Moorabbin Activity Centre Western Precinct

Urban Design Framework

Prepared for: City of Kingston Council

Project / Report

Moorabbin Activity Centre Western Precinct Urban Design Framework

Job No.

180357

Client

City of Kingston Council

Document Location

S:\180357.00\Docs\C_Client\_reports

Version / Date Issued

Issue A: External Draft (for Client review) - 28/06/2019 Issue B: External Final Draft (for Client review) - 12/07/2019 Issue C: Draft - 19/11/2019 Issue D: Final - 23/03/2020 Issue E: Final Review - 06/08/2020

Report Contact

Dean Thornton (Principal, Architectus)

This report is considered a draft unless signed by a Director or Principal General Disclaimer –– The information contained here is believed to be correct at the time of preparation, however it is not guaranteed. Recipients must rely on their own enquiries to satisfy themselves in all respects. Architectus accepts no damages, liabilities or costs, including legal costs of defence, arising from changes made by anyone other than Architectus or from the information contained here without prior consent of Architectus.

–– Architectus Pty Ltd does not accept any liability to any third party for the contents of this report.

–– This report is not intended for use by any other person or for any other purpose. Only the original drawings should be relied on.

–– Further development of the design, measurement and construction tolerances and/ or further client/ tenant requests will inevitably result in changes to these areas [which could involve significant reductions] and Architectus Pty Ltd accepts no legal responsibility for any decision, commercial or otherwise, made on the basis of these areas.

–– The Copyright in this report belongs to Architectus Group Pty Ltd.

2

| One Mile Grid | DARMS Property

Adelaide Lower Ground Floor 57 Wyatt Street Adelaide, SA 5000 t. (+61) 08 8427 7300 e. adelaide@architectus.com.au Perth Lower Ground Floor 57 Wyatt Street Perth, WA 000 t. (+61) 08 8427 7300 e. perth@architectus.com.au Melbourne Level 25, 385 Bourke Street Melbourne VIC 3000 t. (+61) 03 9429 5733 f. (+61) 03 9429 8480 e. melbourne@architectus.com.au Sydney Level 18, MLC Centre 19 Martin Place Sydney NSW 2000 t. (+61) 02 8252 8400 f. (+61) 02 8252 8600 e. sydney@architectus.com.au architectus.com.au

Contents

01 02 03

Introduction + Background

5

Project Vision and Principles

15

Framework Approach and Design Guidelines

19

Moorabbin Activity Centre Western Precinct | UDF Background Report

3

Pedestrian priority public realm - Kyiv, Ukraine

01 Introduction + Background This chapter provides an overview of the project’s background and process.

A more comprehensive overview of this Chapter's material can be found in the Background Report (June 2019).

Introduction + Background

1.1 Introduction

1.2 Project Aims and Objectives

1.3 Project Process

1.4 Structure of this Report

Architectus together with One Mile Grid (transport planners) and DARMS Property (economic advisors) have been engaged by Kingston City Council to develop an Urban Design Framework for the Moorabbin Activity Centre’s Western Precinct (hereby referred to as the Precinct).

The purpose of this piece of work is to provide:

This report has been prepared by Architectus, the lead consultant for this Project, with inputs from our sub-consultant team. The report has been informed by extensive investigation, reviews and analysis, and a comprehensive process of Council, stakeholder and community engagement.

This Urban Design Framework Report is structured across four (4) chapters, as outlined below.

Consultant Team

Vision and Principles

In 2011, Council adopted the Moorabbin Structure Plan, setting a vision to ‘actively engage to bring Moorabbin to life by complementing its strong cultural role with a living population that calls it home’. The structure plan recognised the potential to consolidate land within its western precinct to facilitate significant redevelopment opportunities, potentially inclusive of hotel / convention facilities, landmark buildings and strong forms to strengthen the entrance to the activity centre.

Then in 2015, Schedule 3 of the Activity Centre Zone was introduced into the Planning Scheme implementing the objectives of the Structure Plan. Objectives within the Precinct refer to encouraging land consolidation, landmark commercial buildings along Nepean Highway, sympathetic responses to heritage and residential areas as well as enhancing connections to the retail core and Moorabin Railway Station.

Moorabbin is home to a diverse multicultural community and this urban design framework has the potential to provide a place for new development and opportunities to come together.
