Diamond / CBN Grinding Tools, Electroplated Bond Diamond Escapement Files
Diamond escapement files DF 3608 half round DF 3609 crossing oval DF 3610 barette DF 3614 three square DF 3617 hand DF 3619 square DF 3621 round
Diamond escapement files are used on very small shapes in toolmaking applications and general precision mechanics.
Diamond escapement files have a forged shank, which eliminates the need for a handle.
Grit sizes D 25 and D 46 provide ultra-fine surface finishes. Order No.
Grit size D 25
Ordering example: EAN 4007220535530 DF 3608 D 25 Please state required grit size.
Grit size D 15 and finer grit sizes can be supplied upon request.
D 46
D 91
D 126
Overall length [mm]
Coating length [mm]
Cross-section with coating [mm]
140 140 140 140 140 140 140
40 40 40 40 40 40 40
4,2 x 1,5 3,8 x 1,8 4 x 1,2 3 4 x 1,2 2x2 1,8
EAN 4007220 DF 3608 DF 3609 DF 3610 DF 3614 DF 3617 DF 3619 DF 3621
535530 535516 535509 535561 535578 535547 535523
Diamond escapement file sets
323625 323632 323649 323656 323663 323670 323687
254622 254462 254493 254554 254523 254592 254653
254639 254479 254509 254578 254530 254608 254660
Diamond escapement file sets are supplied in a plastic pouch protecting them from corrosion and mechanical damage.
1 1 1 1 1 1 1
4 4 4 4 4 4 4
Ordering example: EAN 4007220535639 DF 3090 D 25 Please state the required grit size.
Contents: 1 piece each of DF 3608 (half round) DF 3614 (three square) DF 3617 (hand) DF 3619 (square) DF 3621 (round)
Order No.
Grit size D 25
D 46
535639
323700
D 91
D 126
323694
017364
Overall length [mm]
EAN 4007220 DF 3090
12 I 205
140
1
27
