Some of the colour photography used in Building Innovations is provided and paid for by contributors. The publishers do not accept liability for errors that may appear in the publication. This edition is dedicated to our much-loved friend and colleague, Mike Mahon. Always one of us. No part of this publication may be reproduced or transmitted in any form or by any means without the consent of the publisher. Published by L2 Media Ltd, Parkfield Business Centre, Park Street, Stafford ST17 4AL Tel: 01785 223253 Fax: 0845 862 8639 www.l2media.uk

Award

Winning, Victorian Terraced Townhouse, Highgate LondonLLI Design

LLI Design recently completed a total redesign and refurbishment of a 5 storey, period terraced townhouse in Highgate, North London. LLI Design’s work was commended with an award in the Residential Interior Private Residence London category, of the United Kingdom Property Awards in association with Rolls Royce.

The award’s judging panel was chaired by Lord Caithness, Lord Best, and Lord Waverley, members of the House of Lords in the UK Parliament. Historic Highgate is filled with beautiful period family homes and this one was no exception.

Perched at the top of Highgate Hill commanding enviable views across London this 1860s house forms part of a terrace. The townhouse sits within the Highgate Conservation area, so any architectural amendments had to be approached in a sensitive manner. Although the brief was to keep the period feel of the building, it also required that a contemporary individual aesthetic should be overlaid in order to create easy open plan living spaces that worked for a modern lifestyle. (cont...)

(cont...) The house was tall and narrow but had the advantage of being quite long front to back. A major design problem which had to be addressed in the overall scheme was how to make the property feel visually more expansive laterally.

To answer the brief, the existing layouts required a total redesign, with careful consideration required to how the dynamics and flow of the spaces would feel. The direction adopted throughout was eclectic with elements of mid century, contemporary, industrial and traditional styling all coming together.

By way of reconfiguration, clever use of colour and lighting together with bespoke joinery elements, this property was completely transformed from a traditional layout 5 storey Victorian townhouse into a contemporary family living space. The design stayed true to the Victorian bones and features of the original.

At the same time it was able to offer the elements so desired of 21st Century living, being open plan, multi-functional spaces with large windows offering inside / outside living.

LLI Design offers a comprehensive design service, taking projects from briefing through to Handover; creating beautifully crafted interiors for discerning clients. The creative team is led by Design Director Linda Levene. Her background as a fashion and textile designer is reflected in her love of form, texture and colour.

Recent projects include the interior design and modernisation of properties in Hampstead, South Kensington and Highgate including a 10,000 sqft Victorian residence, a 12,000 sqft new build home and the co-joining and re-planning of two apartments to provide a single luxury penthouse. www.llidesign.co.uk

Gateway

Central And Gateway West Buildings Completed At White City Place

The Gateway Central and Gateway West buildings at the White City Place business campus in west London are now completed. Both Gateway buildings have a Platinum WiredScore, the highest certification for pre-enabled connectivity.

Gateway Central is an eleven-storey building comprising 280,000 square feet of total floor area, including two outdoor terraces at Levels 4 and 8. L’Oréal UK and Ireland have taken the five upper floors of the building for their new UK Headquarters and are currently fitting out the new space. The design of Gateway Central with its solar-control glass with shading from external fins and shelves – enables the building to use less than half the energy a comparable building requires to cool.

The building is targeting BREEAM Outstanding and an energy efficiency EPC ‘A’. The building will provide a unique opportunity post-COVID for L’Oréal to build a workplace for tomorrow, designed around modern working methods that encompass L’Oréal’s ethos of creativity and innovation. The new HQ will also feature a training

academy, a flagship training hub which plans to upskill 10,000 hair professionals from across the country each year. Gateway West is a four-storey building comprising 25,000 square feet which offers the rare opportunity to accommodate a stand-alone headquarters while also being flexible for a multi-tenanted occupation. It is a distinctive, angular brick and ceramic building, accessed via a new, landscaped public garden.

A collaborative approach to sustainability has resulted in a low level of embodied carbon in the building. It has also achieved 20252030 energy performance targets and the site now supports twice the previous levels of biodiversity, prior to its redevelopment. The building is targeting BREEAM Outstanding and an energy efficiency EPC rating of ‘A’. www.whitecityplace.com

ISG Awarded

£50 Million Low Carbon

Marylebone Office Scheme

ISG has won a £50 million project to redevelop and refurbish Woolworth House in the heart of London’s West End. The mixed-use scheme, for General Projects with Henderson Park, will increase the building’s gross area by circa 100,000 sq ft. to over 236,000 sq ft, offering 172,000 sq ft. of lettable space and increase floor areas by over 40%.

It includes the complete refurbishment of the existing eight-storey office building, located at 242 Marylebone Road in the London Borough of Westminster. Renamed Metropolis, the new building will benefit from both office and retail facilities, with external green roof terraces across every floor. An events auditorium, rooftop-bar, on-site coffee shop, cyclist zone as well as new health and wellbeing amenities complete the specification.

A new extension will significantly increase outdoor and green space, adding over 6,000 sq ft of new landscaped gardens. To achieve this, the scope of work includes infilling the existing courtyard area up to the seventh floor, providing tiered planted terraces and the structure will be extended with various additions across floors three to eight using a steel frame with cross laminated timber (CLT) slabs.

In addition, the existing roof plant enclosures will be removed and consolidated, allowing the creation of rooftop office pavilions on level five and eight. Designed by London architect AHMM, the environmental performance of the refurbished building will be boosted to a BREEAM rating of Outstanding. Careful retention of existing building material will result in over 4,500 tonnes of carbon saved during the construction process and diverted from landfill.

The new scheme will also achieve industry leading Wired and AirRated scores. The use of engineered timber floors to all building extensions has dramatically reduced embodied carbon, equating to a 73% improvement against RIBA 2030 targets. The masonry facades, concrete frame and cores will also be retained while CLT will be used for all new floors forming the building’s extension.

Jim Knowlton, ISG project director, said: “Originally constructed in the 1950’s, Woolworth House is an exemplar of how a low carbon approach can transform our cities’ dated building stock. Underpinned by environmental, social and governance (ESG) considerations, the scheme shows how adapting assets into smarter office and retail environments, with more green spaces for occupants, can future proof London’s commercial property market.

“Following the successful completion of 66 Shoe Lane in 2020, Woolworth House is our second collaboration with Henderson Park. The project builds upon the success, expertise and shared learnings of the same delivery team, now applied to this trailblazing low carbon scheme.”

www.isgplc.com

NEW WEBSITE MAKES STRONG IMPRESSION

First impressions count – including digital ones – which is why AliMet Fabrications has launched a new website to better represent its extensive services as it celebrates its third anniversary. The company, which specialises in the fabrication of commercial aluminium doors, windows, shopfronts and screen-work along with pressed metal services, has evolved since its first website was created for its 2019 launch.

The new site - www.alimet.co.uk - has an ultra-modern design, improved navigation/user journey, and better categorisation of services. It includes a downloads section for customers to obtain technical drawings and data, product brochures and compliance certification. A news section has also been added for company updates and case studies. Said Steve Marshall, Managing Director of AliMet Fabrications: "We felt it was time for AliMet Fabrications to present a fresh face to the world. The former iteration of the website was put in place when AliMet's management team acquired the assets of Midland Glass Solutions. Three years on, the company has evolved, our customer base is better established and the range of products and services that we offer has been extended." www.alimet.co.uk

A. PROCTOR GROUP LAUNCHES RIBA APPROVED CPD SEMINARS

Aimed at architects, specifiers and contractors, attendees will receive technical advice from A. Proctor Group technical experts, providing the latest guidance on British and European Standards, compliance with Building Regulations, and learning on how to maximise performance and avoid potential failures.

Each seminar is available as an in-person seminar provided within practice or as indepth Online Learning material to support individuals with their Continuing Professional Development. Iain Fairnington, the Technical Director at A. Proctor Group adds, “Through the CPD series, we aim to provide technically accurate learning based on best practices, innovation, and project examples to help individuals make informed choices when specifying product solutions for their projects.”

www.proctorgroup.com

UK’S FIRST ZERO CARBON MIXED USE SCHEME BANKS ON FHP’S BUILDING SERVICES EXPERTISE

Ojmar, manufacturer of innovative high performance electronic and mechanical locks, is delighted to introduce OTS ® PULSE, the latest addition to the well-known family of locks.

Specifically designed for the Corporate and Leisure markets, OTS ® PULSE is the ultimate wireless networked locking solution that operates in highly secure cloud software. It uses the latest battery technology providing a life of up to 10 years before needing a simple battery replacement. This makes it one of the most efficient, longest-lasting systems available on the market.

Fully plug-and-play, online, self-managed and wireless, the OTS ® Pulse will help your office be flexible at minimal cost. OTS®PULSE does not require any expensive servers, just a simple standard internet connection managed through a PC, tablet or smartphone. Samples, case studies and technical guidance are available from ojmar.com or look for Ojmar on NBS Source

National building services and engineering consultants

FHP has been appointed to support the £2.5bn design and construction of the UK’s first zero carbon mixed use development for the Bankside Yards West project on the south bank of the River Thames.

A key feature of the plans is sustainability, with the main Arbor office complex built to deliver a carbon neutral operation and achieve BREEAM ‘Outstanding’ status. 45% less carbon dioxide will be created during the building’s operation while a 30% reduction in energy consumption will also be achieved when compared to standard buildings. www.fhpp.com

Building membrane specialist, Industrial Textiles & Plastics (ITP) Ltd, has launched a new vapour control layer with A Euroclass A rating which enables maximum fire safety throughout an external wall system. FlameOut Block Class A is independently tested to offer a Euroclass A2-s1,d0 rating which goes beyond the minimum regulatory requirement for vapour control layers and matches the fire safety classification required for other façade elements on buildings over 18m.

Its glass-based reinforcement scrim provides excellent tensile strength. An aluminium layer features a special coating to protect the aluminium from corrosion. Fully CE certified to BS EN 13984, the product has a W1 rating for water tightness, excellent water vapour resistance and a reflective surface for extra energy efficiency. www.Itpltd.com

ITP LAUNCHES NEW EUROCLASS A-RATED VAPOUR CONTROL LAYER CAST IRON CERTAINTY FROM STELRAD…

The latest addition to the Stelrad Radiator Group portfolio is the new Cast Iron Column range, adding undoubted charisma to any modern or period home with its distinctive, ageless look and its Natural Cast finish. With the added options of either Antique Brass or Brushed Nickel TRVs to provide the ultimate in modern heating control.

The classic, clean lines suggest a genuine piece from yesteryear whilst offering the very best in quality and craftsmanship to enhance the very latest in heating technology. These radiators are floor standing with in-built feet for extra stabilitys. They are available in two heights and a wide variety of widths. And as you would expect, they come with a cast iron ten-year warranty. www.stelrad.com

NEW HYDRAULIC DESIGN SOFTWARE FOR HAURATON SURFACE DRAINAGE SYSTEMS

HAURATON’s new web-based application ‘DesignSoftware’ provides quick, simple hydraulic analysis, channel sizing, project design and product specification for the company’s range of surface drainage systems.

Immediate access for registration and use of this new hydraulic design software is achieved through the link: www.hydraulicdesign.hauraton.com

User-friendly and free-of-charge, it provides engineers with the flexibility to create their own drainage designs and project specifications, with just three clicks to a hydraulic calculation. www.hauraton.co.uk

Whiteout Fails to Thwart Strand Celebration

Strand Hardware defied the ‘Beast from the East’ when it went ahead with its office reopening event and rededication ceremony. Fortunately, the majority of guests were not deterred by the snowfall, with 70 people attending, including staff, suppliers, customers and media representatives. They included representatives from Athmer, who travelled from Germany, to support their UK distributor and Simon Forrester, Chief Executive Officer of the Guild of Architectural Ironmongers. They toured the newly refurbished Strand House, in Walsall, where the company has been located for more than 30 years.

Christine Franks, the wife of company founder, the late Jonathan Franks, carried out the ribbon cutting ceremony. “I know that Jonathan would have been extremely proud to see how Strand Hardware has flourished,” she said. The building has had a radical make over resulting in a more modern, open plan work space for its expanding team.

