Managing and suppressing POP’s in your waste stream

Page 1


Jetstream Dust

Control for Shredder

The Jetstream range consists of powerful, singular nozzles that are powered by high-capacity air flow.

Jetstream systems are a solution installed at the source of the problem. Using powerful jets of fine mist, they effectively control dust as it is produced by the shredder.

Jetstream systems are built bespoke to each HAAS unit and are compatible with the HAAS static and mobile shredder range.

The Jetstream Smartech is an intelligently controlled, compressed air misting system, giving the ability to supply and control multiple nozzles in multiple zones using the latest in PCB technology Featuring an advanced 7-day timer and optional remote options which can be triggered from an external remote source such as a remote control, and SMS activation. The control panel uses our latest controller providing the user with a simple colour screen interface allowing simple selection of zones and timers.

The Jetstream Smartech is powered by compressed air, water, and mains electricity supply which is provided in an all-in-one skid unit to accompany the shredder. The Atomising nozzles utilized in the system are machined from Stainless steel to provide durability and precision. Each nozzle can be adjusted to provide as little or as much suppression as required on the nozzle itself.

FEATURES

Jetstream Smartech system nozzles on hopper
Jetstream Smartech system nozzles on exit
Jetstream Smartech system nozzle and skid power system

Jetstream Dust Control for

Shredder

Standard configurations have between 8-10 nozzles run by 1 Jetstream Smartech control panel which is located on a skid frame located close to the unit. Further nozzle configurations and additional nozzles are possible but will require a bespoke installation.

System requirements (included on skid power unitfor information purposes only)

Power can also be provided separately by site if suitable

• Air supply – 10bar @ 6m3/hr -8mm od. (min requirement)

• Water Supply – 4–6 bar potable mains supply 22mm mdpe

• Power Supply – 230v 16amp

• Droplet Size – 15-50 micron user adjustable

• Water Consumption – Per nozzle from 2lph up to 5.5lph

Jetstream Smartech system control panel
Jetstream Smartech system on HAAS shredder
Jetstream Smartech system on HAAS shredder
