PROTECT YOUR KNEES™
POD ACTIVE | KNEE BRACES SPARE PARTS & ACCESSORIES PODKNEE.COM Version 2 | September 2014
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
TYPICAL product COMPONENTS – KX KNEE BRACE
10
13
1 6
4
2
9
15
5
14
7 8 1
12
11
Part #: 1 2 3 4 5 6 7
Description Frame Upper Cuff Lower Cuff Human Motion® Hinge Hinge Pad Upper Frame Liner Lower Frame Liner
Part #: 8 9 10 11 12 13 14 15
3
Description Lower Strap (#1) Upper Strap (#2) Top Strap (#3) Bottom Strap (#4) Strap Loop Strap Pad Patella Guard Synthetic Ligament®
2
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
TYPICAL HINGE COMPONENTS – HUMAN MOTION® HINGE
4 2
3
2 1
5 6
Part #: Description 1 Hinge Insert Set
Part #: Description 4 Allen Key
2
Ligament Screw
5
Synthetic Ligament®
3
Ligament Nut
6
Hinge Housing Set
3
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
SPARE PARTS
padding
strapping
guards
hinge
Description
frames
Side
K1 YOUTH
K300 SPORT
K700 PRO
KP100-000-OS
One size fits all
Bilateral
æ
æ
æ
Hinge Ligament Set
KP120-000-NS
One size fits all
Bilateral
æ
æ
æ
Hinge Refurb Set
KP140-000-OS
One size fits all
Bilateral
æ
æ
æ
KX Patella Guard
KP200-001-SM/MD Small / Medium
Bilateral
æ
æ
æ
KP200-001-LG/XL
Large / Extra-Large Bilateral
æ
æ
æ
KP200-001-2X
Extra-Extra-Large
Bilateral
æ
æ
æ
K1 Patella Guard (Youth) KP230-001-OS
One size fits all
Bilateral
æ
K1 Strap Set
KP330-014-OS
One size fits all
Bilateral
æ
KX Strap Set (NEW)
KP320-014-SM/MD Small / Medium
Bilateral
æ
æ
KP320-014-LG/XL
Large / Extra-Large Bilateral
æ
æ
KX Strap Loop Set
KP340-001-NS
No size
Bilateral
æ
æ
K1 YTH Strap Loop Set
KP350-006-OS
No size
Bilateral
æ
K1 Pad Set (Left)
KP410-009-YM
Youth Medium
Left
æ
KP410-009-YL
Youth Large
Left
æ
KP411-009-YM
Youth Medium
Right
æ
KP411-009-YL
Youth Large
Right
æ
K300 Pad Set (Left)
KP430-003-OS
One size fits all
Left
æ
K300 Pad Set (Right)
KP431-003-OS
One size fits all
Right
æ
K700 Pad Set (Left)
KP470-003-OS
One size fits all
Left
K700 Pad Set (Right)
KP471-003-OS
One size fits all
Right
KX Velcro Set
KP400-001-OS
One size fits all
Bilateral
æ
K1 Frame Set (Left)
KP510-230-OS
One size fits all
Left
æ
K1 Frame Set (Right)
KP511-230-OS
One size fits all
Right
æ
K300 Frame Set (Left)
æ æ æ
KP530-008-SM
Small
Left
æ
KP530-008-MD
Medium
Left
æ
KP530-008-LG
Large
Left
æ
KP530-008-XL
Extra-Large
Left
æ
KP531-008-SM
Small
Right
æ
KP531-008-MD
Medium
Right
æ
KP531-008-LG
Large
Right
æ
KP531-008-XL
Extra-Large
Right
æ
KP600-016-YM
Youth Medium
Left
æ
KP600-230-YL
Youth Large
Left
æ
KP601-016-YM
Youth Medium
Right
æ
KP601-230-YL
Youth Large
Right
æ
K1 Conversion Set (YM)
KP602-000-YM
Youth Medium
Pair
æ
K1 Conversion Set (YL)
KP602-000-YL
Youth Large
Pair
æ
K300 Frame Set (Right)
cuffs
Size
Hinge Insert Set
K1 Pad Set (Right)
K1 Cuff Set (Left) K1 Cuff Set (Right)
conversion sets
SKU
æ
4
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – HINGE ASSEMBLY
SKU
Description
Size
Side
KP100-000-OS
KX Hinge Insert Set
One size fits all
Bilateral
SKU
Description
Size
Side
KP120-001-NS
KX Hinge Ligament Set
No size
Bilateral
5
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – HINGE ASSEMBLY
SKU
Description
Size
Side
KP140-000-OS
KX Hinge Refurb Set
No size
Bilateral
SKU
Description
Size
Side
KP200-001-SM/MD
Patella Guard (Small; Black)
Small / Medium
Bilateral
KP200-001-LG/XL
Patella Guard (Large; Black)
Large / Extra-Large
Bilateral
KP200-001-2X
Patella Guard (Extra-Extra-Large; Black)
Extra-Extra-Large
Bilateral
KP230-001-OS
Patella Guard (Youth; Black)
Youth
Bilateral
PARTS – PATELLA GUARD
6
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 STRAP SETS
SKU
Description
Size
Side
KP330-014-OS
K1 Strap Set (Black/Grey)
One size fits all
Bilateral
SKU
Description
Size
Side
KP350-006-OS
K1 Strap Loop Set (Grey)
One size fits all
Bilateral
7
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – KX STRAP SETS
SKU
Description
Size
Side
KP320-014-SM/MD
KX Strap Set (SM / MD; Black/Grey)
Small – Medium
Bilateral
KP320-014-LG/XL
