Fitting instruction - KUBE 1001 by FROST

Fitting instruction - KUBE 1001

KUBE 1001 (A1001S)

PRODUCT

DETAILS, TECHNICAL DETAILS AND FITTING INSTRUCTIONS www.frostdenmark com 59 mm 4 mm 50 mm 26 mm 16 mm 120 mm 38 mm 30 mm 30 mm 16 mm 22 mm

8 x 8 mm 59 mm 4 mm 50 mm 26 mm 38 mm 30 mm 30 mm 22 mm

8 x 8

Spindle:

KUBE 1001

lever handle, 2 pcs. a set

Stainless Steel AISI 304

Suitable for indoor and outdoor use

Length: 120 mm

Projection: 59 mm

Rose: 50 x 50 x 4 mm

Door Thickness: 40-69 mm

Spindle: 8 x 8 x 90 mm

Longer spindles available on request

Design: Busk+Hertzog

CLEANING AND MAINTENANCE

Stainless steel surfaces should be cleaned with a microfibre cloth, glass cleaner or other non abrasive and gentle agents.

ATTENTION:

Never use solvents or aggressive household cleaners like bleach, acids (e.g. descalers) or ammonia-based bathroom cleaner to clean the product. Steel wool and hard brushes can permanently damage the surface of the steel.

Brushed Stainless A1001BS Brushed Copper A1001BOCS Brushed Gold A1001BMGS Brushed Black A1001BCBS Polished Stainless A1001PS Polished Copper A1001CS Polished Gold A1001GS Matt Black A1001BLS

FITTING INSTRUCTIONS

Spindle: 90 mm Ø5x20 Plastic tube plug

Door thickness: 40-69 mm

When the set screw is tightened, a guide hole is punched in to the spindle.

Torx no. 15 Allen key 2 mm Rose key

Machine screw: M4x62 brake off Machine screw: M4x35

E2 2x

Torx no. 15 1 D D A B1 E1 F H E2 2x 1x 2x 2x 1x 2x C 1 D D B1 E1 F H E2 1x 2x 2x 1x 2x C 1 D A B1 E1 2x 1x 2x C 1 D A 1x 2x 2x 2x 1x 1x C 2x 4x 1x

M4x62 M4x35

Torx no. 15

WHAT IS IN THE BOX E F

Wood screw: ST4,5x16

DK - 8370 HADSTEN

T +45 8761 0032

info@frost.dk www.frostdenmark.com

facebook.com / FROSTdenmark

twitter.com / FROSTdenmark

instagram.com / FROSTdenmark

pinterest.com / FROSTdenmark

No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopy, recording or any other information storage and retrieval system, without prior permission from FROST A/S. We reserve the right to make alterations to the models without prior notice.