It also includes a hi-tech reception and energy efficient measures including better insulation and motion sensor lighting. Many of the materials used in the project were sourced from suppliers and clients including new windows, fire doors, electricals, plumbing, furniture, decoration, carpeting

and signage, along with some of its own ironmongery products. Guests were treated to refreshments and goody bags and a special cake was created to mark the event.

Managing Director Steve Marshall said:

“The completion of the refurbishment project has taken many months of planning, organisation, disruption and hard work from all concerned. Those who had visited us before will no doubt see a vast improvement in our working environment, and our environmental credentials. “Since the dear late Mr Jonathan Franks set up the company in 1992, Strand Hardware has gone from strength-to-strength, navigating its way through many national and global challenges, while always sitting solidly on its impeccable financial foundations.”

He also paid tribute to Strand’s ‘family’ – its 21-strong workforce and Jonathan’s daughter, Catherine Franks who took over as MD in 2005 and now Chairs its board. “She has positioned Strand as one of the market leaders in our industry with customer service levels that are second to none and a reputation of which we can be proud,” he added. www.strandhardware.co.uk

YORK HANDMADE UNVEILS

“TRANSFORMATIONAL” £1.5M STATE-OF-THE-ART MACHINERY

The award-winning York Handmade Brick Company has invested £1.5 million in brand-new machinery which will transform how the company makes bricks. York Handmade, who are now the UK’s leading small independent brickmaker, is confident this investment will open a new chapter in the company’s illustrious history. The first bricks from the new plant will be available in March.

David Armitage, chairman of York Handmade, which celebrates its 35th anniversary this year, commented: “Over the years, we have undertaken significant technological improvements, culminating in this £1.5 million overhaul and renewal of our manufacturing process, which will speed up production, facilitate two brand-new products and increase efficiency. This is a transformational move, by far the biggest and most significant in our history. Our revolutionary new manufacturing line will combine three different types of brick - the Handmade Style, as currently produced, together with Water Struck and Pressed Bricks."

“Most of the Water Struck Bricks, which are currently very popular in London, are imported, so we are fulfilling an important demand and supporting the sustainability agenda. We have an impressive track record in London, with iconic projects across the capital, and we can now build on this. More generally, this investment will enable us to manufacture high-quality, UK-made bricks for many years to come and it reflects our commitment to the brick industry and the astounding architectural projects using bricks,” explained Mr Armitage. www.yorkhandmade.co.uk

DESIGN SHOW SUCCESS FOR ENHANCED MARMOX RANGE

Already widely regarded as a lead player in the creation of stylish bathrooms, wetrooms and spa facilities, manufacturer Marmox was able to unveil extensions to its widely specified range at this year’s Surface Design Show in London earning particular interest in its new Slicedstone – Large Format Veneer Sheets.

The Sales and Marketing team were on hand throughout the three days at The Business Design Centre, Islington, showcasing the new large format version of mosaic style product introduced in 2020. Still displaying the beautiful colour variations of natural Indian sandstone, the new Slicedstone – Large Format Veneer Sheets are available in two sizes - 1220 x 610mm or 2100 x 1050mm - rather than 50 x 50mm mosaics on a mesh roll.

However, the new product’s slimline form - at just 4 (±1.5) mm thick, means they can still be applied to curved surfaces both indoors and out. Utilising the latest technology,

Slicedstone – Large Format Veneer Sheets are cut from the surface of Indian sedimentary rock and then re-engineered with a stabilised backing. The natural stone blend substrate is treated with a clear polycarbonate solution to offer a flexible surface that is both stable and fully resistant to water as well as being stain resistant.

Being in large format means, compared to conventional tiling, savings will be made on the cost of grout and adhesive as well as the reduced labour through quicker installation. www.marmox.co.uk/slicedstoneveneer

A. PROCTOR GROUP INTRODUCES NEW U-VALUE CALCULATOR AND MEMBERS AREA

The A. Proctor Group, synonymous with technically advanced thermal, airtightness and condensation control membrane solutions for the construction industry, has introduced a new online U-value calculator, Condensation Risk Analysis and members area with an impressive range of technical support available to architects, contractors, and customers.

The software is an essential online tool for meeting the new standards and improving the energy performance of new and existing buildings. U-value calculations are carried out in accordance with BRE443:Conventions for U-value Calculations and can be submitted with your building control applications to demonstrate compliance.

In addition, a new Members Area has been introduced to the A. Proctor Group website that enables architects, designers, contractors, and clients to access a comprehensive range of technical resources. Registered members will have access to high-quality webinars on critical topics, with personalised CPD certification for each. A full suite of brochures and product documents including technical properties and characteristics is available for download from the Members Area. Please visit www.proctorgroup.com to register for the members area where you will access the U-value calculator and Condensation Risk Analysis tools. www.proctorgroup.com

GEZE EXHIBITS AT BAU

The world’s leading trade fair for architecture, material, and systems, BAU 2023 will be opening its doors from 17-22 April in Munich and GEZE, a specialist in door, window and safety technology will be exhibiting a range of innovative products, system solutions and services at the show. Under the motto of “Liveable buildings: digital, sustainable, smart” GEZE will be exhibiting myGEZE Control: the next generation networking solution for smart buildings that is able to integrate door, window and safety technology into many different areas of a building management system.

In addition GEZE will be exhibiting several other new products; Revo.PRIME – an automatic revolving door system with a low canopy height and narrow profiles, the F 1200+ window drive, designed for large and heavy turn-and-tilt, and bottom hung windows up to 200kg leaf weight, and the TS 5000 SoftClose, perfect for anywhere where a doors needs to be closed securely, but with minimal sound. The exhibition stand, which is 500sqm in size, will be located in Hall B1, stand 538-539, with representatives from GEZE UK on hand to offer advice and demonstrate products.

kSaid Andy Howland, GEZE’s Sales and Marketing Director, ‘The BAU exhibition is an important one for the whole of the construction industry with visitors from many countries. It is the perfect opportunity for GEZE to show our latest products and innovative solutions’. www.geze.co.uk

For more information on the BAU exhibition visit https://bau-muenchen.com/en/

Britannia Brick Slips Contributes To Sustainability

Brick is the traditional building material in the UK and although architectural styles may come and go, brick seems to be a constant. There are however limitations to the use of whole bricks, particularly as they require a lot of energy to manufacture. The increase in the cost of energy has had a dramatic impact on brick manufacturers and led to significant price increases. The need to improve sustainability means alternatives to whole bricks are being sought to reduce the embedded energy of projects.

One such alternative to whole bricks is extruded brick slips. Made from natural clay and fired like traditional bricks, extruded brick slips are manufactured as thin slips or tiles requiring only 30-40% of the energy used to manufacture whole bricks, which is quite a substantial reduction in energy consumption. Furthermore, manufactured brick slips are usually around 15mm thick and are packed up to 3000 slips to a pallet as opposed to up to 600 whole bricks to a pallet. This means fewer pallets of brick

slips will be required to cover a given area compared with traditional bricks, reducing associated transport costs. Their Britannia range is a selection of kiln fired natural clay brick slips that provide excellent quality and great value, offering a wide range of colours and textures. The smooth finish and clean edges of some brick slips in this range complement contemporary designs while others offer the more traditional aesthetic that is always in demand.

Manufactured in standard UK metric sizes, the nominal size of the Britannia range brick slip is 215mm in length by 65mm height with a thickness of just 1415mm. Corner pieces are also available and nominally measure 215 x 65 x 100 x 14-15mm. Eurobrick also have a specially formulated pointing mortar called Europoint which is designed for bag or gun injection into the joints of its brick slip cladding systems. Europoint is available in 8 colours to contrast with or complement the brick choice. www.eurobrick.co.uk

KEUCO AXESS, Design By Studio F.A. Porsche

Accessibility in the bathroom has never been so beautiful

When Studio F. A. Porsche designed a range of accessible bathroom products for KEUCO, the result was something unique: German engineering meets premium interior design. What is striking about the entire KEUCO AXESS barrier-free range, Design by Studio F. A. Porsche, is the clean lines of all the products – commencing with the folding support rail, positioned over the rail system for the shower, the grab rails, through to the freestanding stool.

The design, focuses on the essentials, combining aesthetics and barrier-free functionality in a stylish and innovative way, without making the special functions visually obvious. It is this aspect that will pleasantly surprise design lovers who want to see accessibility integrated in the bathroom: products with a minimalist appearance - design that inspires.

Good design has to be honest - “It was our wish to meet the highest aesthetic demands and yet incorporate the specific needs of a barrier-free bathroom system. Our aim was to develop accessible bathroom products from a completely new perspective. Timeless, very clear, aesthetic forms, permanently perceived as beautiful, even after many years. Independent of the spirit of time and trends and at the same time, beyond anything known so far. Out ambition was to create something special, right down to the smallest detail, and making it technically possible. A combination of German engineering and top-quality implementation in every respect.“ Christian Schwamkrug, Design Director Studio F. A. Porsche.

Accessibility meets design: for high-quality bathrooms across all sectors - KEUCO AXESS, Design by Studio F. A. Porsche, is designed for barrier-free bathrooms in hospitality, private and public sectors, e.g. high-quality healthcare facilities such as hospitals and nursing homes, hotels and spas, restaurants in the home. KEUCO AXESS is a sustainable and cross-generational concept made from high-quality materials in a beautiful and timeless design. KEUCO AXESS ensures the comfortable and safe use of all areas of the bathroom - not only for the elderly, those currently in need of care or for people with a physical disability, but for all generations.

The intelligent design details support independence and autonomy in the bathroom; so, people of all ages and abilities can benefit from comfort-enhancing functions. What may be a useful aid for one person, provides additional comfort for another, such as taking a shower whilst sitting down. A barrier-free bathroom brings many advantages, regardless of age and physical constitution. A bathroom without barriers offers a adds to the quality of life, is comfortable, future-oriented and, thanks

to the unique design of KEUCO AXESS, Design by Studio F. A. Porsche, is extremely attractive and visually appealing. Turning barrier-free bathrooms into ‘bathrooms’ for people of all ages and for all life situations. More and more building owners in the project sector, architects, and planners along with private individuals, when deciding to renovate or refurbish, opt for barrier- free solutions. They increase the level of comfort and safety in the bathroom and add to the value of a property – even more so now with the unique design of KEUCO AXESS!.

Elegance on the wall: a folding support rail like no other - Studio F. A. Porsche has developed a strikingly beautiful and unique solution together with KEUCO - for a folding support rail, the special highlight of the barrier-free KEUCO AXESS range. It looks nothing like folding support rails of the past as the visually appealing folding support rail stands uniquely flat against the wall when folded up.

When unfolded and exposed in the downward position, the KEUCO AXESS support rail is a beautiful and elegant solution. It is available in three finishes: chrome, matt black or aluminium- chrome and depending on the surface, a grip-friendly plastic inlay in black or white is seamlessly integrated. The plastic is significant as it makes it easy to grip and prevents slipping when supporting or holding on.

There is an optional and retrofittable toilet paper holder which has a black or white roller stopper enabling it to colour match the design. Two different projections in 700 and 850 mm offer perfect safety and support. The larger projection folding support rail is also suitable for larger wheelchair-accessible WCs. (cont...)

(cont...) The optional and retrofittable radio WC flush actuator integrates aesthetically into the handle and is compatible with radio flush cisterns from common manufacturers via Bluetooth. Despite the reduced design, stability is guaranteed with 115 kg load capacity: KEUCO AXESS folding support handles are TÜV tested and certified according to DIN standard.

The rail system - beautiful design that provides support at the same time The rail system and the grab rails of the KEUCO AXESS range are characterised by their elegant yet starkly simplistic design. The versatile range provides support and safety in the shower and bath, at the washbasin and WC. Despite high stability when holding and supporting, yet this ergonomic design appears light, stylish, and un-cumbersome.

The grip surface at the front forms a smooth rectangular band - with flat surfaces and precise edges. At the back, the rail/grip system and handles are ergonomically shaped in a semicircle - for an optimised grip. This oval rounded back perfectly fits in the hand when grasping so it is not necessary to exert a great deal of force when holding on; ensuring a secure grip and a reliable hold. The unobtrusive wall fixings of the rail system and grab rails emphasise the clear, minimalistic design, whilst

ensuring sufficient stability for a barrier-free solution. The range of KEUCO AXESS grab rails ranges in lengths from 400 to 1000 mm. In the shower, the rail system can be flexibly adapted to suit on-site conditions. The shower rail also serves as a stable grab rail, always giving a feeling of safety.

