ELECTRICAL COMPONENTS
SEALED BATTERY BOX
Part # 74051
ELECTRICAL COMPONENTS
• Ideal for relocating a battery to the rear of any race, street or show vehicle with or without a rear firewall • Holds a Series 21, 24, 26, 34, 42, 54, 55, 56, 61, 62, 63, 85, 86, 96R battery with either top-post or side-post terminals • Outside Dimensions: 13-1⁄8" W, 11-1⁄8" D, 11-1⁄8" T • Fully approved for racing by NHRA, IHRA and SCCA No. 74051 • Includes grommets and all mounting hardware • Does not include battery cable; use with Moroso Battery Cable Kit No. 74055, below Description Sealed Battery Box, Black
BATTERY CABLE KITS • High-grade 2 gauge copper cable provides unrestricted current flow • Rugged PVC insulation resists most car fuels, oils and under hood cleaners • Available with and without battery terminals • I deal for relocating a battery to the rear for improved weight transfer Part # Description 74005 Battery Cable Kit, 20' with 4 terminals 74055 Battery Cable Kit, 20' with 4 terminals, 8' with top-post terminals and 6" 12 gauge leads with butt connectors*, rubber-lined clamps, grommets and shrink sleeving. Use with Sealed Battery Box No. 74050. *Terminated at both ends. Cut in two to desired length.
No. 74055
BATTERY/ WEIGHT BOX • Bolts together for easy installation • Bottom flange for secure attachment • Holes provided for battery cables • Constructed from 1⁄8" thick mild steel • Includes 3⁄8" hold down rod and grommets • Fits "Series 24" batteries • Meets sanctioning body requirements for weight box and battery containment in cars with rear firewall • Inside dimensions: 12-3⁄8" long x 9-3⁄4" wide x 10" high
No. C4029
Part # Description C4029* Battery/Weight Box
*NOTE: Check your rule book for specific mounting requirements
The Chassis People
419
