MEFI Fuel Injection
Ignition Control Module
The external ignition control (IC) module is mounted on a bracket with the coil on the back of the engine. This is a one piece assembly. The IC module contains the coil driver. It receives an ignition timing signal from the ECM and triggers the coil. Pin A…..Ignition Voltage Pin B…..Ignition Timing Signal Pin C…..Ground Pin D…..Coil Driver
119
