2023 - Router bits for hand portable machines S= ∆6 - S= ∆1/4” (6,35) - S= ∆8
INSERT ROUTER BITS FOR PORTABLE ROUTERS Always looking for innovative products and most useful solutions, SISTEMI has developed a new line of router bits with interchangeable carbide knives, which have a higher hardness than the tips used in traditional brazed router bits. The main advantages granted by the use of HW reversible knives and the possibility of their easy replacement are: ®
- Longer tool life - Better finish quality - Higher measures precision
HW INSERT FLUSH TRIMMING BITS WITH BALL BEARING ART. WC120
- Better Quality/Price ratio - Environmental friendly
HW INSERT FLUSH TRIMMING BITS Z=1 ART. WC101 Complete with reversible knives
S∆8 WC120.127.R
Z050.003.N
D 12,7
Z055.551.N
B 20
L 62
Z051.503.N Screw for ball bearing
Z 2
Z051.501.R Screw for knives
HW INSERT RABBET BITS WITH BALL BEARING Z=2 ART. WC121
Complete with reversible knives
S∆8 WC101.120.R
Z055.330.N
D 12
B 29,5
L 66
Z051.501.R
HW INSERT V-GROOVING BITS Z=1 ART. WC109
Complete with reversible knives
S∆8 WC121.286.R
Z050.002.N
Complete with reversible knives
S∆8 WC109.176.R
Z055.001.N
D 17,6
B 8,5
α 45°
D 28,6
Z055.552.N
B 13,2
Z051.503.N Screw for ball bearing
E 7,95
L 48
Z051.501.R Screw for knives
L 53
HW INSERT FLUSH TRIMMING BITS WITH BALL BEARING Z=2
Z051.501.R
ART. WC122
HW INSERT CORE BOX BITS WITH UPPER BALL BEARING Z=1 ART. WC111
- Complete with reversible knives - The same knives can be used for both 45° and R= 3 bevel Complete with reversible knives
S∆8 WC111.127.R
D 12,7
B 13
R 6
L 59
S∆8 WC122.273.R
Z050.003.N Z050.018.N
1.26
Z055.550.N
Z051.501.R
www.sistemiklein.com
D 27,3
Z055.553.N
B 5,7
R 3
α 45°
Z051.501.R Z051.503.N Screw for ball bearing Screw for knives
L 59
