2023 - Spare Parts
WASHERS
HW “VERSOFIX” KNIVES
ART. Z053
ART. Z055
10 pcs. set
Item Z053.001.N Z053.002.N Z053.003.N Z053.004.N Z053.010.N
D 9,5 8 12,7 16 9,5
d 3,2 4,8 4,8 5 6,4
- With “Kawedur” coating - 4 cutting edges - Spare parts for W120÷W127 and W138
SPRING WASHERS
Item Z055.220.N Z055.221.N
L 20 20
B 5,5 10
C 1,1 1,5
Z055.230.N Z055.231.N
30 30
6,5 10
1,1 1,5
Z055.250.N
50
10
1,5
ART. Z054
Item Z054.001.N Z054.002.N Z054.003.N Z054.410.N
D 6 7,5 11 9,5
d 2,5 3,2 6,4 6,4
KNIVES
HW STANDARD REVERSIBLE KNIVES
ART. Z055
ART. Z055 1 2 3 10 pcs. set 10 pcs. set
Item Z055.100.N
Drawing 1
spur
Z055.101.N
2
centerpoint
Z055.125.N Z055.126.N Z055.130.N Z055.135.N Z055.140.N
3 3 3 3 3
HW-knife for ∅25 HW-knife for ∅26 HW-knife for ∅30 HW-knife for ∅35 HW-knife for ∅40
10.10
- 4 cutting edges - 2 fixing holes - 5° right - Spare parts for Art. W153 - W154 - W155 - W156
Item Z055.423.N Z055.424.N Z055.425.N Z055.430.N Z055.440.N Z055.450.N
www.sistemiklein.com
Grade HC05 HC05 HC05 HC05 HC05 HC05
L 30 40 50 30 40 50
B 9 9 9 12 12 12
C 1,5 1,5 1,5 1,5 1,5 1,5
a 35° 35° 35° 35° 35° 35°
