Diamond cutting tools
High-performance cutting blade
High-performance product for use on asphalt. Special segments ensure smooth operation and optimal protection of the master plate. The DS 100 A cuts fast with low vibration and is suitable for gasoline powered machines and joint cutters with a power output of up to 15 kW From diameter 300 mm with driving hole
DS 100 0A
Design Laser welded Edge Segmented
Applications: Asphalt Screed Green concrete
Diameter x Bore in mm
Max. operating speed
Max. RPM
300 x 20
100 m/s
6,400 rpm
300 x 25,4
100 m/s
6,400 rpm
350 x 20
100 m/s
5,500 rpm
350 x 25,4
100 m/s
5,500 rpm
400 x 20
100 m/s
4,800 rpm
400 x 25,4
100 m/s
4,800 rpm
450 x 25,4
80 m/s
3,400 rpm
High-performance cutting blade
Machines
Segment in mm Number / L / W / H
Packing unit/pcs.
Cat. number
Petr. pow. cutter
18 / 41,5 / 2,8 / 13
1
313715
18 / 41,5 / 2,8 / 13
1
313716
21 / 40,3 / 3,0 / 13
1
313717
21 / 40,3 / 3,0 / 13
1
313718
24 / 39,6 / 3,2 / 13
1
313719
24 / 39,6 / 3,2 / 13
1
313720
25 / 39,6 / 3,6 / 13
1
313721
Petr. pow. cutter, Joint cutter up to 15 kW Petr. pow. cutter Petr. pow. cutter, Joint cutter up to 15 kW Petr. pow. cutter Petr. pow. cutter, Joint cutter up to 15 kW Petr. pow. cutter, Joint cutter up to 15 kW
High-performance tile cutting disc with a thickness of only 1.2 mm, turbo rim and reinforced flange area. Precise and fast cutting even on the hardest of materials, in addition to maximum product safety. The DT 100 F with turbo rim features high-precision cutting performance, even without breaks for cooling. It is suitable for use on tiles, feldspar and granite tiles
DT 100 0F
Applications: Stoneware Floor tiles Natural stone Granite Stove tiles
Diameter x Bore in mm
Max. operating speed
Max. RPM
Machines
Segment in mm Number / L / W / H
Packing unit/pcs.
Cat. number
115 x 22,23
80 m/s
13,300 rpm
Angle grinder
CR* / CR* / 1,2 / 7
1
313684
125 x 22,23
80 m/s
12,200 rpm
Angle grinder
CR* / CR* / 1,2 / 7
1
313685
C R* = Continuous Rim Please observe: Please see Applications Guide on page 170 - 171. How to order: Instructions on page 199.
178
Design Sintered Edge Turbo
