COPPER TUBING TYPE L COPPER WATER TUBING

C

NOM. SIZE IN. 1/4 3/8 1/2 5/8 3/4 1 1-1/4 1-1/2 2 2-1/2 3 4 5 6

ACTUAL O.D. IN. 3/8 1/2 5/8 3/4 7/8 1-1/8 1-3/8 1-5/8 2-1/8 2-5/8 3-1/8 4-1/8 5-1/8 6-1/8

WALL THICK. IN. .030 .035 .040 .042 .045 .050 .055 .060 .070 .080 .090 .110 .125 .140

COPPER REFRIGERATION TUBING SIZE O.D. 1/8” 3/16” 1/4” 5/16” 3/8” 1/2” 5/8” 3/4” 7/8” 1-1/8”

WT. LBS. PER 100 FT. 12.6 19.8 28.5 36.2 45.5 65.6 88.4 114.0 175.0 248.0 333.0 538.0 716.0 1020.0

WALL THICK. IN. .030 .030 .030 .032 .032 .032 .035 .035 .045 .050

WT. LBS. PER 100 FT. 3.48 5.76 8.04 10.90 13.40 18.20 25.10 30.50 45.50 65.50

COPPER DRAINAGE TUBING TYPE K COPPER WATER TUBING NOM. SIZE IN. 1/4 3/8 1/2 5/8 3/4 1 1-1/4 1-1/2 2 2-1/2 3 4

ACTUAL O.D. IN. 3/8 1/2 5/8 3/4 7/8 1-1/8 1-3/8 1-5/8 2-1/8 2-5/8 3-1/8 4-1/8

WALL THICK. IN. .035 .049 .049 .049 .065 .065 .065 .072 .083 .095 .109 .134

WT. LBS. PER 100 FT. 14.5 26.9 34.4 41.8 64.1 83.9 104.0 136.0 206.0 293.0 400.0 651.0

NOM. SIZE IN. 1-1/4 1-1/2 2 3 4

2

ACTUAL O.D. IN. 1/2 5/8 7/8 1-1/8 1-3/8 1-5/8 2-1/8 2-5/8 3-1/8 4-1/8 5-1/8 6-1/8

WALL THICK. IN. .025 .028 .032 .035 .042 .049 .058 .065 .072 .095 .109 .122

WT. LBS. PER 100 FT. 65.0 80.9 107.0 169.0 287.0

ALUMINUM TUBING SIZE O.D. 1/4” 3/8” 1/2”

TYPE M COPPER WATER TUBING NOM. SIZE IN. 3/8 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3 4 5 6

WALL THICK. IN. .040 .042 .042 .045 .058

WT. LBS. PER 100 FT. 14.5 20.4 32.8 46.5 68.2 94.0 146.0 203.0 268.0 466.0 666.0 892.0

7/19

WALL THICK. IN. .035 .035 .035

WT. LBS. PER 100 FT. 2.78 4.40 6.01
