OPERATING INSTRUCTIONS
LIFTING THE MACHINE WITH A CRANE Template Name: OM_1_col Template Date: 1994_04_29
When lifting this machine with a crane, it is recommended that you use a four leg bridle sling that has a 4536 kg (10,000 pound) lift capacity with a 30 degree sling angle. Each leg of the sling must have a minimum length of 1.8 m (6 ft). The machine must be equipped with the optional D102001 lifting brackets. 1. Make sure that you and the crane operator know and understand the correct hand signals. 2. Keep all other persons out of the area when lifting. Do not move the machine over the heads of people. 3. Make sure that you inspect the lifting equipment each day for damaged or missing parts.
TRIM THIS EDGE
FOUR LEG SLING
1.8 m 6 FEET
Alt= to hide template information Alt+ to display template information
1
BS99C012
1. LIFTING BRACKETS
78
