2023 - Insert knives router bits and DP diamond router bits
DP GROOVE CUTTER FOR “LAMELLO®“ JOINTS CLAMEX P
DP GROOVE CUTTER FOR “LAMELLO®“ JOINTS ART. XAH
ART. XAH 15°
UP TO
30/50X
UP TO
TOOL LIFE
30/50X TOOL LIFE - For Lamello Clamex S classic biscuit joints - To be used on Top 20, Top 21, Classic X
- Suitable for making Clamex P connecting fittings for furniture, shelve units and kitchen making - To be used both on CNC machines and ZETA P2 hand power tool - Recommended for grooving corner and longitudinal joints on hardwood, veneered and laminated MDF with the P-System anchorage
Item XAH100.10330 XAH100.10630 XAH100.10322
D 100,4 100,4 100,4
d 30 30 22
B 7 7 7
Z 3 6 3
Item XAH100.20622
Pin holes 4/6,6/48 4/6,6/48 4/4/36
CLAMEX P JOINTS
D 100
d 22
B Z 3,96/2,8 3
Pin holes 4/4/36
DP SAW BLADES FOR CUTTING ABRASIVE MATERIALS ART. XGE B c
D
TOOL SET FOR CNC d
Art. T118...
Art. T128.140.R T128.141.R T128.145.R P-SYSTEM ANCHORAGE
①
②
③
10
Art. XAH...
15
1,5
- Suitable for cutting cement fiber, plasterboards, fiber reinforced plastics, solid surface and Eternit - DP flat teeth - DP tooth height 3,5 mm - ♫ = no-noise
1,5
UP TO
30/50X TOOL LIFE
Pin holes: PH02= 2/7/42 + 2/9,5/46,5 + 2/10/60
Item XGE160.10420 ♫ XGE160.10820 ♫
D 160 160
d 20 20
B/c 2,4/1,6 2,4/1,6
Z 4 8
Pin holes 2/6/32 2/6/32
XGE190.10420 ♫
190
20
2,4/1,6
4
2/6/32
XGE200.10430 ♫ XGE200.10830 ♫ XGE216.10830 ♫ XGE230.10630 ♫ XGE250.10630 ♫ XGE250.11230 ♫
200 200 216 230 250 250
30 30 30 30 30 30
2,4/1,6 2,4/1,6 2,4/1,6 2,4/1,6 2,4/1,6 2,4/1,6
4 8 8 6 6 12
2/7/42 2/7/42 2/7/42 PH02 PH02
XGE300.11230 ♫ XGE300.12030 ♫
300 300
30 30
2,4/1,6 2,4/1,6
12 20
PH02 PH02
www.sistemiklein.com
9.27
