PXNL OH HEADS NEW
D
D1
Milling | Indexables
R
l l1
Variable helix solid carbide head with coolant hole Roughing shape in 45 HRC work materials
L
For PXMZ straight shank holder 12 - 25 mm
EDP
Heads
Milling | Indexables
7830411 7830412 7830413 7830414
C 856
Designation PXNL120C12-04C005-O PXNL160C16-04C006-O PXNL200C20-04C006-O PXNL250C25-04C006-O
Z 4 4 4 4
D1 12 16 20 25
R 0,5 0,6 0,6 0,6
l 8,4 11,2 14 17,5
l1 14,4 18,7 21,5 27,5
D 11,7 15,7 19,6 24
Helix angle 19/21 19/21 19/21 19/21
P
Grade XP3225 XP3225 XP3225 XP3225
dry ◉ ◉ ◉ ◉
M
K
dry
GG GGG dry ◉ ◉ ◉ ◉
◉ ◉ ◉ ◉
C.865
C.982
S
H
N dry
dry ◎ ◎ ◎ ◎
◎ ◎ ◎ ◎
