09 Hydraulic system 09 20 Valves
Description 1 Supply plate.
11 Tie-rod.
2 Intermediate plate with flow divider.
12 Supply plate casing.
3 4 position "kick-out" double effect auxiliary valve.
13 Pressure limiter .
4 Hose.
14 "kick-out" 4 position double effect control.
5 Spacer.
15 Spool valve body.
6 Zero leak 4 position single and double effect auxiliary valve.
16 Single action/double action valve.
7 Spacer.
17 Sealed valve.
8 Zero leak 3 position single and double effect auxiliary valve.
18 Zero leak 4 position single and double effect control.
9 Blanking plate.
19 Zero leak 3 position single and double effect control.
10 Nut.
Preliminary operations – Position the tractor on flat stable ground. – Actuate all controls of the auxiliary valves in the floating position, then stop the tractor. If the tractor is fitted with front lifting and one of the valves supplies it: – Isolate lifting by closing the 4 way valve. – Switch off the ignition.