The shower slider can be unlocked and moved up or down simply by pressing on the back, and this can be done with one hand. The shower head can be turned in various positions, to the left and right in the holder and can be tilted up and down from any angle without any problems.

Safe, beautiful and comfortable: mobile seating in the bathroom - A stable seat is a plus for comfort in the bathroom. Taking a shower while sitting down is particularly comfortable. KEUCO has supplemented its range of seats with the mobile KEUCO AXESS stool. The design of the KEUCO AXESS stool, Design by Studio F. A. Porsche, is crafted to the highest standard: as minimalistic, as safe as possible, and as comfortable as possible. In an archetypical, timeless design, the stylish stool takes up little space in the bathroom and fits in any corner.

With a load capacity of 150 kg, the KEUCO AXESS stool can be used in both private and public areas. The stool is particularly stable and resilient as the discretely outward-facing legs with anti-slip ensure a secure standing position, whilst being easy to reposition using one hand. The softly roughened, nonslip surface of the seat has a pleasant feel and is easy to clean. The seat is slightly curved inwards and features a small hole in the middle which allows water to drain off directly in the shower. The mobile stool with a white or black seat can be harmoniously integrated into the bathroom or shower area. With a white seat, you can choose between chrome or aluminium legs; with a black seat, the legs are also in black. All versions are robust, durable and easy to clean.

(Stylishly) safe barrier-free even in the professional environment of hospitals and nursing homes - For people in need of care, access to the individual bathroom areas can be difficult or even impossible. They are dependent on assistance. Nevertheless, for all people and age groups, the desire for independence and autonomy in the bathroom plays a very decisive role in maintaining quality of life. Assistance from care staff can be optimally supplemented in the bathroom with KEUCO AXESS as the flexible and adaptable barrier-free bathroom range made by KEUCO enables a high degree of independence for users and facilitates the daily work of care staff.

Ideally, a barrier- free bathroom equipped with KEUCO AXESS is designed in such a way that people can find their way around without help, if possible - whether they are motor-impaired, people with little strength or users with cognitive impairments and coordination problems. KEUCO AXESS combines barrierfree comfort with a high degree of aesthetics, the shapes and materials meet the highest standards of hygiene and ease of care, even in the optional service area.

Andreas Lohmann, Head of Object Management at KEUCO: "KEUCO AXESS closes a real gap. Products for barrier-free bathroom design that don't look like they are barrier-free. A flexible and aesthetic professional system. Well thought-out and with a strong design.

Perfectly combinable with IXMO fittings and KEUCO accessories - KEUCO AXESS products are perfectly matched to KEUCO IXMO fittings. The cover plate can be combined in either round or square. In the shower, head and hand showers can be individually combined. The IXMO range of fittings from KEUCO enjoys great popularity among design lovers and sanitary professionals thanks to the bundling of functions with a minimalist appearance.

IXMO fittings are available for all areas in the bathroom: washbasin, shower, bathtub and bidet. IXMO stands for "x possibilities" and promises: design variety and planning freedom, aesthetics and easy care, quick and an affordable installation. The KEUCO AXESS barrier-free range can also be combined with various KEUCO accessory collections, such as the PLAN or REVA range.

Various different KEUCO shower shelves make handling easier and, together with a comfortable seat from KEUCO, bring real pleasure to the shower. KEUCO AXESS series, in combination with IXMO fittings and KEUCO accessories, can be used to transform any bathroom in the object or private sector into a design-strong, barrier-free place of well-being.

www.keuco.com/gb

DRU Reports Excellent Growth From Its Expanding Dik Geurts Wood Stove Range

Established in the Netherlands in 1981, Dik Geurts stoves and fires are now produced by DRU, one of Europe’s leading fireplace companies. Soaring energy prices have provided a welcome boost to wood stove sales. Consumers are looking for cheaper and greener sources of home heating that can be supplied and installed rapidly to alleviate punitive home heating bills. Increased production and distribution.

This market uplift has led to DRU increasing production and distribution of its Dik Geurts Ivar selection of classic and contemporary stoves, which align with British and European emissions and efficiency standards. They are a popular choice to replace older, inefficient stoves or open fires. The Dik Geurts Ivar series also includes the Aste, Soren and Modivar models. These stoves are based on classic designs, making them ideal for traditional or modern homes.

They are easily installed into Class 1 chimneys, with their dark anthracite colour finishes blending perfectly with any style of décor. A+ energy labels and high efficiency Each model in the range has an A+ energy label, with an efficiency rating of over 80%. And for added air quality, there are external air and room-sealed options available. All stoves in the range are Ecodesign ready, so they comply with European standards for low emissions and clean burning. In addition, they have HETAS, DEFRA and clearSkies approvals.

Freestanding and water heating options For homes with no chimney, customers can choose from a range of freestanding models, which are available in a selection of sizes and capacities with built-in wood storage. In addition, The Ivar 10 H2O Store model is an Ecodesign ‘boiler stove’ with a substantial 4.7 kW room heating output and 5.5 kW of water heating power. It provides supplementary water heating for radiators, showers and general domestic hot water. Commenting on the success of the Dik Geurts range, DRU UK general manager Niall Deiraniya said: “The Dik Geurts Ivar series and its associated models are among the best performing and best value wood stoves in Europe. That is why we are committed to increasing their production and distribution throughout the UK. “In return, we offer high profitability, regular stocks, prompt deliveries, nationwide technical and marketing support, friendly customer service and expert account management.” For further information email: info@drufire.co.uk or visit www.dikgeurts.co.uk

Vicaima Unveils The Main Decor Trends For 2023

Comfort, exquisite details and technology lead the world of architecture and decoration in the transition to a new year of potential challenges and possibilities.

Forecasting what 2023 holds for the world of architecture, construction and interior design is a demanding challenge, but history proves that in a period of metamorphosis corresponding opportunities present themselves for growth and renewal. Faced with a multitude of possibilities, in times that evoke beginnings, comfort and energy, Vicaima outlines the main trends that could be incorporated and inspire new projects in the year ahead.

Well-being, above all - Following a remarkable pandemic period, the desire for large spaces and open decor settings, in which natural light and innovative elements flourish, has become increasingly popular. Today, the aim is not merely to conceive a unique design, but to blend the aesthetic focus with maximum functionality and adaptation to different daily needs, in which the rooms are suited to the recovery and rejuvenation demanded by daily life.

As one of the largest European players in the design and production of cutting-edge solutions for interior doors, technical doors, frames, wardrobes, panels, and furniture items, Vicaima provides models that improve the accessibility of spaces and functional design, such as the Portaro® Sliding Door solution, which integrates door, frame and accessories in a single piece.

The company also features complements that promote the perfect harmony between the aesthetics of interiors and a welcoming environment, as demonstrated by the glazing options, reflecting the physical comfort in the emotional wellbeing of each resident.

Bold details ruling spaces - In a highly globalised and interconnected world, interiors now incorporate increasingly unique and customised accessories and identity traits, in an organic approach, with the addition of details that define the personality of projects, appealing to different audiences. Through a wide selection of models, coatings, and finishes, the Vicaima solutions are the ideal match for balanced and contemporary spaces.

Viva Magenta: A fusion between this new Pantone colour and the identity of Vicaima - A symbol of the increasing presence of bold and exquisite details, which put in evidence the freedom of self-expression and nonconformism with restrictions, is summarised by Pantone. The colour elected by Pantone as the "colour of the year" and the visual identity of Vicaima, evident in its logo, meet in their similarity as the summary of everything that 2023 anticipates.

Vicaima options allow the achievement of a distinctive personality through finishes such as Naturdor®, Dekordor® and Lacdor, whose palette of tones allow a synergy with the Pantone colour of the year for an ideal blend. Viva Magenta, in all its grandeur, reveals the optimism and vigour that drive a unified demonstration of strength.

Alongside these attributes, Viva Magenta is a shade rooted in nature, capable of driving a design that portrays a better future, a key feature in a period of growing environmental awareness. For the sustainable conservation of ecosystems, all Vicaima products are FSC® (Forest Stewardship Council®) certificated.

The symbiosis of tangible reality with the virtual universe - With the development of home automation and technological innovations, 2023 promises a greater incorporation of digital elements in interiors, adapted to the current lifestyle pace and the frequent use of mobile devices. A trend proven by the choice of Pantone, which explores the dynamic between Artificial Intelligence and human creativity, by creating a hybrid colour that portrays a balance between warm and cold, reminiscent of our

multidimensional world. Mindful of the latest developments in the sector, Vicaima offers the Infinity concept, that shapes the virtual into the tangible through an avant-garde style, employing high-end technology and a mix of innovative production processes that allow the creation of customised designs and coatings in essential elements such as doors, panels, wardrobes, and furniture pieces. Characterised by enabling infinite possibilities in any project, Vicaima Infinity defines creativity as its only boundary, aimed at sectors such as hospitality, housing, health, offices or commercial spaces.

As 2022 shaped architecture and design through Nature, minimalism and sustainability, 2023 heralds new dynamics and methodologies. Faced with volatile periods, Vicaima reaffirms its continuous renewal of styles and its firm commitment to quality, displaying this avant-garde attitude on its international presence in projects of excellence and in a close involvement with construction industry professionals everywhere. www.vicaima.com

Yorkshire Housebuilder Specifies Stelrad Radiators For All Its Developments

Radiators are the key sharer of heat around homes in the UK and many housebuilders are specifying designer radiators because they want their customers to benefit from a premium product as part of the new home’s specification. One of these is Erris Homes, based in Leeds. Erris Homes is a provider of modern and luxurious new family homes across Yorkshire.

The company has chosen the Compact with Style design radiators from Stelrad –another Yorkshire-based company – with more than two and a half million radiators a year manufactured at its manufacturing plant in Mexborough, near Rotherham in South Yorkshire. Purchasing radiators from a locally based manufacturer is definitely a plus for Erris Homes as it means it is not only supporting its local supply chain but also minimising its environmental impact due to the reduced distance of transport for the radiators from the National Distribution Centre alongside the Stelrad factory to the sites around Yorkshire.

Chris Harvey is Head of Marketing at Stelrad: “It means a lot to us to see housebuilders making a positive decision to select premium panel designer radiators for their homes and Erris Homes is one of the housebuilders in the UK that has decided to select a model from our Stelrad range.” The Compact with Style offers a clean, crisp, flat fronted radiator with a horizontal lined fascia. The subtle architectural look and feel of the Compact with Style is combined with value, range and availability to provide a sophisticated, designer styling for any room, commercial or domestic, at affordable prices. It’s available in 126 different models – horizontal, vertical, lo-line and coloured versions. www.stelrad.com

ESG Switchable™ Glass Finds

Spiritual Home At St Dionis Church

ESG Switchable™ glass has been used to create a new multi-use space for the church and community at St Dionis Church in Parsons Green, London. Ion Glass, which provides bespoke structural glass solutions for a range of distinctive buildings, including churches, specified ESG’s Switchable™ glass as part of a stunning refurbishment of the historic Anglican church building.

Using meticulously cut ESG Switchable™ panels, Ion Glass installed new glazing to gothic arches at the rear of the church, separating the main worship area from the newly enclosed area. They also added new privacy glazing to shield the church hall from the public gaze, so that meetings and functions such as weddings can take place in privacy.

The church’s gothic arch shapes made for quite a challenge for leading glass processor ESG, whose expert technicians cut the required panels to the precise shape of each arch using advanced CNC techniques while preserving the functionality of the privacy interlayer. This complex task also required the Switchable™ interlayer to be cut to the exact shape and dimensions of each arch with pinpoint accuracy, making each panel a truly bespoke project.

ESG and Ion Glass worked together to ensure that not only did the ESG Switchable™ glass fit to perfection, but that the connections for mains wiring to provide privacy at the touch of a button were positioned so that the wiring itself could be routed as discreetly as possible in this historic setting. Ion Glass and ESG have collaborated successfully on a number of projects, ESG’s glass processing expertise perfectly complementing Ion Glass’s innovative and imaginative approach to refurbishing and replanning unique built environments.

Susan Sinden, Commercial Manager for ESG Group Ltd commented, “This has been one of our most satisfying projects, as our experts really enjoy finding solutions for unusual applications. This was one of our most complex CNC challenges to date and the end results are quite exceptionally beautiful.”

