MIDSHIP MOUNTED PUMPS Darley offers both manifolded and non-manifolded midship pumps with ratings from 500 to 3500 gpm.
KHM PUMPS The KHM series pumps have been a best seller for almost 30 years. These high performance compact pumps are rated at 250, 350 and 500 gpm @ 150 psi.
LSM PUMPS The LSM pump is a lightweight, high flow Miship mounted pump with ratings from 500-1000 gpm and excess capacity with flows over 1250 gpm. The LSM utilizes the same compact high efficiency volute as our popular LDM and is also available with a high pressure booster pump or CAFS.
PUMP
PAGE
KHM 500
52
LSM 500, 750, 1000
52
PSM 1000, 1250, 1500
53
LDM 1000, 1250, 1500, 1750
54
LDMH 1000, 1250, 1500, 1750
55
LDMX 1000, 1250, 1500, 1750
55
EM 1000, 1250, 1500, 1750, 2000
56
ZSM 2500, 3000, 3500
56
MIDSHIP
PSM PUMPS The PSM is an ideal solution for economical pumpers and tankers due to reduced installation cost, while offering pump and roll capability. Its compact design means less space and weight on the vehicle. Rated at 1000, 1250, 1500 @ 150 psi.
LDM PUMPS Our flagship midship mounted pump. Double suction design allows for highly efficient operation and a compact design. Thousands are in service. Ratings from 1000 - 1750 gpm @ 150 psi.
EM PUMPS The EM pump is Darley’s two stage midship pump with standard ratings from 1000 – 2000 gpm and with series flow pressure to 600 psi.
LDM MIDSHIP SINGLE STAGE PUMP NFPA RATINGS 1000-1250-1500-1750 GPM
ZSM PUMPS The ZSM is the highest flowing Midship pump on the market with ratings from 2500-3500 gpm in a compact package. Features the new Darley MagnaTrans™ which incorporates the option of a belt driven primer and a larger driveline drop for additional applications. The ZSM design is capable of significant excess capacity for applications where larger engines are utilized.
1
2
FEATURES THAT SET DARLEY PUMPS APART 1. Discharge check valve allows priming with discharge valves open for rapid water deployment
3
2. Self locking discharge valves 3. Bronze vacuum cast impeller
4
4. Powder coated gear case interiors 5. MagnaTrans™ gearbox with a 19,230 ft. lb. rating, helical cut gears, AutoCool, and chamfered sliding clutch
5
6
6. Dipstick on larger models for easy oil level checking 7. Injection Packing allows the pump to be repacked in minutes 8. Mechanical Seal is made with a silicon carbide stationary face
