STANDARD TOOLHOLDERS AND ACCESSORIES
COLLETS ER TYPE
ER TYP SPANNZANGEN PINZE TIPO ER PINZAS TIPO ER PINCES TYPE ER НАБОРЫ ЦАНГ ER ER 类型的夹头 DIN6499/ISO15488
RUNOUT≤ 0,010
TYPE
NEW
NEW
NEW
NEW
NEW
NEW
D
L
CLAMPLING CAPACITY
ER8D.. ER11D.. ER11 ERW
8.5 11.5 11.5
13.5 18 15
ER16D..
17
1÷5 1÷7 7,5 / 8 1÷3 4÷10 10,5 11 / 11,5 12 1÷3 4÷13 13,5 / 14 14,5 / 15 1÷3 4÷16 16,5 / 17 / 17,5 18 18,5 / 19 19,5 / 20 2÷20 20,5 / 21 / 21,5 / 22 / 22,5 23 / 23,5 24 24,5 25 3÷30 31 32 6÷34
27.5
ER16 ERW
17
26 21,7 20
ER20D..
21
31.5
ER20 ERW
21
29 25,5
ER25D..
26
34.5
ER25 ERW
26
ER32D..
33
ER32 ERW
33
ER40D..
41
ER40 ERW
41
ER50D..
52
34 33 31 28 40 40 39 37,5 35,7 34 46 43 39,5 60
CLAMPING RANGE
DIN
mm 0,5 mm 0,5 mm 0,5 mm 0,5 mm 1,0
4004E 4008E OVERSIZE
mm 0,5
OVERSIZE
mm 0,5 mm 1,0
428E
mm 0,5
OVERSIZE
mm 0,5 mm 1,0
430E
mm 0,5
OVERSIZE
mm 1,0
470E
mm 0,5
OVERSIZE
mm 1,0
472E
mm 1
OVERSIZE
mm 2,0
477E
426E
ER COLLET SETS
ER - SPANNZANGENSATZ SERIE PINZE TIPO ER JUEGO DE PINZAS TIPO ER JEUX DE PINCES TYPE ER НАБОРЫ ЦАНГ ER ER 夹头组套 RUNOUT≤ 0,010
TYPE
NUMBER OF COLLETS
SERIE-ER8 SERIE-ER11 SERIE-ER16 SERIE-ER20 SERIE-ER25 SERIE-ER32 SERIE-ER40
(1÷5) 9 collets (1÷7) 13 collets (1÷10) 10 collets (2÷13) 12 collets (2÷16) 15 collets (3÷20) 18 collets (4÷26) 23 collets
SERIE-ER40C
(3÷30) 28 collets
CLAMPING CAPACITY Ø 1-1,5-2-2,5-3-3,5-4-4,5-5 Ø 1-1,5-2-2,5-3-3,5-4-4,5-5-5,5-6-6,5-7 Ø 1-2-3-4-5-6-7-8-9-10 Ø 2-3-4-5-6-7-8-9-10-11-12-13 Ø 2-3-4-5-6-7-8-9-10-11-12-13-14-15-16 Ø 3-4-5-6-7-8-9-10-11-12-13-14-15-16-17-18-19-20 Ø 4-5-6-7-8-9-10-11-12-13-14-15-16-17-18-19-20 21-22-23-24-25-26 Ø 3-4-5-6-7-8-9-10-11-12-13-14-15-16-17-18-19-20 21-22-23-24-25-26-27-28-29-30