ESG is renowned for its collaborative approach, working in consultation with its clients on both product development and delivering world class glazing solutions for a multiplicity of applications and settings. www.esg.glass

Rundum Meir Façade Doors Uniquely Reflect Manchester Landmark’s Heritage

A bronze façade featuring integrated Rundum Meir garage doors for two new townhouses in central Manchester has been uniquely designed to reflect the architecture of the nearby John Rylands Library, one of the city’s most famous neo-Gothic buildings.

The duo of four storey, high specification private dwellings designed by Snook Architects for regeneration specialist Watch This Space have given new purpose to an unused site nestling between two post-industrial buildings close to Deansgate. Their full height bronze façade delivers a striking external appearance that takes a distinctive visual cue from the library, located opposite.

The houses are designed around an inverted living approach, enabling the architects to maximise the footprint of the site and use the space to its full potential. Above the garages are floors accommodating the bedrooms, with the living, dining and kitchen areas on the upper floors, and a rooftop courtyard/garden completing the arrangement.

Photos © Andrew Haslam Photography (andyhaslam.com)

The aluminium façade of both townhouses features laser cut and acid-etched lacy blind tracery patterns that match those in the windows of the library, a late Victorian neo-Gothic building which opened in 1900 and is now part of the University of Manchester. The lacy pattern extends over the full height of the façade which includes large folding/sliding shutters.

These balance privacy with natural light requirements for residents during the day whilst being eye-catching at night as internal light shines through the laser cut pattern. This design extends into the twin side sliding sectional garage doors manufactured and installed by Rundum Meir, which effectively deliver a sliding façade at street level.

Working closely with architect Neil Dawson, Rundum Meir’s designers were able to replicate the design with total consistency and manufacture in Germany using acid etching across the six aluminium sections. Neil Dawson of Snook Architects said: “Watch This Space approached us to look at how they could transform this

city centre site and we immediately saw the potential to take design inspiration from the nearby John Rylands Library. The resulting façade is unique, and through the movement of the shutters and garage doors during daily life it is constantly moving and changing."

“The laser cut pattern means that the building really comes to life at night as the internal light makes the intricate façade design a stunning feature. To be able to match this styling in the garage doors was crucially important and the result reflects the bespoke craftsmanship provided by Rundum Meir.” The twin Rundum Meir sliding garage doors each provide a clear opening of 3.8 m for easy vehicle access from the street.

Hand made using extruded aluminium, the fully automated bespoke garage doors have an automated pedestrian door as well as the side sliding door that demonstrate the design flexibility offered by Rundum Meir, who create every garage door to meet project requirements. www.rundum.co.uk

Profab Access Adds A Five Star Finish To Cardiff’s Newest Luxury Hotel

Leading riser door and access panel solution supplier, Profab Access, has proven its first-class credentials once again as part of the recent completion of a major specification at Cardiff’s new 5-star Parkgate hotel. Located next to the Welsh Capital’s famous Principality Stadium, the Parkgate hotel has been designed to provide a luxurious experience for rugby fans, in addition to city dwellers visiting the country all year round.

Widely coined as Cardiff’s most lavish new location, the hotel includes 170 guest bedrooms and suites, a signature restaurant and bar, a traditional tea lounge and a rooftop spa overlooking the city skyline. As part of the prestigious build, a unique collaboration between the Welsh Rugby Union, property developer, Rightacres, and The Celtic Collection,

the hotel required an extensive riser door specification, with safety, high performance and aesthetic appeal key considerations.

In total, 310 Profab Access VEGA 1500 Fire Rated Riser Doors were specified for installation by Hazelwood Carpentry throughout every part of the building, including communal areas and the hotel’s vast range of luxury guest rooms and suites. The VEGA 1500 Series Riser Doors offer the highest standards of fire safety, extensively tested by Efectis in France and Ireland to provide a bidirectionally fire tested product that is available in both single and double door configurations.

This means the riser door sets are fire tested from both sides to 60 minutes, providing the specifiers, contractors and hotel guests residing within the building with confidence the critical fire integrity products offer the highest standard and most up to date evidence for fire safety performance. The range also features a slimline, neat construction, whilst its proven technology ensures permanent, safe access to mechanical and electrical services housed within the riser core.

This provides first class functionality and safety, without compromising the overall interior concept. The steel riser doors also streamlined the installation process, as the quick release pivot hinge and light weight enabled easy handling, allowing Hazelwood Carpentry to complete the job quickly and optimise overall project efficiencies.

In the event of a fire, the VEGA 1500 Series Riser Door sets will maintain the frame and integrity for up to 60 minutes, preventing the spread of fire throughout the property for this period of time. The riser doors are

31dB acoustic rated, smoke sealed and airtight to Part L, whilst also featuring intumescent smoke seals that enable occupants to safely exit the building. By specifying bidirectionally fire tested VEGA 1500 Series Riser Doors, the development is actively future proofed as the comprehensive testing certification provides a complete and transparent audit trail of due diligence that evidences the products are not only fit for purpose but meet the duty of care required to ensure legal compliance.

Profab Access’ diverse portfolio of riser doors and access panels are supported by a wide range of BIM Level 2 and CAD files to aid the specification process and streamline the initial design stages. Manufactured at Profab Access’ Atherstone headquarters in accordance with ISO 9001, the 1500 Series Riser Doors can be specified and installed in a range of configurations to meet each project’s measurements and requirements. www.profabaccess.com

Remember Me

The Remember Me memorial portico at St Paul’s Cathedral is a physical memorial to all those that died as a result of the Covid-19 pandemic. Entered via the cathedral’s North Transept entrance it is home to the online book of remembrance.

Designed by Caroe Architecture with Connolly Wellingham, the portico is a beautiful, elliptical structure crafted in the UK and featuring several GEZE doors.

As a visitor enters the cathedral from the North Transept they pass through a pair of swing doors powered by GEZE Powerturn automatic swing door operators. These doors take the visitor

into the memorial and were chosen as they can open large or heavy doors and offer the flexibility of allowing the doors to be used both manually and automatically due to GEZE’s Smart swing function.

Above the doors, etched in to the structure in gold are the words ‘ Remembering all who died as a result of the coronavirus pandemic’. Once inside the portico, visitors can view the online Remember Me memorial, search for and view the tribute to their loved one, light a candle and take a moment to pause and reflect in this tranquil space.

The online book is open to all people, whatever their faith or none. From the memorial portico the main entrance into the cathedral is through GEZE’s TSA 325 NT, a manual revolving door with 4 leaves. The revolving door was chosen as it minimises air flow into the cathedral as only one quadrant is open at a time.

To ensure access for all a GEZE Slimdrive SCR curved automatic sliding doors was installed opposite the revolving door enabling those who are less able, or people with children in buggies, can still visit the memorial and access the cathedral. The Slimdrive SCR is controlled by wave sensors to ensure the doors only open when requested. This is part of the portico’s design to minimise air flow. Across all the glass in the doors are beautiful phrases such as ‘we will always remember’ and ‘never forget’. The Remember Me memorial portico is a poignant tribute to

those who died as a result of the Covid-19 pandemic and is the most significant change to St Paul’s Cathedral in 300 years. Following the public response to the online memorial, and in partnership with the Daily Mail, over £2million was raised to give the Remember Me memorial a physical home within the Cathedral.

Said GEZE’s National Specification Manager, Richard Richardson-Derry, ‘We were honoured to play a part in the construction of the Remember Me memorial. The combined challenges of minimising air flow, ensuring equal access and creating a beautiful structure to recognise those lives lost has been successfully achieved’.

www.geze.co.uk

Smart Launches Innovative New Ranges At Futurebuild

Smart Architectural Aluminium displayed an extensive range of new products and systems at this year’s Futurebuild exhibition. With innovative solutions across its three core product areas, visitors saw a wide range of both completely new products and product evolutions across each of the company’s Internal, External and Outdoor Living collections.

At the heart of the stand was the company’s new Signature Door range which was launched at the show. The range brings a completely new collection of entrance and back doors to sit alongside Smart’s established Designer Door range (for which, a new double door option was also unveiled), opening up an even broader audience for these high quality, high security doors. Two new additions to the Visoglide sliding door range were also on display.

Visoglide offers contemporary styling and is the perfect solution either for sliding commercial entrances where large opening apertures are required, or as statement sliding door for residential properties.

Visoglide doors combine strength and weather resistance and the range now includes two new products: InVisoglide, a bonded-glazing door, and Thermaglide, a highly energyefficient. Featuring a new bonded glazing system, InVisoglide provides enhanced security and extremely slim profiles to create elegant

architectural lines. The bonding process also enables all four sides of the outer frame to be concealed in the aperture.

Thermaglide builds on the proven performance of the established Visoglide range to provide architects and developers with a highly energy efficient option, achieving u-values of 1.4W/ m K with a 1.0W/m K centre pane and 1.16W/ m K with a 0.7W/m K centre pane. In keeping with the slim lines and elegant aesthetics of the entire Visoglide range, the new Thermaglide door features perimeter sightlines of just 115mm, with the option of a 20mm interlock profile.

Elsewhere on the stand were a new opening vent for Smart’s Aliver roof light and additions to the Alitherm 400 window and door system. Commenting on the company’s presence at the exhibition, Smart’s Managing Director, Eddie Robinson, said: “We were pleased to have such a prominent display at Futurebuild 2023, and particularly to showcase such a broad range of innovative new products across all our ranges. “The feedback from visitors to the stand was extremely positive and we look forward to working with our partners, architects, developers and designers over the coming months on some of the projects that we discussed.” www.smartsystems.co.uk

ADSA JOINS INFLUENTIAL IFATE EMPLOYER DIRECTORY FOR APPRENTICESHIPS

The Automatic Doors Suppliers Association (ADSA) can now be found in the Employer Directory, run by the government-backed Institute for Apprenticeships and Technical Education (IfATE), which aims to heighten industry alignment between apprenticeships and occupational needs. The inclusion rubber-stamps ADSA’s position in spearheading professional standards and its role in developing a future workforce for the automatic door industry.

ADSA had to meet a rigorous criterion to gain its place in the directory. It also had to demonstrate its experience and capability to fulfil its role as an occupational expert and ensure that no conflicts of interest would prevent it from operating as such. Directory entrants need to submit written submissions for assessment, with successful candidates attending a seminar on their role within the partnership at the end of September. The directory is intended to promote industry input in the evaluation of apprenticeship end point assessments (EPA). It highlights the importance of partnerships with industry recognised professional organisations.

ADSA managing director Ken Price said: “Our inclusion will help ADSA progress the aims of our industry by enabling us to work with organisation such as Ofqual and the Office for Students, contribute to end point assessment organisation forums and discussion groups, and support efforts to improve external quality assurance.” For more information about ADSA membership or services visit: www.adsa.org.uk or email: rachel@adsa.org.uk

Cheers! Crittall Boosts Brewery Transformation

Described as Dorchester’s most iconic building, the Brewery – once the source of the much-quaffed Eldridge Pope ales – has been transformed into a high-end residential setting with Crittall windows playing a central role in retaining the heritage aesthetic of this historic structure. For nearly a century and a half the building, with its tall chimney, towered above the Dorset town as a symbol of local industry and prosperity.

Designed by architect WR Crickmay the brick building was completed in 1880. At a staggering 13% the brewery’s Thomas Hardy Ale once featured in the Guinness Book of Records as the strongest commercially brewed beer in the country.

The brewery eventually closed in 2003 and the site remained unused until, in 2007, planning permission was granted for a new public square overlooked by the impressive building, restored to its former glory containing 29 one, two and threebedroom apartments.

LMA Architecture of Bournemouth has retained many of the unique

features of the original building including riveted steel beams, cast iron columns and exposed brickwork.

Crittall Corporate W20 steel windows and doors were a natural choice, glazed in small panes to replicate the original configuration of the tall brewery windows.

www.crittall-windows.co.uk

OMNIE WHOLE-HOUSE SOLUTION FOR DEVON BARN CONVERSIONS

The conversion of three stone-built agricultural buildings near the beautiful Devon town of Totnes is employing a full selection of renewable and low-energy technologies from OMNIE, to create a comfortable living environment for the new occupants. The hundred year old buildings at Ritson Farm are being renovated and turned into highly desirable rural retreats.

