Repair instructions
Intermediate housing Reconditioning the intermediate housing, model 280 and 285
3. Remove the plastic washers (1) and the wear washer (2).
1. Remove the 2 screws holding the hose connection (1) on the yoke. Remove the hose connection and the gasket.
9991801
9991801 884311 884259
4. Press out the sealing rings and the needle bearing. Use special tool 884259 and 9991801. NOTE! There is a sealing ring on each side of the needle bearing.
2. Dismantle the yoke by driving out the steering spindle. Use special tools 884311 and 9991801. Then remove the retaining pawl from the yoke.
73
