A 1 6
H O C K E Y ,
S O C C E R
&
L A C R O S S E
G O A L S ,
C O U R T
L I N I N G
T A P E
39d
39 Stored
39b 39c
42
40
39 39a
41
General specifications Hockey: International and Women’s International Hockey Rules Board.
A16-105 Lacrosse Goal - Indoor Folding, 1320 x 1270mm High (Qty 1) Similar to A16-106.
39d A16-444 Soccer/Hockey Goal Cross Bar Padding
Soccer: Australian Indoor Soccer Federation Inc.
A16-104 Soccer Goal - Indoor Folding, 5000 x 1250mm High (Qty 1) Similar to A16-106.
40
All Acromat games posts are made of steel and designed to be as light as possible but robust enough to withstand harsh treatment and comply with the international standards.
39 A16-106 Soccer/Hockey Goal Indoor - Folding, 3100 x 2050mm High (Qty 1) Frame 50mm sq. light steel tube with hinged end frames for storage. Removable rods hold the 50mm sq. sports mesh to the frame. Rubber buffers FCI-431 protect the floor. Holding down plates A16-225 and pads ordered separately.
6 2
39a A16-225 Indoor Goal Holding Down Plates Filled to Bottom Rail (Qty 1) Used if the goals must be fixed to the floor. Suits all indoor goals. Holding down knob X6-39 retained by a chain, screws into a threaded floorplate A6-6. 39b A16-216 Soccer/Hockey Goal Net Indoor 3000 x 2000mm - Replacement Nylon sports mesh 50mm sq. with 6mm polyethylene rope in the bottom edge. 39c A16-443 Soccer/Hockey Goal Safety Padding (Qty 1) Two pads for the 50mm sq. vertical front frames. Carpeted covered Acrolite foam 20mm thick is held in place with touch tape.
A16-217 Hockey Barrier, 95mm High (Qty 1) Steel tube with timber front face angled to deflect balls downwards. Locating pins fit into floor plates A6-7 and interlocking pins link the 4000mm long barrier sections together.
41 A16-218 Soccer/Hockey Barriers Removable, 2400 x 1200mm High Plywood panel is supported by tubular steel frame with folding leg. Holding down fittings and floor plates to suit the type of floor are ordered separately. Option: Clear perspex top half of barrier to improve spectator viewing.
42 Court Lining Tape Used for temporary courts or where it is not practical to use painted lines. Self adhesive PVC tape suitable for smooth floors. Rolls length: 33metres. Width 48mm 36mm 24mm Colour Code Red
Code
Code
A16-120 A16-127 A16-135
Green A16-121 A16-128 A16-136 Black A16-122 A16-129 A16-134 Yellow A16-123 A16-130 White A16-124 A16-131 Blue A16-125 A16-132 Court Lines - Painted Where painted lines are required, Acromat can provide layouts, make recommendations or arrange for the work to be done.
