2023 - Solid carbide spiral cutters, toolholders and accessories for CNC router machines
SOLID CARBIDE SPIRAL CUTTERS, ROUGHING STYLE Z=3 ART. T144
SOLID CARBIDE SPIRAL CUTTERS ROUGHING STYLE Z=3, COATED ART. T144.KD
UP TO
4/6X - Right-hand rotation with "UP-CUT STYLE" - Chip-breaker execution - To be used on machining centres, CNC routers and point to point machines - Suitable for roughing, they guarantee a high feed rate
RH rotation T144.080.R T144.081.R T144.095.R T144.100.R T144.101.R T144.120.R T144.121.R T144.122.R T144.123.R T144.127.R T144.128.R T144.140.R T144.141.R T144.142.R T144.159.R T144.160.R T144.161.R T144.162.R T144.163.R T144.180.R T144.181.R T144.182.R T144.191.R T144.200.R T144.201.R T144.202.R T144.250.R T144.251.R NEW
D 8 8 3/8” 10 10 12 12 12 12 1/2” 1/2” 14 14 14 5/8” 16 16 16 16 18 18 18 3/4” 20 20 20 25 25
B 22 35 1” 35 45 35 45 55 42 1-1/8” 1-5/8” 45 55 58 2” 45 55 72 62 55 72 102 2” 55 72 102 102 130
L 80 80 3” 80 100 80 100 100 90 3” 3-1/2” 100 100 110 4” 100 100 120 110 100 120 150 4” 100 120 150 155 195
Z 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
HOW TO DETERMINE THE FEEDING SPEED RELATING TO THE DIAMETER:
TOOL LIFE - Right-hand rotation with "UP CUT SPIRAL" - Polished and coated cutting edge for improved chip evacuation and less friction for excellent performance - Chip-breaker execution - Longer tool life and greater cutting quality - Suitable for roughing, they guarantee a high feed rate
RH rotation T144.081.RKD T144.100.RKD T144.101.RKD T144.121.RKD T144.161.RKD
D 8 10 10 12 16
B 35 35 45 45 55
ART. T144
- Left-hand rotation with "DOWN-CUT STYLE" - Chip-breaker execution - To be used on machining centres, CNC routers and point to point machines - Suitable for roughing, they guarantee a high feed rate
LH rotation T144.081.L T144.100.L T144.121.L T144.122.L T144.141.L T144.160.L T144.161.L T144.162.L T144.180.L T144.200.L
D 8 10 12 12 14 16 16 16 18 20
B 35 35 45 55 55 45 55 72 55 55
7.56
MDF
Feed (m/min)
Soft wood
Feed (m/min)
Feed (m/min) Cutting depth (mm)
Z 3 3 3 3 3
SOLID CARBIDE SPIRAL CUTTERS, ROUGHING STYLE Z=3
- Referring to item T144 with right hand rotation (UP CUT STYLE), Z=3 - RPM 18.000
Hard wood
L 80 80 100 100 100
Cutting depth (mm)
www.sistemiklein.com
Cutting depth (mm)
L 80 80 100 105 110 100 110 125 115 115
Z 3 3 3 3 3 3 3 3 3 3