Each home is to be heated by an LV air source heat pump, which will be connected via multi-branch manifolds to OMNIE’s Staple underfloor heating system across the ground floors with the company’s LowBoard being specified to warm the upper levels.

A constant supply of pre-warmed and filtered fresh air will be supplied via one of OMNIE’s Zehnder ComfoAir mechanical ventilation with heat recovery (MVHR) units. The Totnes conversions vividly demonstrate how high efficiency heat pumps, combined with underfloor heating developed to bring the best performance from them, can heat any home and keep fuel consumption to a minimum. www.omnie.co.uk

DOMUS VENTILATION MVHR SYSTEMS PROVE IDEAL RETROFIT SOLUTION FOR LONDON RENTAL DEVELOPMENT

Domus Ventilation’s HRXE-HERA® Mechanical Ventilation with Heat Recovery (MVHR) systems have been specified for the be:here Hayes build-to-rent residential development in West London. When the building was designed, Domus Ventilation’s Silavent MVHR ceiling mounted units were installed. These are now being gradually replaced with Domus Ventilation’s latest MVHR model, HRXE-HERA®. As a retrofit solution, HRXE-HERA® has proven ideal for be:here Hayes as they readily use the existing Domus ducting.

Domus Ventilation’s HRXE-HERA® MVHR have proved an ideal solution. It filters and pre-warms fresh air drawn into the apartment using the heat from waste stale air extracted from the kitchen and bathroom using a heat exchanger. It’s advanced heat exchange proficiency enables up to 95% of waste heat to be recovered. It comes with 100% thermal (summer) bypass which automatically activates when the air temperature reaches a pre-set level, allowing in cooler, fresh, filtered air without warming it through the heat exchanger. The smart design of the HRXE means there is no reduction in airflow when operating in bypass mode.

www.domusventilation.co.uk

NEW PROGRAMMABLE ROOM THERMOSTAT LAUNCHED BY ESI

ESi has responded to the current economic climate with the introduction of its latest quality heating control – the RTP4 Touch programmable room thermostat. This latest introduction is capable of controlling heating and hot water systems via combi, system or heat only boilers. When installed with the ESi WIFI hub, homeowners and tenants heating and hot water can be controlled via Alexa or the ESi Centro App. Vitally, the load compensation functionality, available via OpenTherm technology, modulates the flow temperature dependant on the desired room temperature, saving up to 15% on gas usage – a benefit not to be overlooked in the current situation where energy prices have leapt to a huge new high in the UK.

The 4 Touch has a large backlit LCD display and touch screen making it simple-to-use and programme. It offers optimum start/ stop and delayed start functions offering additional cost savings for users, 7 day, 5/2 day or 24 hour options to suit the homeowner or tenants lifestyles, automatic summer/winter change settings and has home, manual, away, sleep and holiday modes long with its popular landlord service interval reminder. The new unit is battery controlled and comes with a low power indicator to show simply when the battery needs replacing. www.esicontrols.co.uk

NEW LOWBOARD 2 UNDERFLOOR HEATING OVERLAY: THIN JUST GOT THINNER

OMNIE, the award-winning UK underfloor heating specialist, has launched a new, low profile, overlay panel, LowBoard 2, the latest upgrade to its industry-leading LowBoard panel which transformed the overlay market when it was launched in 2012. LowBoard 2 consists of routed lower and upper panels with a combined profile of just 18mm, making it the thinnest overlay system on the market. Its predecessor, LowBoard, had a lower panel profile of 15mm but, like other overlays, LowBoard also required a ply upper layer which can add at least 6 mm to its overall depth.

LowBoard 2 is quick and easy to install and offers outstanding heat performance thanks to its innovative design. It has a 15 per cent higher heat output than its predecessor and a 40 per cent higher heat output than other unfoiled low build-up systems or alternative overlay solutions. Its lower and ‘over’ panels have pipe channels that tightly sandwich and encapsulate the warm water pipe.

The routing follows OMNIE’s patented multi-directional pipe channel pattern, eliminating the need for separate straight and loop panels while also ensuring the warm water pipe can be easily laid around any planned room layouts. The channels are spaced 150mm apart for optimal heat output and transfer. The upper ‘over’ panel is 6mm thick wood fibre (or 12mm plywood for tiled applications) and the proportional pipe channel pattern places the encapsulated warm water pipe within 3mm of the floor surface. www.omnie.co.uk

LG Success For New Therma V Monobloc ‘S’ Heat Pump

LG is seeing significant success following the introduction of the latest version of its sector leading Therma V Monobloc air to water heat pump – the Therma V R32 Monobloc ‘S’. The ‘S’ stands for ‘Silence’ and ‘Supreme’ to highlight its reduced noise level and best performance criteria. It's proving to be a commercial success across the UK and Ireland.

The announcement from the UK Government that it would provide a £5,000 grant from April 2022 to individuals choosing to install a heat pump over existing fossil fuel driven heating systems was the next crucial step towards major uptake of proven heat pump technology in preference to reliance on gas, oil and solid fuel options for domestic heating and hot water provision in the UK.

The recent announcement that this level of support will be extended into 2028 will help even more people to switch from traditional

boiler driven systems to renewable heating and hot water. The Future Homes Standard requires serious action and quickly if targets are to be met. Renewables and higher standards of building quality in, for example, recognition of better standards of insulation in homes are key to meeting the aims of the FHS.

Heat pumps have a major part to play. As with the original Monobloc, this new model combines the indoor and outdoor features in one module. It’s also connected by only water piping, eliminating the need for refrigerant piping, making this heat pump an installer’s dream when it comes to ease of installation.

Hydronic components like the improved plate heat exchanger, the expansion tank, water pump, flow sensor, pressure sensor, air vent valve and safety valve are all built in - inside the outdoor unit – pre-installed and ready to run.

And the R32 Monobloc ‘S’ provides excellent heating performance especially at low ambient temperatures whilst lowering its carbon emissions even more with the use of R32. This new unit sees built in water flow and pressure sensors to monitor the water circuit in real time, advanced water pump control, enhanced second circuit logic, energy monitoring of estimated power consumption via the remote controller, MODBUS connectivity without Gateway if required and advanced control for the domestic hot water recirculation pump.

The Monobloc ‘S’ is equipped with a new advanced remote controller which supports a number of functions. It comes with a premium design 4.3-inch colour LCD monitor, user friendly interface that uses simple graphic, icon and text controls, easy schedule and installer settings and energy monitoring without meter interface to provide estimated power consumption figures.

It is possible to monitor not only the temperature of the water circuit but also the flow rate and the pressure. The original version was extremely quiet, but this new ‘S’ version is even quieter and up to 9kW units can be installed at the minimum of 4 metres away, and up to 16kW unitsup to 5 metres away from neighbouring houses complying with international noise regulations.

The heat pump has been awarded the Quiet Mark in the last couple of months highlighting the Therma V Monobloc S as one of the quietest heat pump options available. And through the use of LG’s ThinQ technology it can monitor and control compatible LG products remotely - ThinQ technology also works with voice activation with Google Homes. The unit comes with a Seasonal Coefficient of Performance of up to 4.67 (Average climate/Low temperature application) and

a A+++ rating. The COP rises to 4.9 (Outdoor air 7°C/Leaving water temperature 35°C) and can deliver leaving water temperature of 65°C if required. For more information on the new LG Therma V Monobloc ‘S’ head for partner.lge. com/uk, or email LG at uk.aircon@lge.com.

The Role Of The Heat Pump In Today’s Changing Climate

By Jason Allen, Commercial Product Manager at Hamworthy Heating

With rising energy tariffs and increasing awareness of our environmental impact, maximising energy efficiency plays a key role in helping to lower operational costs and meet the required regulations. While it is, without doubt, a difficult time, some steps can be taken, which can also help to accelerate the transition to the UK government's net zero goal for 2050.

Regulation driving change - The ‘Heat and Buildings Strategy’ launched in October 2021, is the UK Government’s plan to decarbonize virtually all heat in buildings and is fundamental to the Net Zero goal. At the heart of this strategy is phasing out the use of fossil fuels to heat buildings by 2035, whilst increasing the application of low-carbon products, fuels, and energy sources.

The uplift of Building Regulations ‘Conservation of fuel and power: Approved Document L’, introduced in December 2021 and in force as of June 2022, is the legislative method adopted to ensure new buildings will be fitted with low-carbon heating and high levels of energy efficiency achieved. Under the new framework, decarbonising heating is key to cutting emissions across commercial buildings.

If we look past the building fabric and focus solely on the heating system, one of the main points highlighted in the latest regulations states that a heating system must be designed to work at 55ºC flow. This new legislation will effectively mean an end to like-for-like boiler replacements and will eventually phase out the use of non- condensing units in new and existing buildings altogether, except under exceptional circumstances. This means that only high efficiency condensing gas boilers will meet the minimum requirements. However, when it comes to sustainability, there’s no doubt that heat pumps play a key role towards achieving the Net Zero goal.

How do heat pumps work? - Heat pumps gather heat energy from the surrounding air which, via a heat exchanger, is transferred into the heat pump’s refrigerant and turned into vapour. The vapour is passed through a compressor and turned into high pressure, high temperature refrigerant, raising the temperature to a point that can deliver heat throughout a building's heating system. Heat pumps don’t require high external temperatures to function; they can continue to operate with external air temperatures down to -20ºC.

What makes heat pump technology energy efficient? Heat pumps are up to three times as efficient as a gas boiler. Heat pumps change low grade heat into useable heat, with the most popular type being the Air Source Heat Pump. This uses a small amount of electrical energy to transfer the ambient heat in the air outside of a building and move it inside, where, at a higher temperature it can then be used for underfloor heating, radiators, or maintaining a supply of hot water.

Delivering up to 4 kWh of energy for every 1 kWh of electricity used to power it, heat pumps can be 300 to 400% more efficient than electric heating alone. But the benefits don’t end there. In addition to providing a controlled climate with improved air quality, once correctly installed by a qualified installer with maintenance in line with manufacturers recommendations, a heat pump could last between 10-25 years, or more.

Different types of heat pumps - Air source heat pumps are divided into two types: split and monobloc units. A split heat pump has both an outside unit (incorporating the heat exchanger and compressor with pipework containing refrigerant connecting to the internal hydrobox). A monobloc heat pump contains all the refrigerant components in the outdoor unit, leaving more space inside the property The benefit of this means monobloc units are easy to install and maintain.

Features to consider - Accurate control of any heating appliance is crucial to efficient operation, so ensuring appliances are sized to meet the correct load requirements of the building is the first step.

In terms of efficiency, we also need to consider the COP (Coefficient of Performance) of a heat pump. The higher the CoP, the more efficient the heat pump, which equals lower cost operation. Controls are another important feature, particularly when it comes to unpredictable UK weather. Here, a heat pump with an inverter controller compressor will adjust accordingly and accurately meet the heat demand of a building.

Refrigerant is also a vital component of a heat pump and is an important factor to consider when it comes to determining sustainability. Heat pumps that use refrigerants with a low Global Warming Potential (GWP) should be a priority. The Tyneham range of heat pumps from Hamworthy Heating, for example, uses R32 refrigerant which has a very low GWP and a zero Ozone Depletion Potential (ODP), R32 refrigerant, compared to other traditional refrigerants.

Lastly, when it comes to specifying a heat pump, consider brand reputation and look for a manufacturer that provides backup and long-term reliable technical support and customer service. www.hamworthy-heating.com

Window Energy Ratings or U-values?

By Wojciech Brozyna, Managing Director Aluprof UK Limited

Back in 2005, the Glass & Glazing Federation (GGF) took over the British Fenestration Rating Council (BFRC) and then gained Government acceptance of the then new, Window Energy Rating scheme (WER’s). At the time these ratings became a means of compliance with Building Regulations. As all WERs are based on the same standard sized window, and enable direct comparisons across various manufacturer's products, this helps customers in product selection.

By combining a window’s solar gain benefits, its air permeability and thermal efficiency in a simple calculation offers an easily understood ‘banding’ of performance, the result of which is something that the wider public already understands from the sale of domestic electrical goods. As we now move to higher performance windows and the need to thermally enhance our complete building fabric, are WER’s still the best measure?

