2023 - Router bits for aluminium, plastic and advanced materials
HW INSERT ROUTER BITS FOR PLASTIC MATERIAL
HW HINGE BORING BITS FOR ALUMINIUM Z=2
ART. W190.RU – WE190.RU – WG190.RU
ART. U140
10°
R=2
B
- Chip-breaker execution Z=2 - For working aluminium R=2 10° shear angle
- Used for surfacing plastic board material and making deep rabbet (also known as Flycutters - Spoilboard cutters) - Special insert knives with radius (R=2) for smoother cuts and no risk of marks and scratch. - 10° shear angle for better performance - To be used on machining centres and CNC routers - Right-hand rotation - This item is sold complete with a hex key
Item W190.100.RU W190.101.RU
Z051.205.R
WE190.800.RU WG190.635.RU
Z051.020.R
D 100 101,6(4”)
Z055.107.N
B 14 14
L 80 76(3”)
S ∅20x55 ∅19,05(3/4”)x55
76 3 70(2-3/4”) 2
∅12x50 ∅12,7(1/2”)x45
D 25 35
Z051.302.R
Z059.001.L
L 57,5 57,5
S 10x26 10x26
Rot. RH RH
Z059.001.R
SOLID CARBIDE DOUBLE DIAMETER SPIRAL BITS Z=1 ART.
U190
Z052.205.N
80 14 63,5(2-1/2”) 14
Z055.107.N
Z 3 3
RH rotation U140.250.R U140.350.R
- Right-hand rotation with "UP CUT SPIRAL" - Use on CNC machines - For working aluminum and non-ferrous materials
RH rotation U190.030.R U190.055.R U190.060.R
Z052.103.N
VHW TWIST DRILLS Z=2
d 3 5,5 6
D 8 8 11,5
B 5 10 10
I 30 25 40
L 80 100 100
S 8 8 12
HS-E DOUBLE DIAMETER SPIRAL BITS FOR ALUMINIUM Z=2
ART. L120
ART. U290 - U291
- Solid carbide - 2-flutes - For natural wood, pressed wood, veenered, chipboard, laminated and MDF - Ideal for Trespa, Aluminium and Plastic - To use with adaptor bushes Art. Z010/Z011
RH rotation L120.020.R L120.025.R L120.030.R L120.032.R L120.035.R L120.040.R L120.045.R L120.050.R L120.060.R
8.12
LH rotation L120.020.L L120.025.L L120.030.L L120.032.L L120.035.L L120.040.L L120.045.L L120.050.L L120.060.L
D 2 2,5 3 3,2 3,5 4 4,5 5 6
B 18 22 22 22 25 25 28 28 28
L 49 55 55 55 55 55 58 58 58
RH rotation U290.055.R U290.060.R U290.061.R U290.062.R U290.065.R U290.070.R U290.071.R U290.072.R U290.080.R
d/D 5,5/11,5 6/11,5 6/12 6/14 6,5/13,5 7/13 7/14 7/15 8/15
B/I 12/35 12/35 15/35 15/35 15/35 12/35 12/35 12/35 12/35
L 100 100 80 80 100 100 100 100 100
S 10 10 10 10 10 10 10 10 10
U291.055.R U291.060.R U291.065.R U291.066.R U291.067.R U291.085.R
5,5/11,5 6/12 6,5/11,5 6,5/12 6,5/13,5 8,5/14
12/35 12/35 12/35 18/45 12/35 12/35
120 100 100 120 120 100
12 12 12 12 12 12
