WXS-HS-EBD
d
D
d1
Milling | Solid carbide
l
R
l1 L
Carbide end mill with WXS coating For hardened steels up to 65 HRC and stainless steels 2 flutes, shorter overall length, ball nose
○ ◉
~45 HRC
CARBIDE
P
○ ◉
M
◉
K
◉
~55 HRC
~35 HRC
~350 HB
WXS
30˚
FIT
SHRINK
S
○
H
◉
~60 HRC
R
± 0.005 1≥R
H
○
~65 HRC
R
± 0.007 1<R≤6
C.899
EDP
Z
D
R
l1
L
l
d1
d
3041710 3041720 3041730 3041740 3041750 3041760 3041780 3041800 3041820
2 2 2 2 2 2 2 2 2
1 2 3 4 5 6 8 10 12
0,5 1 1,5 2 2,5 3 4 5 6
2 4 6 8 10 -
40 40 50 50 50 50 60 70 80
1 2 3 4 5 9 12 15 18
0,95 1,95 2,85 3,85 4,85 -
4 6 6 6 6 6 8 10 12
Milling | Solid carbide
P
C 677
