Polyamide pipe line 100bar, ø9,6mm-3/8" - HP pipe
MADE IN ITALY
IT.0011
IT.0097
IT.0278
IT.0279
HP polyamide pipe ø9,6mm - 3/8",rods of 750mm (max. pressure 100bar with 23°C temperature)
HP polyamide pipe ø9,6mm3/8", rods of 3000mm (max. pressure 100bar with 23°C temperature)
HP polyamide pipe ø9,6mm - 3/8", rolls of 100m (max. pressure 100bar with 23°C temperature)
HP polyamide pipe ø9,6mm - 3/8", rolls of 25m (max. pressure 100bar with 23°C temperature)
IT.0441 Tube cutter for polyamide pipe ø2-12mm
CLA.PAS008
ZX.0524-38
Rubberized stainless steel clamp, to fix polyamide pipe ø9,6x5mm
Ball valve kit G1/4"F-F, with stainless steel quick couplings ø9,6mm - 3/8" for HP line shutoff
ZX.1235 Water supply Kit, comprising 3m Rilsan d.10 hose with quick male-female connector 3/4" F automatic coupling, piper outer ø19mm
in packs of 100pcs
Couplings IT.0339
IT.0340
IT.0341
IT.0342
Start quick fitting, made of nickeled brass, 1/4”G - ø9,6mm-3/8”
Straight nozzle holder quick fitting, made of nickeled brass, ø9,6mm - 3/8”
Straight nozzle holder quick fitting, made of nickeled brass, ø9,6mm - 3/8”
End line nozzle holder quick fitting, made of nickeled brass, ø9,6mm - 3/8”
2 holes - 120° threaded 10/UNC/2A
1 hole threaded 10/UNC/2A
in packs of 25pcs 1 hole threaded 10/UNC/2A
IT.0343
IT.0344
IT.0345
IT.0347
Straight pipe connection quick fitting, made of nickeled brass, ø9,6mm - 3/8”
Elbow pipe connection quick fitting, made of nickeled brass, ø9,6mm - 3/8”
Tee pipe connection quick fitting, made of nickeled brass, ø9,6mm - 3/8”
End of line cap in nickel-plated brass ø9,6mm - 3/8”
