2023 - Sawblades
HW CIRCULAR SAWBLADES FOR RIPPING AND CROSSCUTTING (MULTI PURPOSE)
TEETH FEATURES
ART. CB - CBS
• WZ (ATB) alternate top bevel teeth • HW grade: KCR05+ (K01-C4)
MATERIALS
α
D 100 120 150 180 200 250 300 300 315 350 350 400 450 500 600 700
d 20 20 30 30 30 30 30 35 30 30 35 30 30 30 30 40
Softwood
Single side veneer
Plywood
MACHINES
SILENT SLOT
Item CB100.02020 CB120.02020 CB150.02430 CB180.03030 CB200.03230 CBS250.04230 CBS300.04830 CBS300.04835 CB315.04830 CBS350.05430 CBS350.05435 CBS400.06030 CB450.06630 CB500.07230 CB600.08030 CB700.08440
Hardwood
B/c 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,2/2,2 3,5/2,5 3,5/2,5 4,0/2,8 4,2/2,8 4,2/2,8 5,2/3,6 6,2/4,0
NO NOISE
Z 20 20 24 30 34 40 48 48 48 54 54 60 66 72 80 84
a 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10° 10°
Pin holes
Power mitre saws
Table saw
Panel saw
PH02 PH02 PH02 PH02 PH02 PH02 PH01 PH01 PH01 PH01
USEFUL INFORMATION • Suitable for particle board in stack • Pin holes: PH01= 2/10/60 - PH02=2/7/42 + 2/9,5/46,5 + 2/10/60 Art. CB - CBS
RPM suggested referred to the blade diameter
HW MULTI PURPOSE CIRCULAR SAWBLADES
TEETH FEATURES
ART. CCS
• WZ (ATB) alternate top bevel teeth • HW grade: KCR05+ (K01-C4)
MATERIALS
α
Hardwood
Single side veneer
Paper coated
Plywood
Plastic coated SILENT SLOT
Item CCS250.04830 CCS300.06030 CCS350.07230 CCS400.08430
D 250 300 350 400
d 30 30 30 30
B/c 3,2/2,2 3,2/2,2 3,5/2,5 4,0/2,8
MACHINES
NO NOISE
Z 48 60 72 80
a 10° 10° 10° 10°
Pin holes PH02 PH02 PH02 PH02
Power mitre saws
Table saw
Panel saw
USEFUL INFORMATION • Pin holes: PH01= 2/10/60 PH02=2/7/42 + 2/9,5/46,5 + 2/10/60
www.sistemiklein.com
12.27
