2023 - Solid carbide spiral cutters, toolholders and accessories for CNC router machines
SOLID CARBIDE SPIRAL CUTTERS “LAMELLO®” COATED
SOLID CARBIDE COMPRESSION CUTTERS Z=2+2 WITH DOUBLE BALL BEARING
ART. T169.KD
ART. T166
B L
Excellent finish on both upper and lower side
UP TO
4/6X
- Right-hand rotation with double flute compression spiral (UP & DOWN). The bottom part is up-cut while the upper part is down cut, ensuring excellent finish on both sides of the panel. - Double ball bearings guide for greater precision of trimming - Special spiral geometry which provides better chip evacuation and smoother cuts on laminate panels.
RH rotation T166.080.R NEW T166.120.R NEW
D 8 12
B 36 51
L 95 110
TOOL LIFE - Suitable for making the groove for Lamello P-System with CNC router - RH rotation - Polished and coated cutting edge for improved chip evacuation and less friction for excellent performance - Longer tool life and greater cutting quality
Z 2+2 2+2
Item T169.098.RKD Z050.032.N
Z050.031.N
(T166.080.R)
(T166.120.R)
D 9,8
B 23
L 80
S 12
Z 2
SOLID CARBIDE FLUSH TRIM BITS WITH DOUBLE BALL BEARINGS Z=2 B
ART. T168
L
SOLID CARBIDE SPIRAL CUTTERS, ROUGHING STYLE Z=2 ART. T170 - Right-hand rotation with "UP CUT SPIRAL" - Double ball bearings guide for greater precision of trimming - Special spiral geometry which provides better chip evacuation and smoother cuts compared to standard flush trim bits - For natural wood, pressed wood, veneered, laminate and melamine
RH rotation T168.127.R
D B 12,7 (1/2”) 51
L 125
S 12
Z 2
Z050.007.N
- Right-hand rotation with "UP CUT SPIRAL" - Chip-breaker execution - Z= 2 for the best chip removal
RH rotation T170.080.R T170.100.R T170.120.R T170.121.R
D 8 10 12 12
B 35 35 35 45
L 80 80 80 90
Router bits with diameter from 12 mm, are produced with shank for Seeger retaining rings
7.64
www.sistemiklein.com
S 8 10 12 12
Z 2 2 2 2
