Sumi Dual Mill
DMSL 06000 R(S) Type Rake angle
Radial -8° to -12,5° Axial -8°
1,5 mm
17° '&6)06 '&% .::
/)
&%'3
.'3
Fig 1
' ' '& '&;
Cat. No. DMSL 06040RS05 06040RS06 06042RS06 06050RS05 06050RS08 06052RS08 06063RS08 06066RS08-27 06080RS09 DMSL 06050R05 06050R08 06063R08
Dimensions (mm)
Stock
Inch
Metric
Body (Shell Type) DCX
DC
DCSFMS
LF
DCB
KWW
KDP
CBDP
D1
D2
l l
40 40 42 50 50 52 63 66 80 50 50 63
32,3 32,3 34,3 42,3 42,3 44,3 55,3 58,3 72,3 42,3 42,3 55,3
33 33 33 41 41 41 50 55 55 41 41 50
40 40 40 40 40 40 40 50 50 40 40 40
16 16 16 22 22 22 22 27 27 22,225 22,225 22,225
8,4 8,4 8,4 10,4 10,4 10,4 10,4 12,4 12,4 8,4 8,4 8,4
5,6 5,6 5,6 6,3 6,3 6,3 6,3 7 7 5 5 5
18 18 18 20 20 20 20 22 22 20 20 20
14 14 14 18 18 18 18 20 20 18 18 18
9 9 9 11 11 11 11 14 14 11 11 11
Number Weight Fig. of teeth (kg) 5 0,20 1 6 0,20 1 6 0,21 1 5 0,31 1 8 0,30 1 8 0,31 1 8 0,52 1 8 0,69 1 9 0,94 1 5 0,32 1 8 0,30 1 8 0,53 1
R
S
08 - 27
Cutter Feed diameter direction
Metric
l l
m m
Take note of the cutter mounting size (DCB) when selecting a cutter. Inserts are sold seperately. For mounting the cutters marked with * to an arbor, use a JIS B1176 hexagonal socket bolt (M12x30 to 35 mm).
Parts Insert screw
Identification Details
Wrench
DMSL Cutter series
BFTX02507IP 2,0
TRDR08IP
Inserts → P.9 Recommended Cutting Conditions → P.9
l = Euro stock
m = Japan stock
6
06 066
Insert size
Number of teeth
Mounting size