With the next announced change in Building Regulations just two years away, when the Industry will be expected to offer window U-values of below 1.0 will this mean that the current WER banding becomes mostly obsolete? When first launched, the WER scheme offered ratings across a band of A to E, more recently the band is running with two further ‘A’ bands of ‘A+’ and ‘A++” which recognise higher performance windows.

Will bandings need to be realigned if we decide to continue to use them in the future? In reality, the choice of window performance on WER’s alone is flawed. When the energy performance label was introduced for electrical goods back in 1995 products bought and used across the UK would perform very much the same in any home, the same cannot be said for WER’s.

Windows chosen on a WER will be made to measure, in various configurations, installed in various constructions, located in different geographic locations and in various orientations.

Windows facing South will realise a high solar gain, whilst those facing North will experience very little so, the ‘best’ WER performance window chosen may not be the best performing in use and therefore not the most cost effective choice. It is well understood today that a holistic optimisation of the complete building fabric is more beneficial in terms of energy and environmental savings than a component-bycomponent approach.

The provision of a calculated window U-value for a given configuration can then be used in the formulation of a building's thermal performance, a WER cannot. Homes in the future will have to be built to and refurbished to a very high thermal standard which then require very little energy to heat, indeed, some high performance buildings could actually generate more energy than they need, producing excess ‘green energy’ which can then be used elsewhere. There are various schemes and specifications that enable architects to construct or renovate buildings to meet very high thermal standards whilst maintaining a healthy internal environment.

Passivhaus is a well known specification which is rapidly becoming the specification of choice for architects. Based on a ‘fabric first’ approach, the complete building fabric must be carefully designed with high insulation materials taking great care to eliminate cold bridging either inside a building element or where various building elements interface.

One of the challenges of good fabric design within Passivhaus, is the window frame interface to the structural reveal of a building, particularly in an existing building.

Whilst not all our future buildings will be built to the Passivhaus specification, the basis of this specification is logical and there will be alternate specifications agreed upon. Scotland has already agreed that in a couple of years all new homes will be built to their version of a Passivhaus standard.

So, whilst there has been a swing in the past to use WERs as a simple tool of energy performance, the industry will swing back to using the U-value as this measure will be needed to design good thermally efficient spaces within buildings. In future, it is not going to be acceptable to simply place a high performance window into a thermally inefficient reveal. Not only will this window not perform as expected, but it’s also simply not cost effective.

Whilst WERs are basically a tool for the public to be aware of energy performance of various products, we can see that in the future window replacement will be coupled together with building structure thermal improvements, this will likely be seen in new building regulations that will stop the simple replacement of windows in an existing structure. Far from restricting sales of windows and doors for home improvement companies, there is huge potential for these companies to rise to the needs of the country to help improve all our building stock to meet our commitment to being carbon neutral by 2050.

Further information about systems and specification support is available through the company’s website at aluprof.co.uk or direct from their UK head office in Altrincham by phoning +44 (0) 161 941 4005.

SureSet On A Mission!

Founded in 1987 with what was originally a reasonably sized house with over 14 acres of land, The Anoopam Mission soon became a beautiful Swaminarayan Temple located in a quiet and secluded part of Uxbridge in South Buckinghamshire. It opens its doors to help those who need it the most, without any discrimination of other faiths and the non-religious, of their class, creed, colour or gender.

Since 2016 SureSet have been working with the Anoopam Mission alongside MEB Design and Beard Construction to complete their project vision of creating the biggest multicultural campus in the United Kingdom. It would have been easy to implement a traditional paving surface but it was decided to use SureSet for all of the pedestrian surfaces.

Using SureSet guarantees no loose stones, because its resin bound system completely infuses the raw material whilst leaving voids for permeability, which also influenced its specification. The project included a total area of 1180m using SureSet resin bound paving materials on the steps and pedestrian entrance to the tranquil Temple.

The colours chosen were from a natural earthy terracotta and uplifting light sandy marble palette. The areas were prepared using permeable open graded asphalt as the base, ideal for SuDS (Sustainable urban Drainage Systems). SureSet's most recent visit back to the premises of the Swaminarayan Campus, just off the A40, was for another approved building phase at Anoopam Mission. It was originally applied for in 2019 to build a Hindu Crematorium.

Anoopam Mission continued to use SureSet for this phase for it was an easy to maintain surface that was accessible. The aggregate colours were kept the same for consistency, creating a continuous flow around the new crematorium building, it was important to continue the same colours used in the first phase of installation as it gives a sense of connection. A fully permeable 14mm open-graded asphalt base was prepared prior to SureSet's arrival. The SureSet paving team completed a full installation of 717m with BBA Approved resin bound materials at a 16mm depth.

The main resin bound colour used was a natural warm red 3mm aggregate known as Tuscan Barley Butter. The chosen warm terracotta colour was perfect to feature around the grounds as it matched the redwood window frames and exterior building features beautifully. The second area of materials SureSet installed was 105m of 3mm luxury resin bound marble, named Buttermilk, a light white sand colour. It was used in the design as a striking decorative border around the crematorium outlining the shape of the building, blending in well with the surrounding colours.

www.sureset.co.uk

MAPEI ULTRATOP LOFT COMPLEMENTS VICTORIAN HOUSE IN BALHAM

Warwick-based surface design specialist – BaSE (www.baselifestyle. co.uk) - has completed a stunning ‘trowel effect’ floor installation using Mapei’s Ultratop Loft. The installation forms part of a kitchen renovation project within the basement of a period property in Balham, South London. Home of interior designer Charlie Nunn and husband, Richard, the large Victorian property has an eclectic style owing to the owner’s creative nature, with colours and artwork adorning the walls. As well as providing a city base for Charlie and her family, the home is used as a location for TV shows and photoshoots and has recently featured in Amazon Prime adverts.

BaSE’s use of Ultratop Loft spans the 50m2 extended kitchen, providing a striking contrast to the red gloss kitchen cabinets and satin wall finish. Ultratop Loft was trowel applied under the existing units and around the cabinet legs; it was applied with a Nuvolato (cloudy) texture in a warm grey called Venezia. The micro-cement based finish replaced a seamless resin floor which had faded in sunlight. A rapid-drying, micro-cement based system, Mapei Ultratop Loft is built up in layers made up of special primers, cementitious layers and hard wearing sealers.

The two cementitious layers - coarse grained Loft F and finer grained Loft W – are mixed with water and colourings to create a trowelable cementitious paste which is then applied in layers up to 2mm thick. Ultratop Loft is part of Mapei’s fast-track range and, in the correct conditions, the surface sets to foot traffic within three hours. The installation was completed with Mapei’s Mapefloor finishing products. Contact: info@mapei.co.uk

BRADITE FLOOR-IT ON THE MENU

Bradite’s versatile, high-performance floor coating, Floor-It, rose to a number of challenges encountered by Norwich-based JB Decorating Services on bars and restaurant projects across the country. FloorIt is a low odour acrylic paint suited to medium traffic areas. It provides an extremely durable surface which is mark, stain and petrol resistant. Its quick drying abilities – touch dry in just 30 minutes and re-coatable after an hour – mean it is highly recommended for business or commercial use, where speed of completion is a major consideration.

“We were after a floor paint that was quick-drying and hard wearing.” Said Jake Bygrave from JB Decorating Services. His regular supplier, Brewers’ South Norwich branch, recommended the Floor-It product.

“I was very impressed with it. The application was fantastic.” says Jake, who decorated the floors of three bars in London, Plymouth and York, each with different substrates.

One floor was a non-porous concrete floor and another had been previously painted. As a versatile floor paint suitable for a range of internal or external surfaces, Floor-It was the ideal topcoat for a smooth, durable finish. The third premises had a floor newly fitted with plyboard, and here Bradite One Can was used as a strengthening primer. Making use of the range of products available from Bradite has ensured a first-rate finish for three demanding jobs.

www.bradite.com

WRAPTITE® PARTNERS WITH HADLEY FRAME FOR AN AIRTIGHT PERFORMANCE

The Wraptite external air barrier system from the A. Proctor Group has enhanced the performance of a considerate inner city development of retirement living apartments working in partnership with the Hadley Group. The Lichfield’s Bonds retirement living development for Pegasus Life consists of three apartment blocks in the heart of the cathedral city.

Constructing on a compact site and nestled against local residents and businesses required a sensitive building approach and a considerate program design. An essential requirement for the client was ensuring that traffic was not disrupted and that the project positively contributed to the city. The Wraptite external air barrier system was installed in combination with the innovative, unique pre-panelised and fully load-bearing Hadley Frame offsite system, which is ideal for developments of low to medium rise structures.

The superior airtightness performance of the Wraptite membrane from the A. Proctor Group delivers significant benefits to projects combining in-factory manufacture and on-site construction. The selfadhesive design ensures that the membrane is held firmly in place, even during transportation, maintaining the system’s quality from installation to build and completion. www.proctorgroup.com

RESIDENTIAL ROOFS BEING UPGRADED USING FIREFLY’S ZEUS LITE 90/30

A specialist fire contractor is employing the Zeus Lite 90/30 flexible fire barrier and Collaroll wrap from the range of TBA FIREFLY ™ in undertaking a major fire protection programme in Sittingbourne. A phased scheme set to continue till its entire stock is upgraded. DC Fire Protection Ltd. works right across the country covering multiple sectors of the construction industry, installing active as well as passive fire protection systems. It is currently engaged in lining the roofspaces to dozens of terraced houses on an estate in Sittingbourne, Kent.

Director of DC Fire Protection Ltd,. Daniel Mabbott, commented: “We have been dealing with FIREFLY™ for a number of years, including buying large quantities of the Zeus Lite, which we use for commercial contracts as well as residential work such as this - where we are uprating the performance of pitched roofs right across a landlord’s portfolio of properties.” The Zeus Lite 90/30 has been developed for use in vertical separation or compartmentation situations, offering 90 minutes integrity and 30 minutes insulation and is straightforward to install for an experienced contractor. It is widely specified to form fire barriers within roof voids and floor voids in many different property types, including multi-storey flats and commercial premises. Also used throughout this project are fire-rated access panels to provide safe and continual secure access as required, installed within a simple frame built into the flexible barrier wall. www.tba-pt.com

BEFORDSHIRE INDUSTRIAL BUILDING FIRE-LINED WITH A1 MAGPLY BOARDS

A family owned fishing and holiday business in the heart of the Bedfordshire countryside is currently seeing a variety of new leisure and commercial facilities being created, with high performance Magply boards from the range of IPP Ltd. having been chosen for lining a large new caravan maintenance workshop. Henlow Bridge Lakes near Henlow, was established on land surrounding a former mineral workings at the time of the Millennium.. The current work is creating space for more customers to stay, along with staff accommodation and other improvements.

Magply boards carry Euroclass A1 and other internationally recognised certifications, confirming their suitability as a fire mitigating sheathing for timber or steel frame systems, as well as in rainscreen cladding, SIPs and other modular/ offsite constructions. The material also offers impact, racking and pull-out strength. Magply has been awarded a BBA Certificate following stringent assessments, including a six-month leaching test, producing a Zero score thanks to the production process which ensures stability and durability as a substrate in render backer and other applications. www.magply.co.uk

THERMOBLOCKS MAINTAIN CONTINUITY TO ‘ WRAP’ FOR BESPOKE BRISTOL HOUSE BUILD

Bristol based architects Marshall & Kendon have sought technical advice from manufacturer Marmox, regarding the integration of its Thermoblocks into the exterior insulation ‘wrap’ of a bespoke, near-to- zero timber frame construction.

Dovetail Design & Build is building the highly insulated home on an elevated site in Kingsdown Parade once occupied by a 17th century summer house and where the existence of a historically significant cellar required the raft type foundation to permit future access for archaeologists. The founding partner of Marshall & Kendon, Jeremy Marshall, said: “It is our habit as a practice to always run insulation across the outside of the structure, wrapping them rather than putting it within the timber frame. In this instance, Thermoblock enables us to make the layer of insulation continuous as it passes through the loadbearing structure, while the airtightness membrane is continued up the outside of the sheathing boards.'

Marmox stockist, Eco Merchants of Swindon, supplied a total 170 of the 100 mm wide version for the versatile 600 mm long Thermoblocks, with Dovetail’s own operatives utilising an approved adhesive to not only seal the overlap joints, but also to bed the blocks across the OSB base which is covered by a ‘paintable’ membrane. The various lines of Thermoblocks then support the stick-built timber frame exterior and internal walls, with the main isocyanate floor insulation panels infilling the rest of the ground floor area. www.marmox.co.uk

Bilco UK Sets The Standard For Safety At Glasgow Housing Development

Glasgow’s latest redevelopment project, located on Langside Road, is built upon the former site of the city’s Victoria Infirmary and consists of a large housing development that includes 413 flats, offices and retail space.

