Functions of and How to Use User Mode (TL-300E-3) Display Panel 1
9. Load radius limit symbol
1. Jib angle display
This symbol indicates that the load radius display [11] is showing the registered load radius limit value. The load radius symbol [10] is also displayed at the same time.
When jib lift is selected, the jib offset angle is displayed. When the number of parts of line select key or the display alteration key is pressed, the number of parts of line is displayed. Also, when an upper boom angle limit has been registered, the registered upper boom angle limit value is displayed while the register key is pressed.
10. Load radius symbol This symbol indicates that the load radius display [11] is showing the load radius.
2. Number of parts of line symbol
11. Load radius display Normally displays the crane's load radius. Displays the boom swing angle while the display alteration key is pressed. When a load radius limit has been registered, the registered load radius limit value is displayed while the register key is pressed.
This symbol indicates that the jib angle display [1] is showing the number of parts of line. 3. Boom length symbol This symbol indicates that the boom length display [13] is showing the boom length. 5. Jib angle symbol
13. Boom length display
This symbol indicates that the jib angle display [1] is showing the jib offset angle.
Normally displays the boom length. Displays the lifting height while the display alteration key is pressed. When a lifting height limit has been registered, the registered lifting height limit value is displayed while the register key is pressed.
6. Jib lift symbol This symbol indicates that the jib lift is selected. Its also indicates the condition of the jib. 7. Actual load display Displays the actual load.
14. Lifting height symbol This symbol indicates the boom length display [13] is showing the lifting height.
8. Rated lifting capacity display Displays the rated lifting capacity.
19
W301-0351E
