2023 - Sawblades
HW MULTI PURPOSE SAWBLADES (THIN KERF)
TEETH FEATURES
ART. CF
• WZ (ATB) alternate top bevel teeth • HW grade: KCR10
MATERIALS
Softwood
Single side veneer
Plastic coated
MACHINES Item CF150.02430 CF180.03030
D 150 180
d 30 30
B 2,2/1,6 2,2/1,6
Z 24 30
Pin holes
CF200.03230 CF250.04030
200 250
30 30
2,2/1,6 2,2/1,6
34 40
PH02
CF300.04830 CF350.05430
300 350
30 30
2,2/1,6 2,4/1,8
48 54
PH02 PH02
Power mitre saws
Table saw
Panel saw
USEFUL INFORMATION • Suitable for particle board in stack • Extra fine finish • For cutting expensive wood to reduce waste • Pin holes: PH02=2/7/42 + 2/9,5/46,5 + 2/10/60 RPM suggested referred to the blade diameter
HW MULTI PURPOSE SAWBLADES (THIN KERF)
TEETH FEATURES
ART. CG
• WZ (ATB) alternate top bevel teeth • HW grade: KCR10
MATERIALS
Hardwood
Softwood
PVC frames
MDF
MACHINES Item CG150.04830 CG180.05630
D 150 180
d 30 30
B 2,2/1,6 2,2/1,6
Z 48 56
Pin holes
CG200.06430 CG250.08030
200 250
30 30
2,2/1,6 2,2/1,6
64 80
PH02
CG300.09630 CG350.10830
300 350
30 30
2,2/1,6 2,4/1,8
96 108
PH02 PH02
Power mitre saws
Table saw
Panel saw
USEFUL INFORMATION
www.sistemiklein.com
• With thin kerf for less friction cuts • Extra fine finish • For separating plastic up to 10 mm cutting height chipboars • Pin holes: PH02=2/7/42 + 2/9,5/46,5 + 2/10/60
12.31
