MOTOR
KRAFTSTOFF
1.8
NG
Gewinde g
ød mm
VE
7 8 10 12 14 17,5
1 1 1 1 1 1
g
Bestell-Nr.
g
KRAFTSTOFF
00 126 901 00 126 902 00 126 903 00 126 904 00 126 905 00 126 906
5 6 6/8 6/8/10 10/12 12/15
M10 x 1 M12 x 1,5 M14 x 1,5 M16 x 1,5 M18 x 1,5 M22 x 1,5
d
UNIVERSAL Überwurfmuttern, metrische Gewinde Ähnlich DIN 3870
5 6 6/8 10 12/15 8 10
1/8" 1/4" 1/4" 3/8" 1/2" 1/4" links 3/8" links
7 7,9 9,7 12 15,5 9,8 12,6
1 1 1 1 1 1 1
Bestell-Nr.
NG
Überwurfmutter
ød mm
VE
KRAFTSTOFF - Universal
00 126 908 00 126 909 00 126 910 00 126 911 00 126 912 00 126 913 00 126 914
d
Überwurfmuttern, Zollgewinde Ähnlich DIN 3870
00 126 920 00 126 921 00 126 922 00 126 923 00 126 924 00 126 925 00 126 926 00 126 927 00 126 928 00 126 929 00 126 930 00 126 920 00 126 921 00 126 924 00 126 926
5 6 6 6 8 8 10 10 12 12 15 5 6 8 10
M10 x 1,5 M12 x 1,5 M14 x 1,5 M16 x 1,5 M14 x 1,5 M16 x 1,5 M16 x 1,5 M18 x 1,5 M18 x 1,5 M22 x 1,5 M22 x 1,5 1/8" 1/4" 1/4" 3/8"
6,2 7,4 9,5 11,4 9,5 11,5 11,2 13,3 13,5 17 17 6,2 7,4 9,5 11,2
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Bestell-Nr.
NG
Gewind g
ød mm
VE
00 126 935
10
M16 x 1,5
11,2
1
00 126 936
12
M18 x 1,5
13,4
1
00 126 937
15
M22 x 1,5
17,8
1
d
Dichtkegel Ähnlich DIN 7608, mit Dichtkegel
d
Dichtbund Flachdichtend
Obige Ersatzteile werden von ausgesuchten Herstellern produziert und sind keine Original-Ersatzteile, sofern diese nicht ausdrücklich als „Original“ bezeichnet werden. Die angeführten Originalnummern und Systembezeichnungen dienen nur zur Identifizierung der Teile und dürfen nicht weiterverwendet werden. Falls nicht anders angeführt – Abmessungen in mm. Satz-, Druckfehler und Änderungen vorbehalten.
281
