2023 - Sawblades
HW SAWBLADES FOR CUTTING BEAMS
TEETH FEATURES
ART. DL
• WZ (ATB) alternate top bevel teeth • HW grade: KCR10
MATERIALS
Hardwood
Softwood
MACHINES
tem DL0735.04830 DL0735.07230
D 735 735
d 30 30
B/c 6,0/4,5 6,0/4,5
Z 48+6 72+6
Machines Hundegger Hundegger
DL0760.04830 DL0760.07230
760 760
30 30
6,0/4,5 6,0/4,5
48+6 72+6
Hundegger Hundegger
DL0800.07230
800
30
6,0/4,5
72+6
Hundegger
DL1000.07280 DL1200.09080
1000 1200
80+8 80+8
8,5/6,0 9,5/7,0
72 90+12
Essetre Essetre
HW FINE FINISHING SAWBLADES
Multi-rip
CNC machining centres
USEFUL INFORMATION • With HW rakers for better cutting quality • Balanced sawblades to work in perfect stability • Possibility to reach high feed speeds (up to 20/30/40 mt/min) • Ideal for vertical and horizontal cutting of beams, roof production and heavy wooden carpentry
TEETH FEATURES
ART. MLS
• WZ (ATB) alternate top bevel teeth • HW grade: KCR05+ (K01-C4)
MATERIALS α
SILENT SLOT
NO NOISE
Item MLS250.08030
D 250
d 30
B/c 3,0/2,5
a 10°
Z 80
Pin holes PH02
MLS300.09630
300
30
3,0/2,5
10°
96
PH02
MDF
PVC
Wood frames
PVC frames
MACHINES
Power mitre saw
Table saw
Panel saw
USEFUL INFORMATION • Ideal for cutting frames • Excellent finish on 45° cut • Pin holes: PH02=2/7/42 + 2/9,5/46,5 + 2/10/60
www.sistemiklein.com
12.35
