NEXUS MAP -
FOUNDTION -
FLOORINGs -
- BRICK WORK WALL IN MORTAR
2 MM THICK COW DUNG LAYER USED EVERY TWO WEEKS FOR CLEANING
2 MM THICK COW DUNG LAYER USED EVERY TWO WEEKS FOR CLEANING
10 MM SURKI LAYER WITH COCONUT SHELL CHARCOAL
10 MM SURKI LAYER WITH COCONUT SHELL CHARCOAL
20 MM SURKI LAYER MADE OF RIVER SAND, LIME, EGG, WHITE, JAGGERY
- CEMENT FLOORING (RED OXIDE)
150 MM LATERITE BRICK
- B R I C K B AT F L O O R I N G
20 MM SURKI LAYER MADE OF RIVER SAND, LIME, EGG, WHITE, JAGGERY 50 MM CONCRETE
SAND FILLING
30 MM WOODEN PANELS 350 MM WOODEN JOIST
- RR PLINTH
Traditional building materials include clay, palm leaves for roofing, stone, wood, and lumber. Walls are constructed of the porous red stone known as laterite, while foundations are made of granite. Widely utilized for framing and millwork, teak, rosewood, and jackfruit are frequently artistically carved by talented artisans. Stone or a bizarre mixture of sand, egg whites, burned coconut shells, unrefined sugar, and vegetable juice extract are used as flooring.
- R R F O U N D AT I O N C O M PA D E D S A N D BASE
PLASTERING -
CHARIOT DETAILS -
TEMPLE DETAILS -
Rough plastering -First coat of mortar with limestone and river sand
Stucco decorations : the exterior of the gopuram is decorated with stucco decorations.
The Entire Chariot Is Carved In A Single Ellupai Teak Timber .
Nice plastering - Second coat of mortar by grinding limestone and river sand. This is done every one hour for the next 12 hours`V
Red oxide : it is used in flooring.low cost material,they don’t loose their lustre as tiles.
It Is Of Dravidan Style Of Architecture.which Is Characterized By Pyramid Shape Towers.
Timber : Timber have been used for joinery detailing and connecting two minute timber.
Sand white is mixed with limestone for a third coat
Stone masonry: the gopuram construction entire have been done by stone masonry, the gopuram is adorned with numerous sculptures and carving . No motor is being used.
Limestone mixed with water is applied on the wall
Rock:rocks are used for masonry work, lintel and vertical columns, floor covering of the temple.
Foam of egg white and drops of curd made from cow’s milk are mixed and then applied on the walls
Mud: mud have been used for plastering and for adding minute detailing . Most of the shrines around the temple are made of mud .
After drying. walls are then polished with pebbles for three days LENGTHENING JOINT IN WALL PLATES SCARF JOINT
BASIC JOINERYS HALF LAP
MORTISE AND TENON
CROSS LAP
DETAILED JOINERY OF WALL PLATES AND RAFTER
DETAILED JOINERY OF RIDGE AND RAFTER
Intricate Carvings And Intricate Detailing. The Four Gaint Wheels Made Of Timber Is Attached To The Chariot Look Complete With The Axis Shafts. On The Wheels Are Concentric Timber Grains Motifs. The Chariot Is Of Monolithic Structure Of 72 Feet With 12 Tones.
DETAILED JOINERY OF RIDGE AND RAFTER
