Sumi Dual Mill
DMSL 06000 M Type Rake angle
Radial -12,5° to -16,5° -8° Axial
1,5mm
Modular Type
17° Fig 1
+
'&6)06
'&21
&5.6
'&
'&;
/
/6
/) 2$/
Head Cat. No. DMSL 06016M08Z2 06018M08Z2 06020M10Z3 06020M10Z4 06022M10Z3 06022M10Z4 06025M12Z4 06025M12Z5 06026M12Z4 06028M12Z4 06028M12Z5 06030M16Z5 06032M16Z5 06032M16Z6 06035M16Z5 06040M16Z6 06042M16Z6
Stock
Dimensions (mm)
DCX
DC
l
16 18 20 20 22 22 25 25 26 28 28 30 32 32 35 40 42
8,4 10,4 12,4 12,4 14,3 14,3 17,3 17,3 18,3 20,3 20,3 22,3 24,3 24,3 27,3 32,3 34,3
m
l l m m
l l l l l m
l l l
Inserts are sold seperately.
Parts
14,5 14,5 18 18 18 18 22 22 22 22 22 28,5 28,5 28,5 28,5 28,5 28,5
8,5 8,5 10,5 10,5 10,5 10,5 12,5 12,5 12,5 12,5 12,5 17 17 17 17 17 17
CRKS
OAL
LF
LS2
L11
H
M8 M8 M10 M10 M10 M10 M12 M12 M12 M12 M12 M16 M16 M16 M16 M16 M16
42 42 49 49 49 49 56 56 56 56 56 63 63 63 63 63 63
25 25 30 30 30 30 35 35 35 35 35 40 40 40 40 40 40
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
8 8 10 10 10 10 11 11 11 11 11 12 12 12 12 12 12
13 13 15 15 15 15 19 19 19 19 19 24 24 24 24 24 24
Identification Details
Insert screw
BFTX02507IP
DCSFMS DCON
Wrench
2,0
TRDR08IP
DMSL
06
025
M12
Z4
Cutter series
Insert size
Cutter diameter
Mounting screw size
Number of teeth
Modular Tool System
→ P.13
l = Euro stock
m = Japan stock
8
Number of teeth 2 2 3 4 3 4 4 5 4 4 5 5 5 6 5 6 6
Weight Fig. (kg) 0,03 1 0,03 1 0,05 1 0,05 1 0,06 1 0,06 1 0,10 1 0,10 1 0,10 1 0,11 1 0,11 1 0,18 1 0,20 1 0,20 1 0,21 1 0,25 1 0,26 1