The 3.75 hectare site, which is situated next to Queen’s Park on the south side of the city, forms an important part of the Battlefield area’s character, with the buildings’ exterior reflecting and complementing the surrounding heritage by using the city's traditional blonde coloured sandstone. As part of the construction process,

Bilco UK was commissioned to supply six ESW-50REM Smoke Vents, in addition to seven E-50TB Roof Access Hatches, to provide the highest standards of safety and efficiency, whilst being sympathetic to the project’s overall design. Installed onto the roof areas of four blocks of flats by Scottish contractors, Procladd Small Works Ltd, Bilco UK’s ESW-50REM

Smoke Vents were specified to provide essential ventilation in the event of a building fire. Featuring a linear actuator operating mechanism that opens the cover to 140 degrees within 60 seconds, the smoke vents ensure compliance with Building Regulations Approved Document B, BS9999 and EN12101-2.

The built-in wind deflector also provides protection against smoke being blown back into the vent in the event of a fire., whilst the newly-designed closedcell EPDM sponge gasket helps meet Building Regulation air leakage targets by providing a better seal of the cover to the curb. With the addition of a fixed vertical ladder, the smoke vents can also be used by maintenance engineers for roof access.

Billy Baillie, Managing Director at Procladd Small Works Ltd, said: “We have a longstanding relationship of over 20 years with Bilco UK, and will continue to do so over the forthcoming years, due to their impressive product quality and outstanding service. Bilco UK’s Roof Access Hatches and Smoke Vents were incredibly easy to install, and knowing they’re engineered to meet the highest industry standards, it provided both ourselves and the client with the confidence that the installation would set the standard for performance and longevity.”

Constructed with corrosion-resistant materials, Bilco UK’s E-50TB Roof Access Hatches were also installed to provide engineers with safe, regular and convenient access to the roof to conduct essential maintenance. Engineered with compression spring operators to provide easy one-hand operation, the roof access hatch meets the requirements of Manual Handling Regulations, whilst the automatic hold-open arm locks the cover in the open position to ensure safe egress.

The overlapping cover design, fully welded corners and insulated cover also ensure weathertightness and energy efficiency to deliver the highest standards of resilience. Mark Baird, Sales Operations Manager at Bilco UK, said: “Drawing on our longstanding relationship with Procladd Small Works Ltd, it was fantastic to work together on this project, which has been designed to positively impact the city’s culture. The products installed were manufactured with fire safety and efficiency in mind, delivering assurance of the durability and suitability of the installation for years to come.” www.bilcouk.co.uk

Teamwork Makes The Dream Work

A construction project is only as successful as the products and systems that are used. When a completely new flooring system was required for a refurbishment project at Leighton Hospital, Tremco was in pole position to fulfil the needs of the Client, Axiom Group (NW) Limited, with their fully compatible solutions offering.

Positioned within Mid Cheshire Hospitals NHS Foundation Trust, the now 50-year-old Leighton Hospital is currently undergoing a major redevelopment scheme to maintain their commitment to the safety of staff, patients, and visitors. Aside from a much wider overhaul of the site’s current infrastructure, Tremco was called upon to install a number of their market-leading flooring products for the periodic refurbishment of one of the hospital’s buildings.

Due to this particular building’s change of use, a whole new flooring system was required. Through an already well-established relationship with Axiom Group, Tremco also worked in conjunction with Robertson Construction and Kenwood Flooring, who through collaboration, accomplished a safe, reliable, and highquality installation that was suited to the building’s new purpose.

Once the floor was initially ground by Kenwood Flooring, then came the installation of the liquid dampproof membrane (DPM). By applying a surface DPM that bonds to the surface of the concrete, this strives to minimise any moisture vapour transmission. This prevents moisture build-up beneath floor coverings, which in turn mitigates the risk of a floor failure.

Tremco’s ES100 is the UK’s market-leading epoxy DPM, and a single coat of this solution accommodates up to 97% relative humidity (RH). Having been developed for use on both concrete and sand/cement subfloors, ES100 is a cost-effective choice as it guarantees a single coat liquid application, thus significantly reducing time spent on site.

The next stage of the project saw the application of Tremco’s CS190 Gritty Primer, which is a ready mixed, rapid drying solution that can be used on both dry absorbent and non-absorbent substrates. CS190 provides a textured finish that significantly improves adhesion and bond strength, which creates an ideal surface for the application of a smoothing compound.

The smoothing compound of choice was SX302, which is a moisture-tolerant latex underlayment that may accept foot traffic after just 90 minutes, post application. This product is both easy-to-mix and apply, promising extremely low odour, therefore, leaving no unpleasant scent of ammonia behind.

Lastly, Tremco’s SF105 High Performance Acrylic Adhesive was applied over the smoothing compound to achieve a strong, permanent bond to the subsequent floor covering. This non-flammable adhesive has been specially developed for linoleum and vinyl floor coverings, having been approved by major manufacturers for use with all vinyl (PVC) floor coverings. www.tremco-europe.com/en_GB/home

RIVERSIDE APARTMENTS FEATURE A-RATED MAGPLY BOARDS FOR KITCHEN FIT OUT

An acclaimed new residential development in a Thameside location is currently being fitted out, with four of the apartment buildings featuring the use of 18 mm Magply boards, manufactured by IPP Ltd., being used in all the kitchens due to their unique range of physical benefits. With the design of the structure prioritising the use of noncombustible materials in response to recent changes to the Building Regulations, the A1 rated Magply boards were chosen to form pattresses within the external walls on the basis of the material’s unique combination of strength and fire resistance as well as the product’s past performance in similar applications.

Riverscape is a joint development involving international redevelopment specialists, Ballymore and Oxley, with Reddy Architecture + Urbanism leading the design team. The first four blocks, which rise to eight, 10 and 14 storeys, will create a total of 249 dwellings of different sizes and specifications, for social housing tenants and shared equity ownership. Meanwhile S & R London Ltd – responsible for all of the internal partitioning – is using the 18 mm Magply boards to form pattress boards across the outer walls. www.magply.co.uk

FIREFLY’S TITAN LITE SELECTED TO PROTECT LEWISHAM ROOF SPACES

Fully compatible products from the range of TBA FIREFLY™ have been chosen to compartmentalise roof voids between apartments and communal lobbies of a large apartment building in the London Borough of Lewisham, providing 120 minutes fire integrity protection as part of a wide ranging refurbishment programme carried out earlier this year.

The contract on Lewisham Homes’ Commodore Court in Albyn Road has been led by the sector specialist construction company, Mulalley & Co. with London/Sevenoaks based CLM Fireproofing carrying out the installation of the TITAN Lite™ 120:60 barrier system, in combination with Collaroll and the use of ancillary products from the FIREFLY™ range. TITAN Lite™ 120:60 has been developed for use in vertical separation or compartmentation situations, offering 120 minutes integrity and 60 minutes insulation and is able to be sealed around penetrations. It is widely specified to form fire barriers within roof voids and floor voids in many different property types.

The flexible woven material is easy to cut and fix, and is chemically treated to improve its cooling properties and therefore prevent temperatures rising in adjoining areas. The system has been fully tested to BS 476 Parts 20 & 22 and is third party certified by IFC. www.tbafirefly.com

York Handmade Project Wins Prestigious Stirling Prize

One of the York Handmade Brick Company’s most acclaimed projects has won the prestigious 2022 RIBA Stirling Prize. York Handmade, based at Alne, near Easingwold, in North Yorkshire, provided more than 300,000 bricks for the magnificent new Magdalene College Library at Cambridge University. The library beat five other projects to triumph in this year’s Stirling Prize, the highest accolade in architecture.

It is awarded for the UK’s best new building of the past 12 months. The contract was worth £300,000 for York Handmade, one of the leading independent brickmakers in the UK. The prize-winning architects for the new library at Magdalene College were London-based Niall McLaughlin.

David Armitage, chairman of York Handmade, commented: “It is a tremendous honour to have played a pivotal role in creating a building which has won the Stirling Prize. There is no more significant or coveted prize in the architectural world. We were so proud when we were asked to provide our bricks for such a prestigious project. Magdalene has a rich cultural heritage and this stunning new building reflects this."

“The finished building is absolutely magnificent and provides a wonderful place for Magdalene students to work. It is one of our flagship projects over the past few years and we are proud of what we have achieved.”

The Stirling Prize judges praised the new library, called it "exquisitely detailed and solid and confident, yet deferential new kid on the college block". Simon Allford, president of the Royal Institute of British Architects (RIBA), commented that: “It had been a significant challenge to create a building that would last at least 400 years, but that the architects had managed it with 'the utmost skill, care and responsibility'. Well-designed environments hugely improve student success and wellbeing. They should be the rule for all students and teachers in all places of learning, not the exception".

York Handmade was selected primarily for the colour and the character of its brick, but also because of the company’s ability to manufacture a wide range of intricate specials and sizes to fit in with the design specified by the architect.

Mr Armitage explained: “We supplied no less than 40 different sized or special-shaped bricks for this scheme and the quality of the brickwork is outstanding. We must pay tribute to the contractor and especially Julian Redpath, who is the site manager for Cocksedge Building Contractors Ltd."

Tim Allen-Booth, associate with architects Niall McLaughlin, commented: “Our design for the new library was for a bold, modern building, while also having a settled quality that fits with the mediaeval character of the original college buildings. The character of the new brickwork is central to this aim.

“We chose York Handmade’s bricks for their texture, range of colours and ability to produce the range of special shapes and sizes required. The colour mix was developed in close collaboration with York Handmade’s team. The end result echoes the tapestry-like quality of the college’s mediaeval walls and is a key part of both the interior and exterior of the new building.”

Mr Armitage added: “This commission continues our strong relationship with colleges and university buildings at Oxford and Cambridge. We have provided bricks for Christchurch College in Oxford, as well as Oxford’s Said Business School, and Jesus College, Cambridge. It is an immense privilege to be associated with such important buildings and projects in historic and sensitive environments. It is also testament to the renaissance of brick as the building material of choice for significant and prestigious developments.” www.yorkhandmade.co.uk

Howe Green Supports Successful Specification At Bond Street Station

As one of nine new stations developed as part of the construction of the Elizabeth line, Bond Street Station will facilitate up to 137,000 passengers per day, with up to 22 trains passing through the station every hour at peak times from November 6 this year and up to 24 trains per hour from May 2023.

Providing interchanges for the Central and Jubilee lines, the newly constructed Bond Street station will significantly improve accessibility for travellers, whilst simultaneously increasing capacity at one of the busiest shopping districts in the UK.

The development of the station included the specification of 200 Howe Green stainless steel floor access covers as part of the structural and architectural design process to provide secure and concealed access to under-floor services. Installed throughout the entire station, which includes two newly constructed ticket halls at street

level and all underground passenger platforms that can be as long as 255 metres, the medium-duty 7500 Series Floor Access Covers were manufactured to meet the project’s extensive requirements.

With over 50 kilometres of communications cabling, 200 CCTV cameras, 66 information displays, 200 radio antennas, 750 loudspeakers and 50 help points, an essential element of the specification process was ensuring the covers were tamper proof, without preventing contractors from gaining quick and easy access to the services below.

Manufactured with unobtrusive barrel cover lifting points that can only be accessed with unique lifting and securing keys, the access covers are protected from unauthorised access, without impacting the overall design scheme, as only the securing bolt and barrel edge are visible.

The method of removing the covers also ensures the products can be handled easily and safely by contractors, eliminating any potential strain or harm, regardless of the covers’ combined weight with the hard flooring finishes. This is due to the lifting blocks being anchored to the inner frame. Throughout maintenance-only areas, the lifting mechanisms of the floor access covers are mechanically assisted with pistons so engineers can securely lift the covers from underneath.

