HW TOOLING SET FOR CONCAVE AND CONVEX QUARTER ROUNDS ART. TNL Ø D min = 105 R4 8 /6/
R4
/6/
8
24.8
1
ØD
- Cutterhead with two radius knives mounted on the tools - Produced in light alloy with HW knives - Manual feed (MAN) - Available also with bore 35
Item TNL110.25430 TNL110.25630 TNL110.25830
D 123 123 123
Spare parts:
Profile knife Profile knife Profile knife Wedge Wedge screw
d 30 30 30
B 24,8 24,8 24,8
Z 2 2 2
R 4-4 6-6 8-8
TNL110.25 Dimensions R= 4/4 A1 R= 6/6 B1 R= 8/8 C1 M8x20
Item Z055.810.R Z055.811.R Z055.812.R Z056.710.N Z051.805.R
Art. TX0004 complete with: TNL110.25430 + 2 pcs. Z055.811.R + 2 pcs. Z055.812.R
Item TX0004
13.28
Description Set in plastic box complete with cutterhead + 2 profile knives each R= 4/4 + R= 6/6 + R= 8/8 (bore 35 on request)
