2023 - Router bits for wood, chipboard and solid surface materials
ROUTER BITS FOR WORKING SOLID SURFACE MATERIALS
HW STRAIGHT PLUNGE BITS WITH BALL BEARING GUIDE Z=2
HW router bits for working solid surface are manufactured by Sistemi Klein® with high quality raw materials, softer cutting angles and the use of carefully selected Delrin bearings to allow safe and optimal processing of solid surfaces and to decorate Corian®, Avonite®, Hanex® and more. Nowadays, working and routing "Solid Surface" material is more and more common. Solid Surface such as Corian®, Avonite®, Hanex®… are largely used in many different fields, both domestic (bathrooms, kitchens and labs) and health (hospital and clinics). It is a useful, versatile and easy to clean product. All the Klein router bits for working solid surface are developed and made with a special solid carbide for cutting these sturdy materials. The soft form of our cutting angles and the Delrin® ball bearings, allow safe and easy operations.
ART. E302 - G302
HW ROUTER BITS WITH NEGATIVE AXIAL ANGLE Z=2
5° ball bearing with Delrin® ring
ART. E300 - G300
S ∅ 12 E302.190.R
Z050.103.N
S ∅ 1/2”(12,7) G302.190.R
D 19
Z053.002.N
Z051.004.R
S ∅ 12 E302.191.R
Z050.101.N
D 19
Z053.002.N
B 25
L 82,5
α 5°
B 25,4
L 80
α 0°
E 1,6
Z051.004.R
HW FACE-INLAY BITS WITH BALL BEARING GUIDE Z=2 ART. E305 - E306 - E307 CNC
S ∅ 12 E300.095.R E300.127.R E300.128.R E300.129.R
S ∅ 1/2”(12,7) G300.095.R G300.127.R G300.128.R G300.129.R
D 9,5 12,7 12,7 12,7
B 25 32 38 50
L 70 73 79 107,5
HW STRAIGHT PLUNGE BITS Z=1 ART. E301 - G301
S ∅ 12 E305.127.R Selling out
Z050.007.N
Z054.003.N
S ∅ 12 E306.064.R Selling out E306.127.R
Z050.011.N
CNC
S ∅ 12 E301.095.R
S ∅ 1/2”(12,7) G301.095.R
D 9,5
B 25
L 70
Z054.003.N
S ∅ 12 E307.127.R Selling out
Z050.005.N
www.sistemiklein.com
Z054.003.N
D 22
B 12,7
L 82
E 4,8
B 6,4 12,7
L 76 82
E 3,2 3,2
B 12,7
L 82
E 1,6
Z051.004.R
D 22 22
Z051.004.R
D 22
Z051.004.R
3.05
