2023 - Solid carbide spiral cutters, toolholders and accessories for CNC router machines
SOLID CARBIDE SPIRAL ROUTER BITS FINISH/ROUGHING STYLE COATED
SOLID CARBIDE SPIRAL ROUTER BITS FINISH/ROUGHING STYLE COATED
ART. T344.KD
ART. T354.KD
UP TO
UP TO
4/6X
4/6X
TOOL LIFE
TOOL LIFE
Excellent finish on panel top side
Excellent finish on bottom side
- Right-hand rotation with "UP CUT SPIRAL" - To be used on machining centres, CNC routers and point to point machines - Semi-finished chip-breaker execution - For softwood and hardwood, chipboard, MDF, HF, plywood, plastic coated, mineral materials (CORIAN® ecc.)
RH rotation T344.080.RKD T344.100.RKD T344.120.RKD T344.121.RKD T344.140.RKD T344.160.RKD T344.161.RKD T344.200.RKD T344.201.RKD
D 8 10 12 12 14 16 16 20 20
B 30 35 35 45 55 55 75 55 75
L 80 80 80 90 110 110 130 110 130
Z 2 2 3 3 3 3 3 3 3
- Right-hand rotation with "DOWN CUT SPIRAL" - To be used on machining centres, CNC routers and point to point machines - Semi-finished chip-breaker execution - For softwood and hardwood, chipboard, MDF, HF, plywood, plastic coated, mineral materials (CORIAN® ecc.)
RH rotation T354.100.RKD T354.120.RKD T354.160.RKD T354.161.RKD T354.200.RKD
D 10 12 16 16 20
B 35 35 55 75 55
L 80 80 110 130 110
Z 2 3 3 3 3
SOLID CARBIDE SPIRAL ROUTER BITS FINISH/ROUGHING STYLE COATED
HOW TO DETERMINE THE FEEDING SPEED RELATING TO THE DIAMETER: - Referring to item T344RKD with right hand rotation (UP CUT STYLE), Z=2/3 - Referring to item T354RKD with right hand rotation (DOWN CUT STYLE), Z=2/3 - Referring to item T354LKD with left hand rotation (UP CUT STYLE), Z=2/3 - RPM 18.000
ART. T354.KD
Soft wood
UP TO
4/6X TOOL LIFE Feed (m/min)
Excellent finish on bottom side
Cutting depth (mm)
Hard wood
- Left-hand rotation with "UP CUT SPIRAL" - To be used on machining centres, CNC routers and point to point machines - Semi-finished chip-breaker execution - For softwood and hardwood, chipboard, MDF, HF, plywood, plastic coated, mineral materials (CORIAN® ecc.)
Feed (m/min)
LH rotation T354.100.LKD T354.120.LKD T354.160.LKD T354.161.LKD T354.200.LKD
B 35 35 55 75 55
Router bits with diameter from 12 mm, are produced with shank for Seeger retaining rings Cutting depth (mm)
7.66
D 10 12 16 16 20
www.sistemiklein.com
L 80 80 110 130 110
Z 2 3 3 3 3
