CABLE ROUTING
SPEC
CABLE ROUTING Pass the right handlebar switch lead inside the front brake hoses and over the throttle cables. Install the throttle cables to the hook so that the pulling side of the throttle cables is routed downward. Pass the clutch cable through the guide. Plastic locking tie shall be positioned at 15 mm (0.59 in) below from the upper bracket. Clamp the left handlebar switch lead to the front fork with the plastic locking tie and cut the tip of the tie. Clamp it to the protector section. Clamping position should be 10 mm (0.39 in) or lower from the top end of the under bracket. Attach the horn lead to the hook on the steering cover.
Right handlebar switch lead Clutch cable Main switch lead Left handlebar switch lead Throttle cable (return side) Throttle cable (pull side) Horn lead Steering cover Front brake hose Throttle cables Joint
6
