Functions of and How to Use User Mode (TL-300E-3) Selecting Number of Parts of line [NOTICE] If the registered number of parts of line is smaller than the standard number, a maximum allowable lifting load is limited, depending on the registered number. If zero(0) is registered, however, the AML performs as if the standard number were registered. Similarly, the AML works on the basis of the standard number of parts of line if the registered number is larger than the standard number, or other than the values specified for your model. When the power supply is turned on (i.e. PTO switch ON), the standard number of parts of line corresponding to the work condition is selected. Register the number of parts of line by use of the number of parts of line select key and the register key, as follows:
1. Press the number of parts of line select key. The number of parts of line symbol will flash, and the number of parts of line will be shown on the jib angle display in a flashing mode.
3. Once the intended number of parts of line is set, press the register key to register the number. Then, the number of parts of line symbol will be turned off and the jib angle display will return to a normal status.
2. Press the increase or the decrease key to set the number to the actual number of parts of line.
[NOTICE] The number of parts of line can be confirmed by pressing the display alteration key.
[NOTICE] When the increase or the decrease key is pressed, a numeral showing the number of parts of line changes from flashing to lighting, and increases or decreases. When the increase or the decrease key is kept pressed, the number of parts of line continuously increases or decreases.