KX Strap Set (LG / XL; Black/Grey)
Large – Extra-Large
Bilateral
SKU
Description
Size
Side
KP340-001-NS
KX Strap Loop Set (Black)
No size
Bilateral
8
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 YOUTH PAD SETS
SKU
Description
Size
Side
KP410-009-YM
K1 Youth MX Pad Set (LT; YM)
Youth Medium
Left
SKU
Description
Size
Side
KP410-009-YL
K1 Youth MX Pad Set (LT; YL)
Youth Large
Left
9
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 YOUTH PAD SETS
SKU
Description
Size
Side
KP411-009-YM
K1 Youth MX Pad Set (RT; YM)
Youth Medium
Right
SKU
Description
Size
Side
KP411-009-YL
K1 Youth MX Pad Set (RT; YL)
Youth Large
Right
10
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K300 PAD SETS
SKU
Description
Size
Side
KP430-003-OS
K300 MX Pad Set (LT; Red)
One size fits all
Left
SKU
Description
Size
Side
KP431-003-OS
K300 MX Pad Set (RT; Red)
One size fits all
Right
11
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K700 PAD SETS
SKU
Description
Size
Side
KP470-003-OS
K700 MX Pad Set (LT; Red)
One size fits all
Left
SKU
Description
Size
Side
KP471-003-OS
K700 MX Pad Set (RT; Red)
One size fits all
Right
12
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – VELCRO SET
SKU
Description
Size
KP400-001-OS
KX Velcro Set (Black)
One size fits all
13
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – FRAMES (K1 YOUTH)
1
2
SKU
Description
Size
Side
KP510-230-OS
K1 Youth Frame Set (LT; Grey/Orange)
One size fits all
Left
KP511-230-OS
K1 Youth Frame Set (RT; Grey/Orange)
One size fits all
Right
14
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – FRAMES (K300)
2
1
SKU
Description
Size
Side
KP530-000-SM
K300 Frame Set (LT; SM)
Small
Left
KP530-000-MD
K300 Frame Set (LT; MD)
Medium
Left
KP530-000-LG
K300 Frame Set (LT; LG)
Large
Left
KP530-000-XL
K300 Frame Set (LT; XL)
Extra-Large
Left
KP531-000-SM
K300 Frame Set (RT; SM)
Small
Right
KP531-000-MD
K300 Frame Set (RT; MD)
Medium
Right
KP531-000-LG
K300 Frame Set (RT; LG)
Large
Right
KP531-000-XL
K300 Frame Set (RT; XL)
Extra-Large
Right
15
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 CUFF SETS
SKU
Description
Size
Side
KP600-016-YM
K1 Cuff Set (LT; Youth Medium; Grey)
Youth Medium
Left
SKU
Description
Size
Side
KP601-016-YM
K1 Cuff Set (RT; Youth Medium; Grey)
Youth Medium
Right
16
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 CUFF SETS
SKU
Description
Size
Side
KP600-230-YL
K1 Cuff Set (LT; Youth Large; Black)
Youth Large
Left
SKU
Description
Size
Side
KP601-230-YL
K1 Cuff Set (RT; Youth Large; Black)
Youth Large
Right
17
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
PARTS – K1 YOUTH CONVERSION SETS
SKU
Description
Size
Side
KP602-000-YM
K1 Conversion Set (YM; LT)
Youth Medium
Pair
SKU
Description
Size
Side
KP602-000-YM
K1 Conversion Set (YM; RT)
Youth Medium
Pair
18
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
ACCESSORIES accessories
Description
K1 YOUTH
K300 SPORT
K700 PRO
æ
æ
Pair
æ
æ
Large / Extra-Large Pair
æ
æ
SKU
Size
Side
Brace Bag
KA-100-001-NS
No size
Pair
æ
Undersleeves – Youth
KA200-001-NS
No size
Pair
æ
Undersleeves – SM / MD KA220-001-SM/MD Small / Medium Undersleeves – LG / XL
KA220-001-LG/XL
19
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
ACCESSORIES – BRACE BAG
SKU KA100-001-NS
Description KX Brace Bag (Black) (Open, Lying Down with Two Braces)
Size
Side
No size
NA
20
POD ACTIVE | SPARE PARTS & ACCESSORIES | 2014
ACCESSORIES – KNEESLEEVES
SKU
Description
Size
Side
KA200-001-OS
KX Kneesleeves (Youth; Black)
One size fits all
Pair
SKU
Description
Size
Side
KA220-001-SM/MD
KX Kneesleeves (SM / MD; Black)
SM / MD
Pair
KA220-001-LG/XL
KX Kneesleeves (LG / XL; Black)
LG / XL
Pair
21
PROTECT YOUR KNEES™
Customer Service: W www.podactive.com E support@podactive.com
facebook.com/podactive
POD Active Pty. Ltd. AUSTRALIA T
+61 3 5244 4111
POD Active Europe Ltd UNITED KINGDOM T
+44 191 4813587
© Copyright 2014 POD Active | NOTE: The products depicted in this brochure may vary to some degree in product graphics and colour.
