VERMICULITE FIRE BRICK INSTALLATION SEQUENCE - WESTFIRE UNIQ 17/18/19 Uniq 19

1 – Top Turbulence Brick 2 – Rear Brick 3 – Left Base Brick 4 – Right Base Brick 5 – Grate 6 – Metal Spacer 7 – Left Side Brick 8 – Right Side Brick 9 – Top Baffle Brick 10 – Log Retainer

Uniq 18

Uniq 17

1 9 2

7

3

5 6 10

4

8


VERMICULITE FIRE BRICK INSTALLATION SEQUENCE - WESTFIRE UNIQ 17/18/19 Installation procedure:

Top turbulence baffle brick 1 – positioned on secondary air pipe & between two retaining lugs on rear panel.

Rear brick 2 – fitted with angled edge at rear / bottom.

Left & right base bricks 3 & 4 fitted either side of grate 5 and metal spacer 6.


VERMICULITE FIRE BRICK INSTALLATION SEQUENCE - WESTFIRE UNIQ 17/18/19

Left & right side bricks 7 & 8 positioned on base bricks 3 & 4.

Top baffle brick 9 ( angled edge resting on chrome tertiary air inlets) fitted and supported with two side pins

Log retainer 10 positioned.

Eurostove Limited, Unit S5, Mendip Industrial Estate, Mendip Road, Rooksbridge, Axbridge, Somerset. BS26 2UG t: 01934 750500 f: 01173 156207 e: info@eurostove.co.uk ww.eurostove.co.uk
