SOUNDUD

os D u ud n

a modular soundproofing panel that's no dud!

fun fact.

coconut husk fibers used to be part of armors

emergent architecture.

in fulfillment of the requirements of the EMERGE3 specialization track

C t nO e

of the Bachelor of Science in Architecture

School of Environmental Design

DLS - CSB

Under the mentorship of:

Ar. Lyle La Madrid & Ar. Cayner Curitana

InCayn

this is ourbrainchild !

ID 118

Isabel Rosales Ramon Tecs

erLyles

abstract

According to the World Health Organization, noise can lead to infections, stress, and other illnesses whereas they were able to conclude that noise pollution causes the same level of risks as any other type of pollution The behavior of an individual or of a group is heavily influenced by the surrounding environment they are in In the Philippines today, there are currently several laws that tackle excessive noise and public nuisance. Although, with the recent pandemic and work from home setups we are in right now, it is important to question whether architectural and structural designs in small spaces such as condominiums are able to support this type of lifestyle.

In this study, the researchers aim to determine the best design for a soundproofing material that will provide the Philippines with more high quality soundproofing options. In addition, this study aims to develop a modular soundproofing option that is both aesthetically pleasing and cost-efficient that will encourage privacy and sustainability for its users

soundud.

NOISY IN MANILA

hindi ka ba nabibingi?

introduction

The Philippines, especially its big cities, is quite a lively but boisterous scene. It is more surprising to have a quiet day than a day filled with noise from the streets, the neighbors’ parties, and the on-going and never-ending road or water construction down the street This shared experience is how the researchers were led to the production of the Soundud – a modular soundproofing panel with a purpose to provide another high-quality soundproofing option in the local market that’s easy to buy and easy to apply for residential spaces. Derived from its name, the Soundud is created to cancel out noise and let its mission to be a pollutant and public nuisance fail

background of the study

City living, work-from-home conditions, condominium life and other residential related instances denote exposure to noise pollution whether by traffic, neighborhood or industrial noise Nonetheless, there is a scarcity in terms of sound proofing sources in the Philippines locally To pursue quietness by design, our task is to provide more options of sound proofing that are accessible, aesthetic and affordable to the masses, and simultaneously be sustainable with our chosen materials.

© Ray Melvin Calaan, 2023 -- Unsplash

w O hats ' pr the

problem statement

The external environment can deeply impact individuals internally, and sound can influence people in the same manner. The purpose of this thesis is to address undesirable noise through sound absorption by discovering alternative materials in sound proofing If this issue is neglected, noise pollution can lead to deafness, sleep disorders, cardiovascular health problems, mental problems and hypertension (United States Environmental Protection Agency, 2022)

Ob

© Klaryss Puno, 2020 -- Unsplash

MethO -dOlOg y

cube box or chamber for sound absorption test

procedure: a standard stereo speaker would be placed inside the box or chamber wherein the sound absorption of the material is obtained for 5 minutes

data collecting instrument

decibel meter SPL meter iPad application

purpose: a decibel meter that can measure the sound level performance for each material in the experiment

test subject variables

comprises dependent and independent variables

dependent: tested and approved materials that are readily available in the market independent: proponents' own combination of materials [the soundud panel]

panel materials

plywood box

material lining speaker

cotton wall foam board cork board cocohusks cardboard plywood

procedures

Add 1/3 cup of PVA glue to cup

Add 2/3 cup of Coconut Husks to cup

Mix the PVA glue and Coconut husks until fully covered

Lay the mixture evenly and press down with heavy weight until dry

Coconut husks boiled in water and strained

Impurities removed and the husk fibers separated by hand

Coconut husk fibers laid out evenly.

PU foam applied

Compressed with spare board and weights.

Same as Test 2 but with less PU foam Applied

experimentation.

h

ow weStart

ed

product design & development procedure

The project required exploring material options, venturing into more testing and form exploration. Once the desired layers, material composition and sound proofing levels were achieved, we strived to accomplish our prototype following our goals to design an aesthetic and functional sound proofing panel design & exploration stage testing stages

final stage (end goal)

material selection design & form +

layering and acoustics testing

ow it could go further

lack of stakeholder expectations

sound tests and sound testing equipment

Cube Chamber Box Testing

Based on other experimentations, the testing of materials was conducted under multiple frequencies to test how well it would perform under different noise conditions. This can help further fine-tune the product to fit a variety of environments and conditions

Sound Transmission Loss (STL) Test

The proper testing method to get a Sound Transmission Class (STC) Rating should be used in order to properly compare it against the standard STC ratings of other products.

Impact Sound Insulation Test

Impact noise, such as footsteps or dropping objects, can travel through floors and walls This test evaluates the panel's ability to reduce impact noise transmission. A source of impact noise is introduced on one side of the panel, and measurements are taken on the other side to determine the reduction in impact noise

Field Tests

Installing panels in real-world settings and conducting listening tests can provide valuable feedback on their practical effectiveness This involves measuring sound levels before and after installation and gathering subjective opinions on sound quality and reduction.

Flammability and Safety Tests

subdued = quiet

SOunD Dud +

dud = fail =

"soundud" is the failure of sound

4 in 1

the soundud panels are sold in packs of four since one triangular soundud panel has the small dimensions of

270 mm x 130 mm x 30 mm thk 4 panels fit in a standard 30 x 30 cm acoustic sheet

soundweb

research findings show that forming a spiderweb leads to efficient sound absorption

from this, the soundud shape was formed [triangular]

coconut husk

aim to repurpose these natural fibers [bound with PU Foam]

lightweight, affordable, and accessible

d

1 2 3 4

cork proven as efficient sound dampeners

o

uble wall cardboard

for further sound absorption

material composition

The amalgamation of coconut husk, cork, cardboard, and foam board in the Soundud soundproof panel epitomizes a thoughtful fusion of natural and recycled elements. This composition not only contributes to enhanced acoustic insulation but also champions sustainability

what is it made of?

soundud

posibilities are endless

The possible configurations are limited only by one's own creativity. Traditional soundproofing solutions often sacrifice aesthetics for utility, imposing limitations on design freedom and spatial adaptability. In stark contrast, Soundud envisions a world where homeowners and designers can craft acoustic environments that mirror their creative visions Through a pioneering modular framework, these soundproof panels can be effortlessly arranged into an array of shapes, sizes, and patterns, tailoring both auditory comfort and visual appeal to each unique space.

Beyond the remarkable adaptability, Soundud’s modular design embodies the essence of versatility Whether it's the cozy confines of a living room, the sprawling openness of a loft, or the intimacy of a home office, Soundud panels gracefully harmonize with the contours of any space The modular concept transcends the constraints of conventional soundproofing solutions, allowing homeowners to curate acoustic experiences that resonate with their lifestyles and aesthetic preferences.

full wall capability.

made to fit any space.

made possible by iterations introducing the soundud corner pieces

soundud

resources

United States Environmental Protection Agency (EPA). (2022, August). Clean Air Act

Title IV - Noise Pollution EPA gov https://www epa gov/clean-air-act-overview/cleanair-act-title-iv-noise-pollution

Everest, F Alton , & Pohlmann, Ken C (2009) Master Handbook of Acoustics McGraw-Hill Companies, Inc.

Hong Hua. (2020). Acoustic coconut fiber panel. https://studiohuahong.com/AcousticCoconut-Fiber-Panel

fun fact burning coconut husk fibers make good insect repellant
