local building departments. This article highlights two major changes to Title 24, Part 6 related to lighting controls in its 2022 version, which is likely to remain in effect until at least December 31, 2025. For detailed information on all changes, consult the code.
Title 24 and lighting controls Title 24, Part 6 allows either a prescriptive (compliance within a set of choices or restrictions) or performance (building modeling using software) compliance path. Both feature lighting provisions that are mandatory, the large majority of these related to installation of interior and exterior lighting controls. Required lighting controls include manual area, multilevel, automatic shutoff, automatic daylighting, and demandresponsive controls. These are broken out as interior lighting controls (Section 130.1) and exterior lighting controls (130.2). Three other relevant sections include demand response (Section 110.12), acceptance testing requirements for installed lighting controls (Section 130.4), and acceptance testing procedures (Nonresidential Appendix 7.6, 7.7.5.2, and 7.8). The 2022 version of Title 24, Part 6 contains numerous changes to its lighting sections, notably updates for outdoor lighting zones, updates to the nonresidential lighting power allowance tables, changes to demand response, and new requirements for occupancy sensing for office spaces (in addition to clarification for occupancy sensors used with HVAC), along with numerous revisions for clarity and consistency. Additionally, there are now mandatory requirements for some buildings to include photovoltaics and battery storage, and multifamily buildings were given their own code sections as an application, which added significantly to the body of the code.
42
designing lighting
Occupant sensing in offices Occupant-sensing controls are required in certain spaces such as offices 250 sq.ft. or smaller, while in others, they present an option to comply with automatic lighting shutoff requirements. These devices automatically turn Off lighting when the area is unoccupied. The device may also be designed to automatically turn On lighting. The 2022 version of Title 24, Part 6 now requires occupant sensors control the general lighting in offices larger than 250 sq.ft. and requires that each sensor be configured in a control zone no larger than 600 sq.ft. These requirements are similar to provisions in both the 2018 and 2021 versions of the International Energy Conservation Code. Note that undershelf and furniture-mounted task lighting controlled by a local switch and either a time switch or occupant sensor are exempted. Here’s how it works: 1.
Upon detecting occupancy, the sensor may automatically turn the zone’s lighting On to any level up to full power.
