Functions of and How to Use Adjustment Mode Other Functions and How to Use Them
Display: [:Disp. Late data ]
1. Language
[:Disp. Max. data]
The menu [Language] is used to change the
3. Display of latest overload data
language for message appearing on the moment display. The message on the menu [Language] is always displayed in English.
The selection of [:Disp. Late data ] results in the latest registered overload history data being displayed. The time when overload history data has been registered is indicated in the moment display. To view the next data on record (up to 50 items), press the scroll-down key.
1. Select the main menu [• Language] in the adjustment mode, and press the register key to select the menu. 2. When message for language selection appears, operate the scroll-up or scroll-down key to display the aimed language. Display example: [= Japanese ] Press the scroll-down key. [: English] The sign “=” at the left side of the message shows that the language is currently set to be used.
Moment display Display example: [99. 01. 23 12:35 ]
3. When the aimed language is displayed, press the register key. After the registration, the sign “:” at the left side of message changes to “=”. Display example: [: English] Press the register key. [=English] 4. Press the display alteration key to exit the menu. After this, the messages on the moment display are switched to the newly set language.
2. Overload History Display The records of crane operations beyond overloading limit are displayed. You can choose between the displays of latest overload data and of the greatest overload data. 1. Select the main menu [• Disp. O/L data ] in the adjustment mode, and press the register key to select the menu. 2. Use the scroll-up or scroll-down key until the menu of latest overload ratio or peak overload ratio appears. Select it by pressing the register key.
