2023 - Router bits for hand portable machines S= ∅10 - S=∅12 - S ∅ 1/2”(12,7)
HW FLUSH TRIM BITS WITH BALL BEARING GUIDE Z=2 ART. E146 - G146
SOLID CARBIDE COMPRESSION CUTTERS Z=2+2 WITH DOUBLE BALL BEARING ART. T166 B L
Excellent finish on both upper and lower side
S ∅ 12 E146.126.R E146.127.R E146.128.R E146.129.R
S ∅ 1/2”(12,7) G146.126.R G146.127.R G146.128.R G146.129.R
D 12,7 12,7 12,7 12,7
B 13 25 38 51
L 71 84 98 106
- Right-hand rotation with double flute compression spiral (UP & DOWN). - Double ball bearings guide for greater precision of trimming - Special spiral geometry which provides better chip evacuation and smoother cuts on laminate panels.
S ∅ 12 T166.120.R NEW Z050.003.N
Z053.003.N
S ∅ 12 E146.190.R E146.191.R E146.192.R
S ∅ 1/2”(12,7) G146.190.R G146.191.R shear angle G146.192.R shear angle
Z054.002.N
D 12
B 51
L 110
CNC
Z 2+2
Z051.002.R
D 19 19 19
B 25 38 51
L 82 98 108
Z050.031.N
VHW FLUSH TRIM BITS WITH DOUBLE BALL BEARINGS Z=2 B ART. T168
Z050.005.N
Z053.002.N
Z054.002.N
Z051.004.R
L
HW FLUSH TRIM BITS WITH UPPER AND LOWER BALL BEARING Z=2 ART. E146 - G146
- Solid carbide (VHW) - Right-hand rotation with "UP CUT SPIRAL" - Double ball bearings guide for greater precision of trimming - Special spiral geometry which provides better chip evacuation and smoother cuts compared to standard flush trim bits - For natural wood, pressed wood, veneered, laminate and melamine
S ∅ 12 T168.127.R
S ∅ 1/2”(12,7) G146.592.R
D 19
B 51
Z050.005.N (upper ball bearing)
Z050.012.N (lower ball bearing)
Z053.002.N
Z054.002.N
Z051.004.N
Z058.002.N
B 51
L 125
Z 2
Z050.007.N
- Suitable for trimming with template on the upper and/or lower side - Klein® trimming bits with straight cut are suitable for smooth and well-finished edges on melamine and veneered panels.
S ∅ 12 E146.592.R
D 12,7 (1/2”)
HW INSERT FLUSH TRIMMING BITS Z=2 L 108
ART. W114 - WG114
- Lower ball bearing - This item is sold complete with a torx key
SHEAR ANGLE
2.16
S ∅ 12 W114.190.R W114.191.R
D 19 19
B 30 50
L 80 100
Z 2 2
S ∅ 1/2”(12,7) WG114.190.R WG114.191.R
D 19 19
B 30 50
L 80 100
Z 2 2
Z555.008.N (B=30)
Z052.201.N
Z050.006.N (D=19)
Z051.010.R (for knives)
Z555.010.N (B=50)
www.sistemiklein.com
Z051.017.R (for ball bearing)
