2023 - Router bits for aluminium, plastic and advanced materials
SOLID CARBIDE SPIRAL BITS UP CUT Z=2
SOLID CARBIDE SPIRAL CUTTERS Z=5 SUPER-FINISHING COATED
ART. U120
ART. U115.KD
UP TO
- Right-hand rotation with "UP CUT SPIRAL” - With chip-breaker - Discontinuous cutting edge - For working wood and aluminium material - Use on CNC and high speed machines
RH rotation U120.140.R U120.160.R U120.180.R U120.200.R
D 14 16 18 20
4/6X TOOL LIFE B 42 42 62 62
L 100 100 120 120
S 14 16 18 20
- For working plexiglass and acrylic - Right-hand rotation with "UP CUT SPIRAL" - Polished and coated cutting edge for improved chip evacuation and less friction for excellent performance - To be used on machining centres and CNC routers - Especially made for plexiglass polishing and best finishing cuts
RH rotation U115.060.RKD U115.080.RKD U115.100.RKD
Router bits with diameter from 14 mm to 20 mm, are produced with shank fit for Seeger retaining rings
SOLID CARBIDE SPIRAL BITS UP CUT Z=2 COATED ART. U120.KD
UP TO
4/6X TOOL LIFE - Right-hand rotation with "UP CUT SPIRAL” - Polished and coated cutting edge for improved chip evacuation and less friction for excellent performance - Discontinuous cutting edge - For working wood and aluminium material - With chip-breaker - Use on CNC and high speed machines
RH rotation U120.140.RKD U120.160.RKD U120.180.RKD U120.200.RKD
8.08
D 14 16 18 20
B 42 42 62 62
L 100 100 120 120
S 14 16 18 20
www.sistemiklein.com
D 6 8 10
B 25 30 35
L 70 80 80
S 6 8 10