Installed in conjunction with terrazzo flooring across the platforms, and Portuguese granite throughout the ground floor public areas, the 7500 Series Floor Access Covers seamlessly blend with the architectural finishes of the station for a streamlined visual effect. This sleek aesthetic is further enhanced by the tiling modules, which create a unified and cohesive finish, simultaneously eradicating any potential trip hazards, as the access covers are

installed entirely flush with the hard flooring. The minimal profile of the edges also reflects the dimension of the joins between the tiles to create a perfect finish, even when working with the radial sections of stone tiling on curved passages and walkways, which required individual access covers constructed of curvilinear profiles to deliver a high quality, bespoke finish.

Each of the covers withstand up to five tonne pneumatic tyre wheel loads. Manufactured to BS 476: Part 22: 1987, the covers’ ability to eliminate the potential transmission of smoke and fire from the underground services in the event of a fire was another key consideration of the specification process. www.howegreen.com

Photo credits above and below - Darren Almond Artwork for TfL

Schöck Isokorb For Iconic Nestlé Factory Site Regeneration

No other UK product for concrete-to-steel applications satisfies the necessary loadbearing requirements, or meets the current and future thermal performance required by building standards (Part L), than the Schöck Isokorb structural thermal break T type SK.

It is a complete system structural thermal break and is used widely on Block B, a collection of nine buildings which make up around a third of the 1400 hundred or so new properties at the Hayes Village development. This is an extensive regeneration programme in Hayes, West London and is built on the original site of the locally iconic Nestlé Factory, which dominated the area for some 80 years before production relocated to Derbyshire.

Hayes Village is situated along the Grand Union Canal, surrounded by nine acres of green space and includes play areas and allotments. Original features from the Nestlé factory, including one of the listed art deco style buildings, are carefully woven into the fabric of the new development and although all the buildings have distinct characteristics, the existing factory buildings have inspired the overall design.

As a result, the nine buildings that make up Block B are broken up into a series of elements and layers, each of a different brick tone and although very different in character, have façades with common themes. As a counterpoint to the solid masonry walls which wrap the primary steel frame, the metalwork of the balconies is used as a feature to enrich the façades.

Minimising thermal bridging is critical - The entire project is built with sustainability in mind and minimising any risk of thermal bridging at the balcony detailing is critical for a number of reasons. Local heat loss will result in more energy being required to maintain the internal temperature of the building, while low internal surface temperatures in the area of any thermal bridge can cause condensation.

This in turn is likely to result in structural integrity problems. Mould growth too is a possible risk, which in a residential situation can cause asthma and allergies. Incorporating the Schöck Isokorb T type SK minimises any chance of these outcomes, as it prevents the risk of thermal bridging between cantilevered steel constructions on reinforced concrete components.

A dependable and fully compliant product rangeThe Schöck Isokorb range of structural thermal break solutions is the largest in Europe and in the UK helps projects meet full compliance with the necessary Building Regulations (and the impending Future Homes Standard criteria where relevant). In addition to the Isokorb type used on this project, there are also solutions for concrete-to-concrete, steel-to-steel, renovation projects – and even a maintenance free alternative to wrapped parapets.

All products have the security of independent BBA Certification, which provides NHBC approval. The temperature factor requirement (fRSI) used to indicate condensation risk at localised junctions, which must be equal to, or greater than 0.75 for residential buildings, is also easily met by incorporating the Isokorb.

www.schoeck.com

NITTAN FIRE DETECTION SYSTEM INSTALLED IN IRELAND’S TALLEST COMMERCIAL BUILDING

Nittan Elite Partner, Fire Technology Ireland (FTI), has recently commissioned and supplied an L1 addressable fire detection system using Nittan Evolution fire detection devices at the EXO, the tallest commercial building in Ireland, located in Dublin. More than 1,350 Nittan Evolution Analogue Addressable devices were installed as the primary detection system throughout the building, along with Advanced Electronics MxPro 5 Series fire alarm panels and network.

The use of Nittan EV-PYS combined smoke detector sounders reduced the overall visual impact on the floors and common areas. The use of Nittan Multiple Input Output units significantly reduced installation time and the need to “hide” equipment. To provide a fault tolerant network, Evolution new ZMU2 complete with SCI were used for leak detection system in basements and top floor plant room with its own network. Where it was necessary to mount wall units for signalling, EVAV2 combined sounder strobes were used. The high visibility 360-degree strobe is extremely bright and visible from all angles. www.nittan.co.uk

ECO-CONSCIOUS HOUSEBUILDER ADOPTS THERMOBLOCK FOR ITS HIGH SPEC DEVELOPMENTS

A housebuilder undertaking high specification developments in the Stockport and Tameside areas of Greater Manchester has incorporated Marmox Thermoblocks into its designs, to target improved energy performance and all-round higher build quality for its customers. Romiley based D. Woodman Developments’ latest project is creating a total of nine dwellings at School Brow in Stockport where the former Cow & Calf pub is being converted to form three new homes, while a further four semi-detached dwellings and two detached homes are being built on the land adjoining what is a ‘Non-designated Heritage Asset.’

The new houses are being raised on conventional strip foundations using Eco Prime concrete and blockwork footings which then carry beam and block floors, along with the 100mm x 600mm x 65mm Thermoblocks, 100mm thick Celcon Solar aerated blocks then form the inner leaf to the insulated cavity exterior walls. Thermoblocks are available in widths of 100, 140 and 215mm and feature a unique design where two rows of high strength epoxy concrete mini-columns are encapsulated in sections of XPS (Extruded Polystyrene). They are attached at either end to the top and bottom layers of glass-fibre reinforced polymer concrete to achieve a good bond with the rest of the structure. www.marmox.co.uk

Yeoman Rainguard Crowning Glory On High End Development

Property developers Golden Eye Group, augmented their latest residential development with a high-end exterior finish incorporating a rainwater system from Yeoman Rainguard. With a mantra of “a quality finish that will stand the test of time” Golden Eye ensured that quality was reflected not only internally but for all parts of the external building envelope too.

As part of the function and design criteria of the house façade, Yeoman Rainguard were able to provide a sophisticated, quality rainwater system to fulfil technical and aesthetic requirements. To dovetail into the contemporary look, Yeoman Rainguard SL Aluminium gutters and downpipes were chosen. The 75 x 75 mm flush-fit SL Aluminium downpipes provided a modern clean line coupled with 125 x 100 mm MOG gutter. Aluminium Fascia and Soffits from Yeoman Rainguard’s new Squareline range were fitted to complement the sleek lines.

All were finished in a smooth RAL 7022 Grey colour to perfectly match the shade of the windows and doors. The aluminium products give a hardwearing, maintenance free lifecycle of 30 years or more, making this recyclable material both an ecologically and economically sound choice. The rainwater system was installed by Yeoman Rainguard’s experienced installer, ensuring the perfect finish.

www.rainguard.co.uk

From A Natural Pool To Natural Slate: Cupa 12 Selected For Beautiful Grand Designs Project

As showcased on a recent episode of Channel 4’s Grand Designs, CUPA PIZARRAS’ CUPA 12 natural slate has been specified for a spectacular new build project in Chichester. Selected to enhance the property’s modern aesthetic, the slate roof also complements the rural surroundings, which include a wildlife pond along with a variety of plant life. Property owners Daniel and Nina Rowland both work professionally within the construction sector; Daniel heads up architectural firm Studio Fuse, while Nina is an interior designer. Combining their skills, they decided the time was right to embark on a new adventure; leaving London to design and build their own home on the South Coast of England. They purchased a period property that happened to back onto a stagnant pond, which consisted of local drainage overflow.

Daniel and Nina put together a design that would see the old house demolished and a new building constructed. Likewise, the pond was to be transformed into a crystal-clear natural swimming pond – a highly ambitious undertaking. Ideally, this would attract local wildlife, such as frogs, newts and sparrows, resulting in a beautiful waterside home. In terms of the design of the new-build property, the couple wanted the house to be eco-friendly and have a contemporary, spacious and natural aesthetic. It was to be built from structural insulated panels (SIPs) clad in Siberian larch and flint, with large glass windows.

Timber decking would then connect the house to the natural swimming pond. When it came to the roofing, Daniel commented: “We considered using a standard seam metal roof but we went with slate to compliment the natural material palette we have used throughout the rest of the house.” Darren Stigant, Director at NJS Roofing, the roofing contractor on the project made the product recommendation: “Although this project looks quite simplistic, the different roof pitches added a certain amount of difficulty to aligning the mitred hips. Having sourced products from CUPA PIZARRAS many times in the past, I suggested the company’s CUPA 12 slate which was available in 400 x 250mm palettes. Utilising this smaller size, as opposed to the usual 500mm x 250mm, helped us to achieve the finish we required on the mitred hips."

CUPA 12 is a non-carbonated slate that is formed by tectonic compression, giving the product a smooth, matt surface. The dark grey colour provided an effective contrast with the timber and glass. The CUPA 12 natural slate is also high performing with outstanding weather resistance, as it has been tested to achieve a water absorption rate of 0.11% and a rating of T1 in thermal cycle tests.

Thus, making it a long-lasting product with a functional life expectancy of 100 years. What’s more, not only is CUPA PIZARRAS officially a carbon neutral company, but CUPA 12 has also been assessed and certified by BRE Global, solidifying itself as a sustainable choice and bolstering the environmental credentials of Daniel and Nina’s new home. Kevin McCloud, presenter of Grand Designs commented: “This design joins together nature and architecture –in every sense it’s beautiful.”

www.cupapizarras.com/uk

Sto Render System Specified For New Passivhaus Development

Sto’s StoRend Flex render system was specified for use on a high-profile development of luxurious and sustainable homes built in Norfolk. Located five miles from Norwich city centre, the six new Octagon Park homes are designed to meet the requirements of the Passivhaus Plus standard, while delivering outstanding quality and a high level of sustainability.

“In order to minimise energy consumption, the Passivhaus Plus standard sets out very specific criteria for construction, insulation and ventilation systems,” explains Sto’s head of sales, Ashley Wainwright. “This meant that the materials specified had to satisfy extremely demanding performance standards, and the StoRend Flex render system was certainly able to achieve this.”

The Octagon Park development was created by JR Cozens Wiley Ltd, and the properties feature a timber-frame construction, which had a direct bearing on the specification of the StoRend Flex system. “An alternative render system was originally considered for the project,” adds Ashley.

“However, this would have required the inclusion of many vertical and horizontal movement joints at every door and window aperture. Fortunately, these weren’t necessary with the Sto system, so it was ideal for this purpose as it helped simplify both the design and construction processes while still

“The boards can be installed quickly and easily and can be cut without the need for power tools,” comments Sebastian Slomkowski of Passivhausapproved S.I.R.S. Ltd of Norwich who installed the Sto materials.

“They can also weigh up to 50% less than other render boards which makes them easy to handle and install.” The addition of StoArmat Classic Plus, a cement-free, acrylic resin-based reinforcing coat –which is up to 15 times more flexible than traditional cement-based reinforcing coats when embedded with Sto Glass Fibre strengthening mesh - provided exceptional levels of crack resistance.

delivering the performance and high level of finish required.”

The StoRend Flex synthetic render system provides a highly flexible, rugged and crack-resistant exterior render finish which was in-keeping with the highquality nature of the Octagon Park development. The render itself was applied to Sto’s own StoVentec render carrier boards, which were fixed to the timber frames of the buildings.

Being made from recycled glass granulate, the StoVentec render carrier boards are dimensionally stable, so thermal movement is minimized and the need for movement joints can be reduced, and often eliminated completely.

Widely regarded as an industry benchmark solution, StoVentec board has been specifically developed for use with Sto render products.

The system was then finished with a stippled StoSilco render and StoColor Dryonic façade paint that promotes fast and efficient drainage of water, allowing the surface to dry rapidly and greatly inhibiting the appearance of algae, fungus and unsightly marks. www.sto.co.uk

Warning Labels

Warning notices to reduce the risk of future pipe damage if the floor finish is replaced.

Even Easier Installation

Unique pre-printed chipboard layer shows where the pipe channels are, eliminating the risk of floor covering fixings damaging the pipe. Locator guides show where screws should be placed.

New Chipboard Covering Layer

Covering chipboard layer is pre-cut with the pipe channel pattern, allowing the layer to slot precisely over the warm water pipes once installed in the chipboard layer.

Ultra Fast Warm Up Times

The pipe sits proud in the chipboard floor layer, ensuring the pipe is in as close contact with the floor finish as possible when the finishing chipboard layer is slotted in place over the pipe.
